User Manual
RT3008 / RT3016
─ ─ 4/8/16CH DVR ─ ─
This document contains preliminary information and subject to change without notice.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RT3016 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ritron RT3016

  • Page 1 User Manual RT3008 / RT3016 ─ ─ 4/8/16CH DVR ─ ─ This document contains preliminary information and subject to change without notice.
  • Page 2 WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. NOTE: This equipment has been tested and found to comply with the limits for a class digital device, pursuant to part 15 of the FCC Rules.
  • Page 3: Table Of Contents

    Table of Contents CHAPTER 1 PACKING DETAIL AND INSTALLATION _____________________ 5 1-1 PACKING__ _________________________________________________ 5 1-2 Hard Disk Installation ________________________________________ 6 1-3 DVD-RW Installation _________________________________________ 7 CHAPTER 2 PANEL LOCATION ________________________________________ 9 2-1 FRONT PANEL CONTROLS ___________________________________ 9 2-2 16CH REAR PANEL CONNECTORS ___________________________ 10 2-3 8CH REAR PANEL CONNECTORS ____________________________ 11 2-4 4CH REAR PANEL CONNECTORS ____________________________ 12 CHAPTER 3 LIVE, PLAYBACK AND PTZ OPERATIONS _________________ 13...
  • Page 4 5-2.2 TIME SEARCH_________________________________________ 43 CHAPTER 6 NETWORK SURVEILLANCE ______________________________ 44 6-1 AP Software Installation and Setup ___________________________ 44 6-2 AP Software Operation ______________________________________ 46 CHAPTER 7 SPECIFICAITONS_______________________________________ 48 CHAPTER 8 MOBILE APPLICATION INSTALLATION AND USAGE __________ 50 8-1 Mobile Application Installation and Operation for Symbian System _____________________________________________________________ 50 8-1.1 Mobile Application Installation___________________________ 50 8-1.2 Mobile Application Operation____________________________ 51...
  • Page 5: Chapter 1 Packing Detail And Installation

    CHAPTER 1 PACKING DETAIL AND INSTALLATION 1-1 PACKING 1. DVR 2. Quick Start 3. IR Remote Control 4.Batteries x2 *Please press “DVR1”button before operation. 5. CD 6. Hard Disk Mount x2 7. Screws x20 8. Power Adaptor 9. Power Cord 10.
  • Page 6: Hard Disk Installation

    1-2 Hard Disk Installation Step 1) Fix the HDD to rack mount with the screws as indicated. Step 2) Place the HDD on the HDD plate and screw it as indicated. Step 3) Connect the power and the SATA cables as indicated. Note: After installation, please initialize Hard Disk before starting to record.
  • Page 7: Dvd-Rw Installation

    1-3 DVD-RW Installation Step 1) Remove the front cover from DVR. Step 2) Put the DVD-RW into the DVR as indicated by the arrow. 2009.3.25 V1.12...
  • Page 8 Step 3) Screw the bottom of the DVR as indicated to fix the DVD-RW. Step 4) Connect the power and the SATA cables. 2009.3.25 V1.12...
  • Page 9: Chapter 2 Panel Location

    CHAPTER 2 PANEL LOCATION ○ 2-1 FRONT PANEL CONTROLS ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Control Keys Description ○ Start or stop recording. ○ Play back in normal speed. PLAY ○ Display the search menu. T-SRH In LIVE mode, press to display the BACKUP menu.
  • Page 10: 16Ch Rear Panel Connectors

    2-2 16CH REAR PANEL CONNECTORS ③ ○ ○ ○ ○ ○ ○ ⑬ ○ ○ ○ ○ ○ ○ MAIN monitor BNC port for the main monitor. BNC port to display full screen image of all installed cameras ○ SPOT monitor in sequence.
  • Page 11: 8Ch Rear Panel Connectors

