Niles IntelliControl GXR2 Datasheet page 2

GXR2
FEATURES
• Modular MultiZone Receiver distributes up to
six sources to six zones
• Built-in High Current 12-channel Amplifier
delivers 55 watts per channel RMS @ 8 ohm
and 85 watts per channel @ 4 ohm to each of six
zones
• Integrated Six Slot Card Cage accepts
any combination of up to six IntelliControl ICS
integration modules
• Plug and Play Integration of IntelliControl
ICS integration modules
• Reliable "One Touch to Music" operation
using IntelliControl ICS Touch Screens, Keypads
and remote controls
• Party Mode turns on all your favorite areas from
any keypad or remote control
• Global Off turns off all areas from any keypad
or remote control
• Tone Controls fine tune bass and treble in each
separate zone
• Balance Control fine tunes channel levels in
each separate zone
• Programmable Turn-On Volume for each
zone
• Alarm Clock and Sleep Timer for each zone
• Paging/Doorbell Input enables system wide
voice announcements from a phone system or
doorbell sounds from the Niles DBI-1
• Zone Linking allows a grouping of zones to
be controlled as a single zone. Turn-On, Source
selection, Paging and Turn-Off all work in unison,
yet each zone has independent volume adjustment
and muting
• Home Theater Integration Ports enable audio
and video source components shared with the home
theater system to be turned on, controlled via IR and
turned off as needed
© 2 0 0 7 N i l e s A u d i o C o r p o r a t i o n 1 2 3 3 1 S . W. 1 3 0 S t r e e t , M i a m i , F L 3 3 1 8 6 Te l : 8 0 0 . B U Y. H I F I – w w w. n i l e s a u d i o . c o m – A l l r i g h t s r e s e r v e d .
N i l e s , t h e N i l e s l o g o s , I n t e l l i C o n t r o l a n d I n t e l l i F i l e a r e r e g i s t e r e d t r a d e m a r k s o f N i l e s A u d i o C o r p o r a t i o n . A l l o t h e r t r a d e m a r k s a r e t h e
p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s . D e s i g n e d a n d e n g i n e e r e d i n t h e U S A . 0 3 / 0 7 LT 0 0 2 2 5 B
WWW.INTELLICONTROL.COM
P R O D U C T
MODULAR MULTI-ZONE RECEIVER
D E T A I L S
110 VOLT FG01174
220 VOLT FG01190
• Selectable Fixed/Variable Zone Preamp
Outputs with 12 Volt Triggers for external
amplifier applications
• Source Matching Gain Control ensures
changing sources doesn't require changing
volume control settings
• Removable Speaker Connectors hold up to
12-gauge speaker wire
• Expandable up to 30 Zones with additional
GXR2s
• Includes Rack Mount Kit and hardware
SPECIFICATIONS
• Agency certifications:
FG01174: Class 2/SELV covering US, Canadian
and EU markets
FG01190: Safety: UL/EN 60065
EMC: CE, CTICK
• 55 watts x 12 channels
• Frequency response: 26-20 kHz +/- 3 db
• Signal to Noise: > = 85 db
• Power supply:
FG01174: AC 120V, 60Hz
FG01190: AC 240V, 50Hz
• Power consumption: 1500 watts maximum
DIMENSIONS
• 17-3/8" wide x 5-3/4" high (including feet)
x 18" deep
WARRANTY AND SHIPPING
• Warranty: Two year limited
• Shipping: Weight: 54 lbs
Specifications subject to change.
