INSTALLATION AND OPERATING INSTRUCTIONS
This wall thermostat provides an user-friendly, safe, and reliable device to control the operation of gas appliances.
Always check the appliance home owner's manual for additional information, or warnings regarding accessory
installation before connecting to this thermostat.
Carefully inspect the contents for shipping damage. If any parts are missing or damaged, immediately contact the
dealer from whom you purchased the kit. Do not attempt to install any part of the kit unless all parts are in good
condition. Please keep this booklet for future reference.
Wall Thermostat
Battery Alkaline AAA
Wall Anchor Screws
Wall Anchor
Installation Instructions
25 Feet Wire
_" Female Spade Terminal
Fork Terminal
•
Contemporary Ergonomic Wall Mount with LCD Display and back light
•
Low battery Indication
•
•
Read this manual thoroughly prior to installing, programming or operating the wall thermostat.
•
Do not use this wall thermostat with voltages above 24 Volts DC and 1 amp current. This wall thermostat
is a DC dry contact system that will turn gas appliances on or off.
•
Wiring must conform to appliance requirement and building codes/ordinances as required by local and
national code authorities having jurisdiction.
•
This wall thermostat should only be used as described in this manual. Any other use is not recommended
and will void the warranty.
Due to the sensitive temperature monitoring components in the wall thermostat, it is
necessary to allow the wall thermostat to stabilize to room temperature before accurate room
temperatures are displayed. If the wall thermostat is activated from a severe cold condition,
allow 15 minutes for accurate temperature readings to appear on the LCD.
Turn appliance OFF and allow to cool before installing or servicing. DO NOT connect
110-120 VAC wiring directly to the wall thermostat. Read all instructions completely before
attempting installation. Follow instructions carefully during installation. Any modification of
components will void the warranty and may cause a fire hazard.
50D0090 Rev 1
WT
Wall Thermostat
CONTENTS OF KIT
Description
FEATURES/SPECIFICATIONS
WARNING
Important Safety Information
Page 1 of 5
Qty
1
2
2
2
1
1
2
2
Ambient Technologies
A Division Of MHS
Advertisement
Table of Contents
Summary of Contents for Ambient WT
- Page 1 110-120 VAC wiring directly to the wall thermostat. Read all instructions completely before attempting installation. Follow instructions carefully during installation. Any modification of components will void the warranty and may cause a fire hazard. 50D0090 Rev 1 Page 1 of 5 Ambient Technologies A Division Of MHS...
- Page 2 Make sure that the wires do not contact the appliances any place other than at the terminals. Exposure to temperatures higher than 105C (250ºF) may cause the wall thermostat to malfunction or fire hazard. 50D0090 Rev 1 Page 2 of 5 Ambient Technologies A Division Of MHS...
- Page 3 In clock setting mode, only clock and degree is displayed. Press _ to advance item (hour, minute or degree). Selected item is flashing. Press _ to select. 50D0090 Rev 1 Page 3 of 5 Ambient Technologies A Division Of MHS...
- Page 4 Fahrenheit, the LCD will display “HI” and the wall thermostat will turn off the appliance. Wall thermostat will not function until the room temperature has dropped below 99 degree Fahrenheit. 50D0090 Rev 1 Page 4 of 5 Ambient Technologies A Division Of MHS...
-
Page 5: Troubleshooting
Answers to any questions regarding our limited warranty may be obtained by writing our corporate offices. Ambient Technologies warrants each new Ambient Technologies wall thermostat against any defects that are due to faulty material or workmanship to the original owner, for a period of five years after the original date of purchase.