    2-3 8CH REAR PANEL CONNECTORS ③ ○ ○ ○ ○ ○ ○ ○ ○ ⑩ ○ ○ ○ MAIN monitor BNC port for the main monitor. BNC port to display full screen image of all installed cameras in ○ SPOT monitor sequence.
  • Page 12: 4Ch Rear Panel Connectors

    2-4 4CH REAR PANEL CONNECTORS ③ ○ ○ ○ ○ ○ ○ ○ ○ ⑩ ○ ○ ○ MAIN monitor BNC port for the main monitor. BNC port to display full screen image of all installed cameras ○ SPOT monitor in sequence.
  • Page 13: Chapter 3 Live, Playback And Ptz Operations

    CHAPTER 3 LIVE, PLAYBACK AND PTZ OPERATIONS The IR remote control and mouse operate differently under each mode; this chapter describes the functions of them under three different modes: LIVE, PLAYBACK and PTZ. 3-1 LIVE Mode You can monitor all the channels, listen to audio signal and have some related operations under LIVE mode.
  • Page 14 Table 3-1.2 Graphical icons that will display after right-clicking your mouse under LIVE mode. Icon Description Resting the cursor on this icon will bring up the following four menu icons. Main menu. Search menu. Backup menu. PTZ mode. Turn on/off recording. Playback.
  • Page 15 Table 3-1.3 Description of on screen graphical icons in LIVE mode Icon Description Recording is on Live Audio is on Live Audio is off Motion detected on the channel Sensor triggered on the channel Video loss detected on the channel USB device detected DVD burner is detected Connected to the LAN cable.
  • Page 16: Playback Mode

    3-2 PLAYBACK Mode Switch to PLAYBACK mode by pressing “PLAY” under the LIVE mode, the graphical icon will show up on the upper center of the screen and the operation panel ( see below picture) will show up at right lower corner of the screen. You can drag the panel by mouse to place it on any location of your screen.
  • Page 17 Table 3-2.2 The mouse operation under the PLAYBACK mode. Icon Description 「 」 Fast rewind 「 」Fast forward Play/pause / 「▲ / SLOW」 ,slow playback 「▼ / ■」stop playback Playback channel by channel with snap shot display Full screen display Quad display 9-channel display 16-channel display...
  • Page 18: Ptz Mode

    3-3 PTZ Mode Switch to the PTZ mode by pressing “PTZ” button under the LIVE mode. The PTZ icon will appear on upper left side of screen and the control panel will appear on the down right side of screen. Table 3-3.1 Remote Control functions under the PTZ mode Button Description...
  • Page 19 Table 3-3.2 Mouse operation under the PTZ mode Icon Description Leave PTZ Mode,back to the LIVE mode Pre-set number N. (1~64) Go to pre-set number N. Set current PTZ location at pre-set number N. 「TOUR」 ,press to activate pre-set tour* 「PIP」...
  • Page 20: Chapter 4 Main Menu Setup

    CHAPTER 4 MAIN MENU SETUP To enter the main menu and set up DVR, log-in account and user password are required. The default password of the administrator is “123456”. Please check the “Account Setup” for related setup of other log-in users. Table 4-0.1 Some definition of virtual keyboard.
  • Page 21: Record Setup

    Table 4-0.2 The operation of remote control under the setting menu Item Description Switch to different options under one item Switch to different items MENU Save setup and back to LIVE mode Back to Upper level of menu without saving ENTER Enter the menu, or display virtual keyboard PS.
  • Page 22: 4-1.1 Quality & Frame Rate Setup

    4-1.1 Quality & Frame Rate Setup : Note 4CH DVR will display 4 channels and 8CH DVR will display 8 channels. Item Description Resolution Choose record resolution from : CIF / HD1(2CIF) / D1. Record Type You can setup quality and FPS separately for record type. Check/uncheck the box will enable/disable recording of that channel.
  • Page 23: 4-2.1 Motion Setup

