Page 1: User Manual
BlueAir User manual Set up and use instructions for BlueAir adapter BA-01... - Page 3 Introduction Thank you for purchasing a BlueAir Bluetooth audio adapter The BlueAir Bluetooth audio adaptor opens a whole new world of freedom and sponteneity for leisure and informal public performances. Equipped with your BlueAir audio adapter, you can turn almost any musical or speaking oppor- tunity into a performance.
- Page 4 Mention of third party products is for infor- mation purposes only and represents neither an endorsement nor a recom- mendation. Exploraudio assumes no responsibility in respect of the per- formance or use of these products. Exploraudio is an Explora ltd company.
-
Page 5: Table Of Contents
Contents This manual contains basic instructions for setting up and using the BlueAir Bluetooth audio adaptor and suggestions for where and how it may be used but the places you can take it and reasons you might use it are lim- ited only by your imagination. - Page 6 BlueAir Adaptor, showing the function button,inducator lights and charger socket used in its operation. Complete wireless freedom and the ultimate in ‘go anywhere’ convenience make the BlueAir adaptor the perfect pocket companion for impromptu amplification. With BlueAir, your own (or someone else’s) Bluetooth headset and almost any audio system that may be to hand, you have instant live amplification.
-
Page 7: Before You Start
Before you start The BlueAir BA-01 Bluetooth audio adaptor pack- age contians the following: BlueAir Bluetooth audio adaptor Mains power adaptor Selection of connector adaptors BlueAir Adaptor Power supply Connector adaptors (Descriptions on next page) - Page 8 2 x 3.5mm stereo jack to mono RCA socket 3.5mm stereo jack to dual (split stereo) RCA socket 3.5mm stereo socket to dual (split stereo) RCA jack 3.5mm stereo socket to dual (split stereo) RCA jack (lead) 2 x single mono RCA socket to dual mono RCA socket 2 x single mono RCA jack to dual mono RCA socket...
- Page 9 Remove all components from the box and using the diagram and con- tents list on pages 5 and 6, check that they are all correct Powering the BA-01: Plug the power adaptor into the mains electricity supply (100V - 240V) and insert its small power connector jack into the socket on the BA-1 (it is the only socket on the unit).
-
Page 11: Connecting To Headsets (Pairing)
Connecting to headsets (pairing) Connecting the BlueAir adaptor to Bluetooth headsets is very simple but before you begin you will need to know your headset manufacturer’s in- structions for switching the headset to “pairing mode”. As with any device used with Bluetooth headsets, to start using the BlueAir adapter it must first be connected to the headset of your choice using the process known as “pairing”. - Page 13 The H-clamp is available for purchase either alone or as part of packages including a mutli- purpose shockmount. For details, visit explorau- dio.com or write to Sales at ExplorAudio (see page 2 for address). The H-clamp is often the best way to combine...
-
Page 15: Connecting To Audio Equipment
Connecting to audio equipment The audio input and output levels of the BlueAir Adaptor are broadly com- patible with standard audio inputs and outputs of both professional and domestic audio systems and computer equipment. The adapter can be con- nected to the ‘line’ or microphone inputs and ‘line’ or headphone outputs of almost all audio equipment and should work well with everything from PA (public address), instrument and HiFi equipment to professional mixers / pre-amps, televisions, portable audio systems and computers. - Page 16 Professional stage / public address equipment Use the connection adaptors shown to the right. Connect a BlueAir adaptor jack to the socket end and plug the other end into the socket of the sound equipment. To use a Bluetooth headset as a wireless micro- phone, plug the BlueAir adaptor’s output jack (black ring) into the connection adaptor and then plug the connection adaptor’s jack into one...
- Page 17 Computer sound card Use the connection adaptors shown to the right. Connect a BlueAir adaptor jack to the socket end and plug the other end into the relevant audio socket of the computer. The BlueAir adaptor’s output jack (black ring) must be connected to the computer’s audio input (for external micro- phones) socket and the input jack (red ring) to the computer’s audio output (for external speak-...
- Page 18 NOTE: The maximum range (between headset and adpator) of the BlueAir adaptor is 10m. The BlueAir adaptor is for mono audio transmission only and will not pair with Bluetooth enabled stereo headphones. The connection adaptors pro- vided can however be used to combine stereo channels for transmission by the BlueAir adaptor as mono audio signals.
-
Page 19: Using Your Blueair Adaptor
Using your BlueAir adaptor The primary purpose of the BlueAir adapter is to allow standard Bluetooth headsets to be used as wireless microphones but it can also be used for wireless audio monitoring. As it can do both simultaneously, it is excellent for using Bluetooth headsets with computers for VOIP (Voice Over IP) te- lephony. - Page 20 For good results when using the BlueAir adaptor to amplify acoustic in- struments such as guitars, cellos and double basses, the best method for mounting the Bluetooth headset is to attach it to the ExplorAudio H-clamp as shown on page 10. Equally good sound can be achieved by attaching the headset to a conventional stand but your freedom of movement is then restricted considerably.
- Page 21 Computer audio The BlueAir adaptor can be connected to the standard audio ports of com- puters to allow both oudio in and out to be sent to/from a Bluetooth head- set. This is particularly useful for internet telephony using services such as Skype.
-
Page 22: Troubleshooting
Troubleshooting PROBLEM SOLUTION The link to a Blue- Press the headset’s call button (to deactivate the tooth headset is active link) and then press it again to re-activate it. If (the BlueAir adap- this doesn’t work, re-pair with the headset and: tor’s green LED is on 1. - Page 23 Any other problem Check our web site (www.exploraudio.com) for any additional advice or contact us directly: E-mail enquiries@explorudio.com +44 (0)1934 713763 Letter Technical Support ExplorAudio PO Box 4473 Bristol BS28 4WE...
- Page 24 BAUM-001-12...
