- Page 1 Meijer.com 73-0116-250 6/09 Featuring Ready-to-Run Ready-to-Run Owner’s Manual Owner’s Manual CAUTI O N—ELECTRI C TOY CAUTI O N—ELECTRI C TOY NOT RECOMMENDED FOR CHI L DREN UNDER EI G HT YEARS OF AGE. AS WI T H ALL NOT RECOMMENDED FOR CHI L DREN UNDER EI G HT YEARS OF AGE. AS WI T H ALL ELECTRIC PRODUCTS, PRECAUTIONS SHOULD BE OBSERVED DURING HANDLING ELECTRIC PRODUCTS, PRECAUTIONS SHOULD BE OBSERVED DURING HANDLING AND USE TO PREVENT ELECTRI C SHOCK.
-
Page 2: Fcc Statement
Explore the possibilities at your authorized Lionel dealer. Use this Owner’s Manual to learn how to set up, operate, and maintain your train set for years of reli- able operation. - Page 3 • One straight FasTrack terminal track section • Smoke fluid • Replacement traction tire • Owner's manual The following Lionel marks may be used throughout this instruction manual and are protected under law. All rights reserved. Lionel , TrainMaster , Odyssey...
-
Page 4: Table Of Contents
CW-80 Transformer operation Powering your layout with the CW-80 Transformer Maintaining and servicing your set Lubricating your locomotive Replacing the traction tire Replacing your locomotive’s headlamp Troubleshooting Lionel Limited Warranty Policy & Service 73-0116-250 Lone Ranger.indd 4 8/14/09 10:34 AM... -
Page 5: Creating Your Layout
• To avoid the risk of electrical shock, do not disassemble the unit. There are no user serviceable parts inside. If damaged, take this product to an authorized Lionel Service Center. A list of autho- rized Service Centers is packed with this unit. -
Page 6: Building Your Lionel Layout
Meijer.com Creating your layout Building your Lionel layout our set comes with eight curved, three straight, and one terminal section of track. Figure 1 pro- vides some examples of layouts that you can build with these track sections. By adding more FasTrack track sections, you can create an endless number of exciting track arrangements for more fun, action, and variety. -
Page 7: Joining The Fastrack Track Sections
Meijer.com Creating your layout Joining the FasTrack track sections asTrack track sections join together easily. With interlocking roadbed sections and large rail tabs, the track fits together securely so you always have good electrical contact. Take a look at Figure 3 to see how to join the track sections. -
Page 8: Wiring Your Cw-80 Transformer
Be sure that the blades are touching the metal post. Tighten the thumbscrew to secure the connection. 4. If you need to power an accessory (available separately at your authorized Lionel dealer), connect the accessory to the ACCESSORY thumbscrew terminals. Use the accessory wire included with the CW-80 Transformer.. 73-0116-250 Lone Ranger.indd 8... -
Page 9: Wiring Your Cw-80 Transformer
Meijer.com Creating your layout Wiring your CW-80 Transformer (continued) 5. Plug the CW-80 Transformer into your wall outlet (120 volts). As your layout expands, you may also make power connections with the stripped ends of wires, placing no more than two wires on each terminal. For best performance on large layouts, it is recommended that you use 16-gauge wire to connect your CW-80 Transformer to the track. -
Page 10: Running Your Train
Power up your locomotive with your transformer. • Your locomotive is designed to operate on 7-15 volts alternating cur- rent. Virtually all Lionel and Lionel-compatible alternating-current transformers are suitable. • Do not power your locomotive with direct current (DC) transformers. -
Page 11: Adding Smoke Fluid To Your Locomotive's Smoke Generator
ON position. Refer to Figure 9 on page 15 for the location of the switch. The smoke generator requires the periodic addition of Lionel smoke fluid in order to function. A small bottle of smoke fluid is included with this set. Press down and unscrew the cap. Pierce the end of the nozzle with a pin, then add about four drops of fluid directly into the locomotive’s... -
Page 12: Coupling
Meijer.com Running your train Coupling hen coupling your cars, at least one of the mating couplers must be open as shown at the left in Figure 7. Press down on the lock release to open the coupler, then push the cars toward each other until they lock together. -
Page 13: Experiencing The Features Of The Cw-80 Transformer
Meijer.com Running your train Experiencing the features of the CW-80 Transformer Refer to Figure 8 on page 14 for the location of the Transformer features listed in this section. THROTTLE Push the throttle forward to increase track power. The markings on the throttle approximate the percentage of full power. - Page 14 The green light illuminates when the CW-80 is on. Whistle/Horn Activates the whistle or horn sound effect in your Lionel locomotives. Press Throttle Controls your locomotive’s speed. Throw the WHISTLE/HORN to begin the sound; release the button to end it.