    4-2.1 MOTION SETUP Item Description Check the box to Enable/Disable Motion Detection for all Motion Detection channels. Check the box to Enable/Disable popup screen function for all Motion Popup channels. When motion is detected in LIVE mode, the detected channel image will pop up in full screen display. 1~16 You can setup independently for each channel.
  • Page 24: 4-2.2 Sensor Setup

    Item Description LOCK/ZOOM Press LOCK/ZOOM to select entire screen as detection area. MUTE / PIP Press MUTE/PIP to deselect entire screen as detection area. STATUS Switch between “select” and “deselect” for cursor-dragging function ENTER Press to function on the selected area with assigned status MENU Press to save the setup and leave Press to cancel the setup and leave...
  • Page 25: Schedule Setup

    4-3 SCHEDULE SETUP Except from starting recording manually, you can also setup the recording time by weeks and schedule including normal, motion detect, and sensor detect recording type. Item Description Click or press ▼ to select Page. Each page provides 10 schedules Page for setup.
  • Page 26: 4-3.2 Holiday Setup

    4-3.2 Holiday Setup Since holidays are different by different country and region, you can setup the holiday of your location accordingly. 4-4 CAMERA SETUP Item Description You can setup independently for each channel. : 1~16 Note 4CH DVR will display 4 channels and 8CH DVR will display 8 channels.
  • Page 27: Account Setup

    4-5 ACCOUNT SETUP The Account Setup menu is used to provide role-based permission independently setting for each user (maximum of 4 users) to access DVR over network. The default admin account and password is “admin” and “123456” The default password remains the same after firmware upgrade, however, it requires 8-digits for password length when you setup a new one Item Description...
  • Page 28: 4-5.1 Permission Setup

    4-5.1 Permission Setup The Account Setup is set to provide individual user (maximum of 4 users) role-based permissions, including access to Setup menu, Network operation, PTZ function, Playback, Utility, Backup, Password expiry date and Mask on specific channels while playing back. Note:4CH DVR will display 4 channels and 8CH DVR will display 8 channels.
  • Page 29: 4-6.1 Networking Setup

    4-6.1 NETWORKING SETUP The DVR supports DHCP, LAN and ADSL accesses for network connection. If the settings are subsequently changed, pressing “PLAY” button to drive new settings for re-connection is required. 4-6.1.1 DHCP If the DHCP option is used for DVR network connection, an IP address is assigned by the DHCP server automatically.
  • Page 30: 4-6.2 Http Setup

    4-6.2 HTTP Setup Item Description Check to enable HTTP server. Users can remotely access into the Enable HTTP DVR over the network if the HTTP function is activated. Server Port Enter a valid port value from 1 up to 65000. The default value is 80. 4-6.3 DDNS Setup Item Description...
  • Page 31: 4-6.4 Mail Setup

    4-6.4 Mail Setup E-mail can be used as a form of notification when an event occurs (VLOSS, MOTION, SENSOR). Item Description Enable E-mail Check the box to enable/disable E-mal Notification function. Notification SMTP Server Enter to set up SMTP Serve name. User Name Enter to set up User Name.
  • Page 32: Ptz & Rs485 Setup

    Icon Description Enable MSN Notification Check/Uncheck to enable/disable MSN notification. MSN Account MSN account to be logged in. Password account password to log into MSN. MSN Receiver MSN account to receive event notification messages. 4-7 PTZ & RS485 SETUP The DVR allows users to control PTZ functions of your camera. To enable PTZ function, the 485 cable should be connected to the RS-485 port of DVR.
  • Page 33: System Setup

    4-8 SYSTEM SETUP Item Description DVR Name The name of DVR will be shown when users login from remote access. DVR Location The location of DVR will be shown when users login from remote access Click or press ▼ to select OSD language from English, Traditional Language Chinese, Greek, Italian, Japanese, Portuguese, Spanish, German, French, simplified Chinese, Russian or Polish.
  • Page 34: 4-8.1 Display Setup

