PSB CBR III Owner's Manual page 2

1.
Remove the spreader and
components from carton and
place hopper up-side down on
a padded surface as shown.
Insert ends of leg into handle
brace as shown and align
holes. Attach brace and leg to
frame using (4) 1/4-20 x 2" hex
bolts, lockwashers, and nuts.
3/16 Dia. x
2" Cotter Pin
3.
Turn spreader upright on
wheels. Insert screen into
hopper sliding it under the
screen clips. Attach the upper
handle assembly to handle
brace with the handle lever
brackets facing as shown.
Secure with (4) 1/4-20 x 1 1/2"
hex bolts, lockwashers and
nuts.
ASSEMBLY
1/4-20 X 2"
Hex Bolt
Drive Wheel
5/32 Dia. x
1 1/4" Cotter
Pin
Free Wheel
NOTE POSITION OF
LEVER BRACKETS
LOCKWASHER
Handle
Brace
2.
Slide drive and free wheel onto
axle as shown with the longer
portion of wheel hub facing the
frame. Secure free wheel with (1)
5/32 dia. x 1 1/4" cotter pin. Attach
drive wheel to axle with (1) 3/16 dia.
x 2" cotter pin.
Upper Handle
Assembly
1/4-20 NUT
&
LOCKWASHER
1/4-20 X 1 1/2"
Hex Bolt
Leg
1/4-20 NUT
Screen
Screen Clip
