Dukane WMIC1 User Manual

Dukane WMIC1 User Manual

Wireless microphone system for 2.4 ghz wireless mic and receiver system
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

WIRELESS MICROPHONE SYSTEM FOR 2.4 GHZ
MODEL; WMIC1

USER GUIDE

Wireless Mic and Receiver System
DUKANE CORP
Audio Visual Products
2900 Dukane Drive
St. Charles, Illinois 60174
www.dukane.com/av
Toll-free: 888-245-1966
Fax: 630-584-5156
E-mail:
avsales@dukane.com
430-WMIC1 User Guide–02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WMIC1 and is the answer not in the manual?

Questions and answers

Related Manuals for Dukane WMIC1

Summary of Contents for Dukane WMIC1

  • Page 1: User Guide

    WIRELESS MICROPHONE SYSTEM FOR 2.4 GHZ MODEL; WMIC1 USER GUIDE Wireless Mic and Receiver System DUKANE CORP www.dukane.com/av Audio Visual Products Toll-free: 888-245-1966 2900 Dukane Drive Fax: 630-584-5156 St. Charles, Illinois 60174 E-mail: avsales@dukane.com 430-WMIC1 User Guide–02...

  • Page 2: General Information

    GENERAL INFORMATION Thank you for purchasing the Dukane Wireless Microphone System WMIC1. This system operates using digital voice coding which is transmitted by radio frequency signal at 2.4GHz. The system consists of a small lightweight transmitter into which a headset, lapel or other mic can be plugged.

  • Page 3: Audio Output

    3.5 mm mini plug on the front of the unit . Connect this output to an amplifier or the MIC input of a projector. The audio out is at line level, so if connecting to a Dukane projector set the MIC LEVEL to HIGH. This is found on the projector at ADVANCED MENU then AUDIO / MIC LEVEL / then HIGH.
  • Page 4 DUKANE the transmitter top. Use either the headset mic or the clip on mic. WMIC1-TX Using the left side power button ( see 8 below) hold it down for 3 seconds to turn ON the power. The indicators will flash red and green.

  • Page 5: System Operation

    DUKANE WMIC1-TX RF Transmitter Using the headset mic and transmitter 3. Pairing; Bring the transmitter close to the receiver ( within 3 ft if possible ). After a short time the transmitter will lock to the receiver. When this happens the transmitter light will remain ON, a solid green.

  • Page 6: Specifications

    Dukane Corporation disclaims all liability for incidental or consequential damage of any kind, including all damages arising out of any interruptions in operation of the product and all damages to software. No person, firm, or representative is authorized to assume any obligation or to make any warranty on behalf of the Dukane Corporation other than as stated above.