    4-8.1 DISPLAY SETUP Item Description Turn On / Off OSD display DVR Status Turn On / Off DVR illustration and record status display Turn On / Off date and time display Date/Time Message Turn On / Off message display Channel Name Turn On / Off channel name display Set up the color of border in LIVE , PLAYBACK mode.
  • Page 35: 4-8.2.1 Change Date & Time

    4-8.2.1 CHANGE DATE & TIME Users are allowed to setup date and time of DVR manually according to your local time. 4-8.2.2 TIME ZONE SETUP In time zone setup, users can change your time zone and activate Daylight Saving Time function according to your DVR location.
  • Page 36: 4-8.2.3 Internet Time Setup

    4-8.2.3 INTERNET TIME SETUP Synchronize your DVR time with internet time server. Item Description Check to enable DVR automatic synchronization function. Automatic Effective by this option selected, DVR will automatically Synchronization synchronize the time upon rebooting or by every 24 hours after booting.
  • Page 37: 4-8.4 Spot Setup

    4-8.4 SPOT SETUP The DVR has two modes of video output; one is main video output, the other is spot video output. SPOT setup is for controlling the order of channels the system cycles through in SPOT mode. User can monitor every channel in the SPOT mode. Item Description Channels display in spot for three different modes:...
  • Page 38: Utility Setup

    4-9 UTILITY SETUP Item Description Select to enter hard disk initialization menu. Please stop HDD Initialization recording before entering this menu. Enter the menu, system will show all the data (model ,volume ) of HDD that installed in DVR. Check the HDD you’d like to initialize then press “Start”.
  • Page 39: Diagnostic

    4-10 DIAGNOSTIC Item Description Version The current firmware version of DVR The connected IP address of DVR. If disconnected from IP Address network, the screen will display” NETWORK DISCONNECT”. MAC Address MAC Address of DVR The capacity of HDD HDD Volume HDD Used Rate Percentage of space used on HDD.
  • Page 40: Chapter 5 Backup & Search

    CHAPTER 5 BACKUP & SEARCH 5-1 BACKUP SETUP User can backup any segment of recorded data in a specified time frame. To do so, either a CD R/W or storage device, like USB, must be connected to the DVR. Recorded data can also backup into NB/PC through our remote access software: 「DVRemoteDesktop.exe」...
  • Page 41: Search Setup

    5-2 SEARCH SETUP Item Description Event Search Press to enter event search menu Time Search Press to enter time search menu 5-2.1 EVENT SEARCH The DVR automatically records events with type, time and channel information included. If there is recording data for an event, a yellow signal will be shown on the left side of time information.
  • Page 42: 5-2.1.1 Criteria Setup For Event Search

    Item Description Setup conditions of event search Criteria Page Switch between pages of events Date/Time Date/time when event occurred. Event type, defined as following VLOSS Video Loss MOTION Motion Detected SENSOR Sensor Detected REMOTEIN user log-in over the network Event Type REMOTEOUT user log-out over the network POWER ON...
  • Page 43: 5-2.2 Time Search

    5-2.2 TIME SEARCH TIME SEARCH can search for the specific time of recording data to playback. To specify a date, to move the cursor up and down, use or roll the mouse to change dates. Press “Enter” or left click on the desired date to playback. Note that dates with recording □...
  • Page 44: Chapter 6 Network Surveillance

    CHAPTER 6 NETWORK SURVEILLANCE AP software:「DVR Remote Desktop」can allow you to remotely access and control the DVR from PC. 6-1 AP Software Installation and Setup Step One:Enter the IP address of DVR in IE browser Step Two: Windows as below will show up. Please enter the user name and password. Default user name and password is admin/123456.
  • Page 45 Step Four: Run or Save our AP software. Step Five: If you choose to run the software, Start window will be shown up. Please enter information of login DVR: IP, Port, Username and Password, or choose “Play Recorded File” to open backup files in your PC. Step Six: You’ve logged into the DVR 2009.3.25 V1.12...
  • Page 46: Ap Software Operation

