Owners Manual
WATER & POOL&FLOOR HEATERS
Including Installation Instructions and Warranty Information
HEAT PUMP POOL&FLOOR & WATER HEATERS
Document Number : QDC0046PD-6
OWNER'S MANUAL
To Suit 2.7kW
MODELS
27ACP-407
27ACP2-22
27ACP2-407
27ACW-417
27ACW-417B
Document Number: QDC0046PD-6
Date of Revision: July 2009
Quantum Energy Technologies
Page 1 of 20
Advertisement
Table of Contents
Summary of Contents for Quantum 27ACP-407
- Page 1 Quantum Energy Technologies Owners Manual WATER & POOL&FLOOR HEATERS OWNER’S MANUAL Including Installation Instructions and Warranty Information To Suit 2.7kW HEAT PUMP POOL&FLOOR & WATER HEATERS MODELS 27ACP-407 27ACP2-22 27ACP2-407 27ACW-417 27ACW-417B Document Number: QDC0046PD-6 Date of Revision: July 2009...
-
Page 2: Table Of Contents
2a: One Of The Worlds Most Energy Efficient Methods Of Water Heating.......5 2b: Application Note For Pool Heaters - Heat Loss..............5 Section 3: HEAT PUMP OPERATION..................6 3a: Quantum Heat Pump Pool / Building Heater.................6 3b: Principle Of Operation......................6 3c: Digital Controller........................7 3c.1: Description........................7... - Page 3 Quantum Energy Technologies Owners Manual 4b.7: Cabinet Clearances......................10 4b.8: Electrical Connection.....................15 4b.9: High & Low Pressure Switch Cut Out Settings.............15 4c: Commissioning........................15 4c.1: Temperature Rise Across Heat Exchanger..............15 Section 5: MAINTENANCE AND SERVICE INFORMATION..........16 5a: Air Evaporator Coils......................16 5b: Special Note On Heat Exchanger..................16 5c: Table Of Parameters......................17...
-
Page 4: Section1:Appliance Details
Quantum Energy Technologies Owners Manual Section 1: APPLIANCE DETAILS For future convenience, please fill in the following details and retain with your original invoice. 1a: Owner’s Details Surname : …………………………………… Given Name(s) : ….………………………..Address : ……………………………………………………………………………...………… Town/Suburb : ……………………………………………………………………..……………... -
Page 5: Section 2: Introduction
In the Quantum Pool or Floor or Water Heater, the cold side of the refrigeration circuit is an air conditioning coil. This coil absorbs the heat from the air that is forced through it by means of the fan. -
Page 6: Section 3: Heat Pump Operation
The system uses the commonly available R22 or R407C or R417A refrigerant. The 2.7kW Quantum pool heater is designed for domestic use but can also be used on smaller commercial applications. The Quantum heating system produces an operating sound of a similar type and level to the outdoor unit of an air conditioner. -
Page 7: Acp2
Quantum Energy Technologies Owners Manual 3c: Digital Controller 3c.1: Description The sophisticated Digital Controller (thermostat) provides temperature readout and set point temperature adjustment. It also monitors compressor operation, controls the de-icing system and indicates the operational status of the heater. -
Page 8: 3C.5: Up Button
Quantum Energy Technologies Owners Manual 3c.5: Up Button a) This key is used to raise a setting after selecting the required programming mode as in section 3c.4. b) When the display is in normal mode, press 3 times to display Axx (the compressor temperature). -
Page 9: Section 4: Installation Details
4b.2: Plumbing Work To The Unit The actual plumbing of the hydraulic circuit to the heater does not form part of Quantum’s supply and is the owner’s responsibility. For pool heating, a fully qualified pool plumber or pool installation company should be engaged to do this part of the work. For floor heaters a qualified plumber, familiar with hydronic type building heating, will be required. -
Page 10: 4B.6: Chemical Balance
5 p.p.m. Salt Chlorinators on indoor or covered swimming pools or spa pools can easily produce excessive chlorine levels, which will damage the heater internals. 4b.7: Cabinet Clearances Note: Quantum recommends allowing the following clearances around the Heat Exchanger Cabinet: - MODEL... -
Page 11: Figure 2: Dimensional Drawing For 2.7Kw Pool & Building Heater
Quantum Energy Technologies Owners Manual Figure 2: Dimensional Drawing for 2.7kW Pool & Floor & Water Heater Do Not Obstruct Air Flow.Allow 300mm clearance Between the air Inlet and any wall or other object. 1700mm clearance Is required in front of the fan to any wall or obstruction. -
Page 12: Figure 3: Hydraulic Connections To Heater
Quantum Energy Technologies Owners Manual Figure 3: Hydraulic Connections To Heater Showing shut-off by-pass valves (Optionally fitted by plumber to isolate the heater) Heated Water To Pool Optional Quantum Heater Unit Shut-off By Pass Cold Water From Pool All Pipes Are 40mm PVC... - Page 13 40mm 40mm From Pool To Pool Size of the water circulation pump & filter is to be selected by the client Quantum does not supply any plumbing – parts or labour LEGEND 3 Way Isolating Valves (Optional) Water Circulation Pump Suggest 0.5 HP...
-
Page 14: Figure 5: Schematic Of Internal By-Pass (Not On Building Heater Version)
Quantum Energy Technologies Owners Manual F a n C o i l E v a p o r a t o r E l e c t r i c a l C o n t r o l C o m p r e s s o r... -
Page 15: 4B.8: Electrical Connection
Quantum Energy Technologies Owners Manual 4b.8: Electrical Connection This heater is designed for single-phase 220/240V AC supply only. A circuit breaker must be installed at the power supply and the electrical connection must comply with Local Supply Authority Regulations and AS3000. It will require an approved, standard 240V 25A On / Off switch in close proximity to the heater. -
Page 16: Section 5: Maintenance And Service Information
Your Quantum heater is a completely sealed refrigeration system, similar to a household refrigerator. The maintenance program to be employed on your Quantum is not much different to that required for the maintenance of a standard electric water heater. However, the Quantum warranty may be void if any of the following conditions are not met or if the refrigeration lines or components are damaged or altered in any unauthorised way. -
Page 17: 5C: Table Of Parameters
Quantum Energy Technologies Owners Manual Figure 7: Wiring Diagram R U N D e-ice D O W N S E T S en so rs W ater S T 1 Q U A N T U M R E L A Y... -
Page 18: Heater
The date and time of the commencement of such warranty work will be at the discretion of the Company. Quantum does not warrant that such repair work will take place within any particular period. A call out fee applies to any warranty calls made outside normal QUANTUM business hours. -
Page 19: 6B: Items Not Covered By Warranty
Quantum Energy Technologies Owners Manual 6b: Items Not Covered By Warranty Service calls due to: • Dirty Filters. • Blown Fuses • Incorrect Operation. • Tripped Circuit Breakers. • Main Isolator Switched Off. • Blocked Drains (such as from the Evaporator etc). - Page 20 NOTE: While every care has been taken to ensure the accuracy in preparing this publication, No liability can be accepted for any consequences, which may arise as a result of its application. Quantum: Hot Water From Thin Air! Page 20 of 20...
