The Worlds Models Manufacturing AeroPet 90 Instruction Manual

0.91- 1.10 cu.in. displacement 4-stroke
Hide thumbs
Table of Contents

Advertisement

Quick Links

AeroPet 90
AeroPet 90
0.91- 1. 10 cu.in. Displacement 4-stroke
Requires: 5-channel radio
Wing Span
Wing Area
Flying Weight
Fuselage Length
Warning ! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of engine powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual
at hand for quick reference.
and 1 low profile retract servo.
* Specifications are subject to change without notice.*
w/ 5 standard servos
Specifications
67 in /1700 mm
854 sq in / 55.1 sq dm
.
8 2 lbs / 3700 g
67.5 in /1710 mm
INSTRUCTION MANUAL
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY (ARF) SERIES
MADE IN CHINA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AeroPet 90 and is the answer not in the manual?

Questions and answers

Summary of Contents for The Worlds Models Manufacturing AeroPet 90

  • Page 1 INSTRUCTION MANUAL AeroPet 90 AeroPet 90 0.91- 1. 10 cu.in. Displacement 4-stroke Requires: 5-channel radio w/ 5 standard servos and 1 low profile retract servo. Specifications 67 in /1700 mm Wing Span 854 sq in / 55.1 sq dm Wing Area...

  • Page 2: Before You Begin

    AeroPet 90 AeroPet 50 I N D E X BEFORE YOU BEGIN P. 1 PARTS LIST P. 2 ASSEMBLY P. 3 - 11 SAFETY PRECAUTIONS P. 11 BEFORE YOU BEGIN Apply instant glue Apply epoxy glue. (C.A.glue, super glue.) Must be purchased separately!

  • Page 3: Parts List

    Parts List 1. MAIN WING--1 pair 12. THROTLE PUSHWIRE 1.2x530mm -- 1 pc. Ø PLASTIC TUBE d2xD3x150mm -- 1 pc. 2. WING TUBE Ø 16x479mm--1 pc. ALUMINUM PLATE (For Engine Mount) -- 1 pc. ANTI-VIBRATION MOUNT 4C-91 -- 1 set 3.
  • Page 4 Main Wing A p p l y i n s t a n t t y p e C A g l u e t o b o t h s i d e s o f e a c h h i n g e . Main Wing Please apply glue to all surfaces of wing tube.

  • Page 5: Aileron Servo

    Aileron Servo 1mm pilot holes for World Models tri-horn are pre-drilled. Ø Please look for pin-hole marks at under side of control surfaces. PM2 x22mm Screw Straper Fuel Tube Ø6x5mm P M2x22mm Clevis Pushrod Ø1.8x140mm Bottom View Retractable Landing Gear Servo Adjuster R-side Set Screw...

  • Page 6: Tail Landing Gear

    Vertical Fin / Rudder Apply instant type CA glue to both sides of each hinge. B = B' Tail Landing Gear 2.5mm 1.5mm Screw PA3x12mm Collar 2.6mm 2.6mm Collar PA3x12mm M3x3mm Set Screw Bottom View Rudder Pullwire PM2x20mm Screw M2 Nut Fuel Tube M2 NUT Ø6x5mm...

  • Page 7: Elevator Pushrod

    Elevator Pushrod 1mm pilot holes for World Models tri-horn are pre-drilled. Ø Please look for pin-hole marks at under side of control surfaces. Screw PM 2 x18 mm ≈65mm Engine Mount PM4 x25mm Screw PM 4x 25mm Washer 4.5x D9mm d4.5 x D9mm Washer A p p l y t h r e a d l o c k e r t o s c r e w s...
  • Page 8 Engine M 4 x 3 5 m m S O C K E T H E A D S C R E W M4 Nylon Insert Lock Nut d4 x D12mm d4 x D12mm Washer KM3x20mm Screw M4 Nylon Insert Lock Nut d4 x D12mm Nylon Insert Lock Nut M 4 x 3 5 m m...

  • Page 9: Radio Equipment

    Radio Equipment Install and arrange the servo as shown in the diagram. Fuel Tube 6x5mm Bottom View Elevator Push rod Press down the center Ø1.8x95mm 1/3 portion M2 Nut Wire Copper Tube KM 2x8mm Main Wing PM4 x45mm Screw d4 . 2xD14 . 5mm Washer PM4 x45mm Washer d4.2xD14.5mm...
  • Page 10 Canopy First insert the grommet to the canopy then apply screw. PWA2 3 x8mm Screw Apply double-sided tape d1.5 x D6.5 mm Silicon Grommet Silicon Grommet d1.5xD6.5mm PWA2.3 x 8 mm Cowling First insert the grommet to the cowling then apply screw. PWA2 6 x12mm Screw PWA2...

  • Page 11: Stabilizer Setting

    Wing Setting A=A' B=B' C=C' Stabilizer Setting M3X6mm Set Screw BOTTOM TO INCREASE INCIDENCE ANGLE, LOOSE BOTTOM SET SCREW AND THEN TIGHTEN TOP SET SCREW. TO REDUCE INCIDENCE ANGLE, LOOSE TOP SET SCREW AND THEN TIGHTEN BOTTOM SET SCREW. DON'T OVER TIGHTEN SET SCREWS AS THE INCIDENCE ANGLE ADJUSTER ARE MADE OF PLASTICS.

  • Page 12: Control Throws

    #Pre-flight adjustment must be done before flying, it is very dangerous to fly a badly pre-adjusted aircraft. AeroPet 90 AeroPet 50 is specially designed to be powered by 4c 0.91- 1.10 engine, using a more powerful engine does not mean better performance. In fact, over powered engine may cause severe damage and injuries.
  • Page 13 LINKAGE CONNECTOR HW7111050 & HW7111060 Drill 2mm hole at servo horn. Insert linkage connector into servo horn. Make sure shoulder of screw is cleared from servo horn. Add washer to reduce play if necessary. Shoulder Tighten up the round nut against the shoulder.
  • Page 14 We would like to share with you any relevant information regarding your model, including product news and free upgrade parts when applicable. Please fill in the following and send to AirBorne Models, 4749-K, Bennett Drive, Livermore, CA 94551 USA. 1. Name: 2.
  • Page 15 The World Models Manufacturing Co., LTD. www .thew orldm odels .com A247PO12680906...