    6-2 AP Software Operation Open the file “DVRemoteDesktop.exe”; enter the information of DVR “IP address”, “Port” “Username” and “Password” and click “OK”. You should be able to login DVR successfully and start to use the software. The default username and password is 「admin/ 123456」 “DVRemoteDesktop.exe”...
  • Page 47 Table 6-2.3 Network Bandwidth Requirement Reference Quality Highest Normal Lowest Resolution 16CH 6.9~7.9Mfps 3.7~5.8Mfps 1.2~2.4Mfps 6.5~8.2Mfps 3.6~5.8Mfps 1~2.6Mfps 6.6~8Mfps 3.8~6Mfps 1.4~3Mfps 6.2~7.6Mfps 3.6~5.7Mfps 1.2~2.5Mfps 16CH 3.6~5.4Mfps 1.9~3.5Mfps 890K~1.7Mfps 3.3~5.6Mfps 1.8~3.7Mfps 900K~1.6Mfps 3.4~5.1Mfps 1.8~3.8Mfps 850K~1.8Mfps 3.7~6Mfps 1.6~4Mfps 870K~1.8Mfps 16CH 1.8~3Mfps 1.2~2.2Mfps 860~1.3Mfps 1.9~2.9Mfps 1.2~2.5Mfps...
  • Page 48: Chapter 7 Specificaitons

    CHAPTER 7 SPECIFICAITONS 1. VIDEO Input Level 1.0 Vp-p±10% Composite, 75Ω Balanced NTSC 480 fps(16CH), 240fps(8CH), 120fps(4CH) Display Speed 400 fps(16CH), 200fps(8CH) , 100fps(4CH) NTSC 720(H) X 480(V) Display Resolution 720(H) X 576(V) Monitor Output 2Vp-p Composite, 75Ω Balanced 2. RECORDING Compression Method H.264 Recording Speed...
  • Page 49 7. ENVIRONMENTAL 5℃ ~ + 40℃ Operation Temperature Humidity Less than 90% 8. PHYSICAL Dimension 430(W) x 293(D) x 55(H) mm Weight 2.5kg (3.5kg including 1 HDD and CD-RW) 9. BACKUP USB Stick Video Data, Audio ±RW BACKUP Video Data, Audio CD-RW/DVD Network Video Data, Audio...
  • Page 50: Chapter 8 Mobile Application Installation And Usage

    CHAPTER 8 MOBILE APPLICATION INSTALLATION AND USAGE You can remotely monitor all channels of DVR through your mobile device. The required mobile application is from DVR manufacturer and it supports mobile OS for both Windows mobile 5.0 above and Symbian. Please confirm network function of DVR has been activated before mobile connection: Main menu Network Setup...
  • Page 51: 8-1.2 Mobile Application Operation

    8-1.2 Mobile Application Operation After the installation, enter the Program Files menu in your mobile device to run a file called “DVRH264”. Select “Menu” at the right lower corner of your mobile screen, 4 commands, Login Add Modify and Delete, will show up.
  • Page 52: 8-1.2.3 Modify The Login Information Of Dvr

    8-1.2.3 Modify the Login Information of DVR You can use the “Modify” command to change the login information of DVR. The dialogue is identical to that of the “Add” command. 8-1.2.4 Delete the Login Information of DVR “Delete” command can be used to remove the DVR information if it is no longer useful. Select the DVR on the name list then choose “Delete”...
  • Page 53: 8-1.3.1 Scroll The Image

    8-1.3.1 Scroll the Image You can use the keypad on your mobile device to scroll the image if it’s oversized. Action Scroll Up Scroll Left Scroll Right Scroll Down 8-1.3.2 Image Quality Setup Select “Quality” under the “Menu” There will be 5 levels for your to choose: Low、 Normal、Middle、High and Highest.
  • Page 54: 8-1.3.4 Size Of Image

