INSTALLATION & OPERATING
INSTRUCTIONS
for
FREE-STANDING THERMAL SHELVES
BUILT-IN THERMAL SHELVES
TS-24, TS-36, TS-48, TS-60, TS-72
TS-24 Shown
THIS MANUAL CONTAINS IMPORTANT SAFETY AND INSTALLATION-OPERATION INSTRUCTIONS. REQUIRE ALL
!
OPERATORS TO READ THIS MANUAL BEFORE USING THE UNIT. FAILURE TO FOLLOW THE INSTRUCTIONS
CONTAINED IN THIS MANUAL MAY CAUSE INJURY AND/OR DAMAGE TO THE UNIT AND WILL VOID THE WARRANTY.
THIS MANUAL SHOULD BE RETAINED FOR FUTURE USE
REV: 10/26/07
Advertisement
Table of Contents
Related Manuals for Merco TS-24
Summary of Contents for Merco TS-24
- Page 1 INSTALLATION & OPERATING INSTRUCTIONS FREE-STANDING THERMAL SHELVES BUILT-IN THERMAL SHELVES TS-24, TS-36, TS-48, TS-60, TS-72 TS-24 Shown THIS MANUAL CONTAINS IMPORTANT SAFETY AND INSTALLATION-OPERATION INSTRUCTIONS. REQUIRE ALL OPERATORS TO READ THIS MANUAL BEFORE USING THE UNIT. FAILURE TO FOLLOW THE INSTRUCTIONS CONTAINED IN THIS MANUAL MAY CAUSE INJURY AND/OR DAMAGE TO THE UNIT AND WILL VOID THE WARRANTY.
-
Page 2: Specifications
DIMENSIONS (inches/cm) SPECIFICATIONS (Standard Models) Voltage / Amps Length Net Wt.* Ship Wt.* Ship Vol.* Model # Watts inches/cm lbs./kg. lbs./kg. cu. ft./cu. m. TS-24 24/61.0 13/6.0 19/9.0 0.75/0.021 TS-36 36/91.4 18/8.2 25/11.4 1.1/0.031 TS-48 48/122.0 24/11.0 32/15.0 1.5/0.042 TS-60 60/152.4... -
Page 3: General Information
The Merco Savory Thermal Shelf, Model TS, is designed for counter-top applications. The aluminum and stainless steel construction provides durability, even heat transfer and easy cleaning. The adjustable infinite control allows for settings for a wide variety of products. - Page 4 BUILT-IN THERMAL SHELF INSTALLATION INSTRUCTIONS CUT OUT DIMENSIONS: Your counter-top cutout should be ½ inch longer and ½ inch wider than the length and width of the base (not the work surface). The minimum depth of the cutout should be 3 ½ inches. INSTALLATION: Mounting brackets are provided under the work surface turn down (one is located on each side).
- Page 5 This Limited Warranty shall be governed by the laws of the state of Delaware, USA, excluding their conflicts of law principles. The United Nations Convention on Contracts for the International Sale of Goods is hereby excluded in its entirety from application to this Limited Warranty Merco Savory LLC 1111 North Hadley Road Fort Wayne, Indiana 46804 www.mercosavory.com...
- Page 6 This page intentionally left blank. TS Series Operations Manual...
- Page 7 This page intentionally left blank. TS Series Operations Manual...
- Page 8 Merco Savory, LLC 1111 North Hadley Road Fort Wayne, Indiana 46804 United States of America Telephone: (260) 459-8200 U.S. Fax: (888) 790-8193 Int’l Fax: (260) 436-0735 Service Hotline: (800) 678-9511 www.mercosavory.com TS Series Operations Manual...
