- Page 1 GE Security Installation/Operation Instructions Warranty Information VAT7420 VAT7420-R3 VAR7420 VAT7430 VAR7420-R3 VAT7430-HP VAR7430 VAT7450 VAR7430-R3 VAT7450-R3 VAR7450 VAT7450-HP VAR7450-R3 www.ifs.com 888-999-9IFS...
- Page 2 VAT/VAR7400 - Audio Input + Audio Input AUDIO A Ground - Audio Input + Audio Input AUDIO B Ground - Audio Input AUDIO C + Audio Input Ground - Audio Input AUDIO D + Audio Input Ground...
- Page 3 VAT7420 -- - 3 4 CHANNEL DIGITAL + - 2 VIDEO TRANSMITTER AUDIO A 4 CHANNEL DIGITAL AUDIO -- - 3 + - 2 AUDIO B International Fiber -- - 3 Systems + - 2 AUDIO C Incorporated 203.426.1180 WWW.ifs.COM -- - 3 + - 2 AUDIO D...
- Page 4 VAT7400 AUDIO B AUDIO D AUDIO A AUDIO C CHAN 1 CHAN 2 CHAN 3 CHAN 4 POWER CAMERA ON Audio B Level LEDs illuminates Audio A Level LEDs illuminates Video Input Camera Input Indicators LED illuminates Audio D Level LEDs illuminates Audio C Level LEDs illuminates...
- Page 5 VAR7400 TRANSMIT POWER CARRIER REMOTE VIDEO ON RECEIVER LOCKED CHAN 1 LOCAL VIDEO ON LED: Illuminates Transmit Carrier LED: Illuminates Video Detected From Camera 3 Video Detected From Camera 2 LED: Illuminates Video Detected From Camera 1 LED: Illuminates LED: Illuminates Video Present On Channel 1 LED: Illuminates Video Present On Channel...
- Page 6 INSTALLATION INSTRUCTIONS FOR ADDITIONAL COMPONENTS REQUIRED TO MEET EMISSION REQUIREMENTS ON THE VAT74XX SERIES AND VAR74XX SERIES STAND ALONE UNITS. INSTALL SUPPLIED EMI FILTER CLAMP (IFS P/N FL0431164181 OR FAIR RITE P/N 0431164181) 0N ALL 4 AUDIO CABLES AS SHOWN. INSTALL SUPPLIED EMI FILTER CLAMP (IFS P/N FL0444177081 OR FAIR RITE P/N 0444177081) 0N ALL 4 VIDEO CABLES AS SHOWN.
- Page 7 INSTALLATION INSTRUCTIONS FOR ADDITIONAL COMPONENTS REQUIRED TO MEET EMISSION REQUIREMENTS ON THE VAT74XX SERIES AND VAR74XX SERIES STAND ALONE UNITS. INSTALL SUPPLIED EMI FILTER CLAMP (IFS P/N FL0443164251 OR FAIR RITE P/N 0443164251) 0N THE POWER CABLE AS SHOWN.
- Page 8 INSTALLATION INSTRUCTIONS FOR ADDITIONAL COMPONENTS REQUIRED TO MEET EMISSION REQUIREMENTS ON THE VAT74XX-R3 and VAR74XX--R3 Series RACK MOUNT UNITS. GASKET INSTALL SUPPLIED CONDUCTIVE FOAM GASKET (IFS P/N MMRFGSKT 375X500 or CHOMERICS P/N 82-122-74021-09600) CUT TO 3 INCH LENGTH AND PLACE ON TOP RAIL OF THE RACK (AS SHOWN), WHERE THE UNIT IS TO BE INSTALLED.
-
Page 9: Fcc Compliance
FCC Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesirable operation. Changes or modifications not expressly approved by International Fiber Systems, Inc.