    8-1.3.4 Size of Image The screen size of different mobile device can be different. You can select “Size” under the “Menu” to choose from “Original” or “Fit Screen” to resize the display image. Item Description Original The image will be shown in original size.
  • Page 55: Mobile Application Installation And Operation For Windows Mobile System

    8-2 Mobile Application Installation and Operation for Windows Mobile System There are two kinds of applications for Window Mobile OS: JPEG compression and H.264 compression. The one for H.264 compression can transfer both audio and video signal to your mobile device. System Requirement: Mobile device OS:Windows mobile system 5.0 above.
  • Page 56: 8-2.2 Mobile Application Operation

    8-2.2 Mobile Application Operation After the installation, enter the Program Files menu in your mobile device to run files named “Jrviewer” and “H264Pocket”. This application allows you to remotely logon and monitor DVR. Press “OK” to bring up the operation menu, see below chart to further information. Item Function Description...
  • Page 57: 8-2.3 Operation Under The Live Monitoring

    8-2.3 Operation under the LIVE monitoring. After successful logon the DVR, press “View” to bring up operation menu. You can choose the channel, resize the image, choose the quality, and turn on/off the status bar, alarm, full screen display….etc 8-2.3.1 Operation uner the LIVE monitoring for Jrviewer Item Function Description...
  • Page 58: 8-2.3.2 Operation Under The Live Monitoring For H264 Pocket

    8-2.3.2 Operation under the LIVE monitoring for H264 Pocket Item Function Description Choose from CH1~16 to display. CH1~4 can Channel 1~16 Display for CH 1~16 receive audio signal. Graphical icons indicated below will be shown on the status bar if there is event such as motion detected, sensor triggered and video loss to be detected on any channel.
  • Page 59: Chapter 9 Cms Installation And Usage Guide

    CHAPTER 9 CMS INSTALLATION AND USAGE GUIDE 9-1 CMS Installation System Requirement: Intel Pentium 4 processor or equivalent. * Microsoft Windows Vista、Windows XP、Windows 2003 Server. * Besides OS and other required APs, there will be 512MB remaining memory needed or above. *...
  • Page 60 5.”Confirm Installation” window shows. Select ‘Next’ then the installation starts. 6. Select ‘Close’ to finish installation when the “Installation Complete” window shows. 2009.3.25 V1.12...
  • Page 61: Cms Login And Environment

    9-2 CMS LOGIN AND ENVIRONMENT To enter CMS, the administrator’s user name and password are required. The defaults are ‘admin’ and ‘123456’. After successful login, the following image shows on your screen: ③ ① ② ④ ⑤ ① DVRs, Groups & Information about DVRs, groups and events.
  • Page 62: Dvrs, Groups & Events

    9-3 DVRs, Groups & Events Icon Description View list of logged in DVR/ Group. View Logs: list all the event information of DVR / 9-3.1 View DVR Group List Single left click on ‘DVR’ or ‘Group’ will expand/collapse the entire DVRs and groups list.
  • Page 63: 9-3.2 View Event Logs

    9-3.2 View Event Logs Under this page, all the events of a DVR can be expanded/collapsed in the order of Re mote in/Remote out, Video Loss, Motion, Sensor, Others (Power Reset, Key Lock, Key Unlock, HD Full). 9-4 Local PC Information and Control Located at the left lower corner of the screen, please see the chart below: Icon Function...
  • Page 64: Main Display

    9-5 Main Display The main display area is where the live image of DVR is shown. You can drag to change the location of screen for each channel and turn on/off audio signal with mouse-click. 9-5.1 Audio Control In live mode, you can turn on/off the audio signal of Ch1~Ch4: 「...
  • Page 65: 9-5.2 Emap Display

