Gas Types: Natural Gas (NG) or Propane (LPG) CUSTOMER INSTALLATION OPERATING INSTRUCTIONS Thank you for purchasing a Paloma Convection Gas Space Heater To operate and maintain this appliance safely and correctly, please read these instructions thoroughly. This appliance must be installed in accordance with: a.
Product Overview General Design Layout Control Panel Features • AS4553 Efficiency Star Rating of 5.9 Stars. • One touch ON/OFF button. • Electronic ignition. • Adjustable Room Temperature. • Economy function. • Low Emission Technology for NG models. • Manufactured in Japan. Safety Devices: •...
Specifications PJC-W13FN PJC-W13FL MODEL PJC-S13FN PJC-S13FL Convection Heater Convection Heater Space Heater Type Gas Input - High (MJ/h) 13.5 13.5 Gas Input - Low (MJ/h) Output (kW) 3.44 3.44 AS4553 Efficiency Star Rating 4247 4247 AS4553 Annual Energy Consumption AS4553 Emission Star Rating AS4553 NO Emmission Performance (ng/J) Approx.
Safety Instructions To ensure safe and proper use of this heater, please read these instructions carefully. Danger – Indicates an immensely hazardous situation which, if not avoided, will result in serious injury or death in the most extreme situations. Warning – Indicates a potentially hazardous situation which, if not avoided, could result in serious injury or death in the most extreme situations.
The heater must be serviced at least once every 12 months. • All replacement parts must be approved Paloma spare parts. • Do not use this heater in areas where spray painting is taking place or in areas such as hairdressers where there may be lots of fluff and dust or where aerosols may be used.
Installation • This room heater must be installed in accordance with this advice to be covered by the Paloma warranty. • This room heater is suitable for indoor installation only. • This appliance must be installed in accordance with: Local Gas Fitting Regulations Municipal Building Codes Australian Standard for Gas Appliance Installations AS/NZS5601.1:-2010...
Regular Care & Maintenance It is the responsibility of the owner to carry out all regular care and organise maintenance and/or service work on this convection heater. All service work must be carried out by a qualified person. Before carrying out any maintenance or service work turn heater off and disconnect hose. After the heater is turned off the convection fan will continue to operate for up to 4 minutes.
Operating Instructions Before you begin ensure that the gas hose connector and electrical cord are plugged in correctly. START UP • Press the ON/OFF Button once to start the heater and the operation light (green) will light up. • After a short delay the combustion light (red) will light up. this indicates proper ignition has been achieved and the burner is on.
ECONOMY OPERATION • To operate the heater in economy mode, press the economy button while the heater is in operation. When the heater is in economy mode the economy operation indicator lights up (green). • To help reduce operating costs and to reduce the cycling of the ignition system, the economy cycle heats up to the temperature selected and after the period of 30 minutes, the temperature allowed to reduce by one degree up to maximum of two degrees for...
Trouble Shooting Please check following important points before calling for a service technician: CONDITION SUGGESTED REMEDY Check that the power cord is plugged in and the power turned on Circuit breaker or fuse is blown Check that gas is turned on See that enough gas is left in LPG tank (in case of LPG appliance) The heater does not operate Operation Light (Green) does not light Check for power failure...
Page 12
1. FLAME FAILURE SAFETY DEVICE It closes the gas valve automatically in the event of a flame failure. 2. OXYGEN DEPLETION SAFETY DEVICE If the oxygen levels drop below a safe level, the oxygen depletion device will cut off the supply of gas to the heater.
Accredited Service Agent’s office and the installed site shall be the owner’s responsibility. 4. If the convection heater is not sized to provide heating in accordance with the guidelines in Paloma’s portable gas heating literature, any resultant fault may not be covered by Paloma warranty.
Page 14
12. If you require a call out and we find that the fault is not covered by Paloma warranty, you are responsible for our standard call out charge. If you wish to have the relevant components repaired or replaced that service will be at your cost.
Page 15
You are also entitled to have the goods repaired or replaced if the goods fail to be acceptable quality and the failure does not amount to a major failure. Paloma/Rheem warranty (set out above) is in addition to any rights and remedies that you may have under the Australian Consumer Law.
(2) Refer to trouble shooting guide (page 11) and malfunction display chart (page 11). (3) Contact Rheem Service. Approval These Paloma models have been certified by the Australian Gas Association under Certificate Number: 5899 In keeping with our policy of continuous progress and product improvement, we reserve the right to make changes without notice.
