U
G
SER
UIDE
HDMI™ 1.3 S
PLITTER
Model: 40471
/40472
(2 Port)
(4 Port)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 40471 and is the answer not in the manual?

Questions and answers

Summary of Contents for TRUlink 40471

  • Page 1 UIDE HDMI™ 1.3 S PLITTER Model: 40471 /40472 (2 Port) (4 Port)
  • Page 2: Table Of Contents

    ABLE OF ONTENTS Introduction..............................2 Features..............................3 Package Contents............................4 Device Overview............................5 Device Installation Device Installation ..........................7 Cascading the Splitter........................10 Troubleshooting............................13 Technical Specifications...........................14 Cables To Go One Year Warranty......................15 Important Safety Information........................16...
  • Page 3: Introduction

    Thank you for purchasing the TruLink™ HDMI™ 1.3 Splitter. This 1.3 compliant HDMI Splitter with HDCP compatibility will connect an HDMI equipped source to two (40471) or four (40472) HDTV displays equipped with HDMI inputs. TruLink Splitters are designed to support 480i, 480P, 720P, 1080i and 1080P resolutions.
  • Page 4: Features

    EATURES HDMI™ (v1.3 with Deep Color, x.v. color, high speed refresh rates and lossless multi-channel surround sound. Supports 480i, 480p, 720p, 1080i, 1080p 12-bit Deep Color HDCP-compliant for HDTV applications Built in Equalizer allows placement of monitors up to 150 feet away by cascading with other splitters...
  • Page 5: Package Contents

    ACKAGE ONTENTS HDMI™ 1.3 Splitter (1) Power Adapter (1) User Manual (1)
  • Page 6: Device Overview

    (40471) EVICE VERVIEW Display Output Indicator LEDs 40471 Front Power Indicator 40471 Rear Power Supply HDMI HDMI Input Input Outputs...
  • Page 7 (40472) EVICE VERVIEW Display Output Indicator LEDs Power 40472 Front Indicator 40472 Rear Power HDMI HDMI Supply Input Input Outputs...
  • Page 8: Device Installation

    EVICE NSTALLATION Step 1 Make sure that your HDMI enabled device and televisions/monitors are turned off. Step 2 Using an HDMI cable (not included), connect the HDMI output of your source device to the HDMI input on the rear panel of the HDMI splitter. Step 3 Using HDMI cables connect the HDMI Splitter outputs to the HDMI inputs on your televisions/monitors.
  • Page 9 EVICE NSTALLATION...
  • Page 10 EVICE NSTALLATION Step 4 Plug in the included 5VDC power adapter to the rear panel of the HDMI splitter, and connect the opposite end into a receptacle outlet. Step 5 Power on source device as well as your televisions/monitors. Step 6 Change your televisions/monitors to its HDMI input (please refer to your television/monitor owner’s manual if assistance is needed with changing inputs).
  • Page 11: Cascading The Splitter

    ASCADING THE PLITTER The HDMI outputs on the rear panel of the splitter are capable of being split up to three levels. This can be referred to as cascading or daisy-chaining. With the two-way splitter, you can take one source device (DVD player, satellite or cable receiver, etc.) and split it so that you can connect up to eight televisions/monitors at the same time.
  • Page 12 ASCADING THE PLITTER Example: Cascading 40471 Diagram...
  • Page 13 NOTE: The resolution mode will depend on the first of the sequenced display devices that can successfully communicate with source device. The detect sequence of 40471 is from Port 1 to Port 2, and 40472 is from Port 1 to Port 4. Make sure your display devices can support the highest resolution as source device can support, and your display devices are HDCP compliant and fully support HDCP.
  • Page 14: Troubleshooting

    ROUBLESHOOTING Problem Solution No Operation Verify the 5V power supply is connected to the selector. Verify unit’s power is on by the power indicator Red LED. No picture or signal; 1. Make sure your video display is HDCP compliant. Poor picture. 2.
  • Page 15: Technical Specifications

    1.2V p-p HDMI Standard Compliant with HDMI 1.3b Product Dimension 8 ¾”W x 2 ¾”D x 1 ¼”H Product Weight 1 lb Power Supply Input 100-240V~50/60Hz 0.2A DC 5V 1.0A for 40471 Power Supply Output DC 5V 2.0A for 40472...
  • Page 16: Cables To Go One Year Warranty

    ™ O ABLES ARRANTY At Cables To Go, we want you to be totally confident in your purchase. That is why we offer a one year warranty on this device. If you experience problems due to workmanship or material defect for the duration of this warranty, we will repair or replace this device.
  • Page 17: Important Safety Information

    ©2008.TruLink is a trademark of Cables To Go. HDMI is either a trademark or registered trademark of HDMI Licensing LLC. This product is not manufactured or endorsed by HDMI Licensing LLC.
  • Page 19 For more information on this product or to check for updated drivers, manuals or frequently asked questions please visit our website. www.cablestogo.com . 1.0.12.12.08...