    9-5.2 eMAP Display In Live mode, pressing will bring the e-MAP drag-down menu. If the channel has been set up to use e-MAP, the menu will show all the e-MAP titles that have been entitled to this channel; otherwise, “No eMaps” will be shown. Please check “9-6.4 eMAP administration”...
  • Page 66: Operation Bar

    9-6 Operation Bar 10 Operations to be listed as below: Table 9-6.1 description of 10 operations: Icon Description User Administration. Please see “9-6.1 User administration” DVR Administration. Please see “9-6.2 DVR Administration” Group Administration. Please see “9-6.3 Group Administration” eMap Administration. Please see “9-6.4 eMap Administration”. Remote Playback.
  • Page 67: 9-6.1 User Administration

    9-6.1 User administration Before the CMS can be used on a PC, user accounts should be added with proper authority. Each user should also be assigned a password and optionally a description. If a user does not have certain authority assigned, he/she will not be able to operate the corresponding function on the Operation Bar.
  • Page 68: 9-6.3 Group Administration

    9-6.3 Group Administration A ‘Group’ means a set of video channels from one or many DVRs, which means, user can organize channels from different DVRs to be set in a group. This function allows you to monitor and manager channels from multiple DVRs easily and flexible. Steps: 1.
  • Page 69: 9-6.4 Emap Administration

    9-6.4 eMap Administration If geographical locations are relevant, or if it is desired to use a picture as the background, eMap can be used for the purpose. With eMap, the background picture can be picked by the user and channels from multiple DVRs can be placed and dragged around on the picture. Steps to follow: 1.
  • Page 70: 9-6.5 Remote Play

    9-6.5 Remote Play Video images recorded on a DVR can be displayed on a remote CMS. With Remote Play function, select a DVR and a display mode on top of the screen. After the recorded segments are listed below, double click on one to show its image on the right. Icon Description Start playing.
  • Page 71: 9-6.6 Hdd Playback

    9-6.6 HDD Playback You can directly play the recording data in the HDD that’s uninstalled from DVR by CMS. See the picture below, the left part of screen is recording data in list that’s separated by hour and the right part is main display. You can change the display modes and play files fast forward or rewind.
  • Page 72: 9-6.8 Event Playback

    9-6.8 Event Playback Event recordings on the DVR can be played back in CMS. Steps to follow: 1. Select a DVR and a display mode. 2. Select a date. 3. Double click an event and play back the images on the right. Use buttons at the bottom to control the playback.
  • Page 73: 9-6.10 Recording Data

    9-6.10 Recording Data It can play all the recording files you’ve recorded in line in “Recording Data”. You can play or delete them here. Steps: 1.Choose the recording time at upper left corner, it will be played on the main display. 2.You can choose the display mode.
  • Page 74: Appendix I I-Dvr.nrt Registration

    APPENDIX I I-DVR.NRT REGISTRATION In the package of each DVR, you will find a sticker shows account information including username and password that allows users to login I-DVR.NET for registration. To register DDNS on I-DVR.NET, please follow the steps as shown. Step 1.
  • Page 75: Appendix Ii Db 26 Definition (For 16Ch Dvr Only)

    APPENDIX II DB 26 Definition (For 16CH DVR only) First pin Read Line NUM. WIRE COLOR NUM. WIRE COLOR BLUE SENSOR 4 ORANGE GREEN SENSOR 5 RS 485_B YELLOW SENSOR 6 BROWN RLY1_NO ORANGE SENSOR 7 BLACK RS485_A SENSOR 8 WHITE RLY1_COM BROWN...
  • Page 76: Appendix Iii Record Mode Comparison

    APPENDIX III Record Mode Comparison Comparison between different setups while in Default Record mode and after it’s been s witched. Schedule Record-Motion Schedule Record-Sensor Default Record After Switch Record Mode Mode Default Record Record and EventR Enable Enable Activated ecord have both been activated Default Record Stop Record...