-
Page 15: Reverse Unit Procedure
Running your train Reverse unit procedure he electronic reverse unit inside your Lionel locomotive acts like the transmission in a car. When you apply power to the track, the locomotive moves in the direction specified by the reverse unit—or it sits in neutral, awaiting another power interruption. Power interruptions are the signal that tells the reverse unit to sequence to the next operational state. -
Page 16: Operating The Sounds In The Baggage Car
Meijer.com Running your train Operating the sounds in the baggage car our Baggage Car requires one nine-volt alkaline battery. To install the battery (not included) , remove the screw from the end of the car, lift it off the frame, and gently push backward to release the catch. -
Page 17: Trainsounds Sound System Operations
Meijer.com TrainSounds sound system operation Operating the TrainSounds sound system our TrainSounds Tender was designed to operate at approximately 6 to 18 volts (AC). When you power up the locomotive on the track, you will hear the sounds of the idling steam locomotive. The chuffing intensity will increase proportionally with the locomotive’s speed. -
Page 18: Adjusting The Volume
Meijer.com TrainSounds sound system operation Adjusting the volume se the volume control knob on the underside of the TrainSounds Tender to adjust the volume. Refer to Figure 11. Volume control knob Sound ON/OFF switch Figure 11. Volume control knob and switch location Silencing the chuffing sounds o silence the chuffing sounds, slide the switch on the underside of the tender to the OFF position. -
Page 19: Cw-80 Transformer Operation
Meijer.com CW-80 Transformer operation Powering your layout with the CW-80 Transformer our CW-80 Transformer provides a total output of five amps. The track outputs will deliver all of this power to the track when no accessories are connected to the Transformer. Keep in mind that connected accessories borrow some of this power. -
Page 20: Maintaining And Servicing Your Set
We recommend that you purchase a Lionel Lubrication and Maintenance Kit (6-62927), available from your Lionel dealer. Two basic rules to keep in mind: never over-lubricate (a small amount will do), and avoid getting grease or oil on the locomotive’s wheels or your track. You’ll know your loco- motive requires lubrication when visual inspection reveals dryness on the parts indicated in Figure 12. -
Page 21: Replacing The Traction Tire
3/16” nut driver to remove the drive rod nut. Slip off the worn tire and position the replacement tire around the wheel. Carefully fit the tire into the groove. If you are uncomfortable with this opera- tion, you may choose to have the traction tire replaced by your authorized Lionel Service Center. 73-0116-250 Lone Ranger.indd 21... -
Page 22: Replacing Your Locomotive's Headlamp
Lionel part nol 600-0191-300. During the course of normal operations, the lamp in your locomotive may require replacement. Replacement lamps are available at your authorized Lionel Service Center or from Lionel Service in Chesterfield, Michigan. -
Page 23: Troubleshooting
Meijer.com Maintaining and servicing your set Troubleshooting No lights or operation Be sure that the CW-80 Transformer is plugged in and the wires are connected. Train runs, but WHISTLE, BELL, and DIRECTION buttons do not work Check track connections. The track must be connected to the “A” and “U” terminals on the Transformer. -
Page 24: Lionel Limited Warranty Policy & Service
(or copy) from an Authorized Lionel Retailer*, will at the discretion of Lionel LLC, be repaired or replaced, without charge for parts or labor. In the event the defective product cannot be repaired, and a suitable replacement is not available, Lionel will offer to replace the product with a comparable model (determined by Lionel LLC), if available.
