  • Page 1 03002 GTH26K54 Owner's Manual / 96043003101...
  • Page 2 TRACTOR - MODEL NO. GTH26K54 (96043003101), PRODUCT NO. 960 43 00-31 SCHEMATIC 02929-194276_Regulated-Tex BATTERY SOLENOID STARTER FUSE BLACK ELECTRIC CLUTCH WHITE BLACK WHITE WHITE GRAY CLUTCH/BRAKE (PEDAL UP) BLACK REVERSE SWITCH PTO SWITCH (NOT IN REVERSE) (DISENGAGED) BLACK BLACK BLACK...
  • Page 3 TRACTOR - MODEL NO. GTH26K54 (96043003101), PRODUCT NO. 960 43 00-31 ELECTRICAL...
  • Page 4 TRACTOR - MODEL NO. GTH26K54 (96043003101), PRODUCT NO. 960 43 00-31 ELECTRICAL KEY PART DESCRIPTION 532 14 49-27 Battery 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4 532 18 64-91 Battery Box 532 17 61-38 Switch Interlock 532 18 37-59...
  • Page 5 TRACTOR - MODEL NO. GTH26K54 (96043003101), PRODUCT NO. 960 43 00-31 CHASSIS chassis-tex_62-gt-husq...
  • Page 6 TRACTOR - MODEL NO. GTH26K54 (96043003101), PRODUCT NO. 960 43 00-31 CHASSIS KEY PART KEY PART DESCRIPTION DESCRIPTION 532 40 50-12 Logo 873 90 05-00 Nut Lock Hex Flange 5/16-18 532 40 87-01 Dash 532 40 35-71 Plug Cruise/Phone 532 41 10-46...
  • Page 7 TRACTOR - MODEL NO. GTH26K54 (96043003101), PRODUCT NO. 960 43 00-31 DRIVE 142 158 drive-tex_32-HG_3000...
  • Page 8 TRACTOR - MODEL NO. GTH26K54 (96043003101), PRODUCT NO. 960 43 00-31 DRIVE PART PART DESCRIPTION DESCRIPTION 143 817 49 05-08 Screw Thdrol 5/16-18 x 1/2 - - - - - - Transaxle, Hydro 344-3000 145 532 16 31-68 Washer Axle flange...
  • Page 9 TRACTOR - MODEL NO. GTH26K54 (96043003101), PRODUCT NO. 960 43 00-31 ENGINE 21 20 SPARK ARRESTER KIT engine-tex_31-kohl KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION - - - - - - - - - Engine Kohl Model No. SV735...

  • Page 10: Steering Assembly

    TRACTOR - MODEL NO. GTH26K54 (96043003101), PRODUCT NO. 960 43 00-31 STEERING ASSEMBLY 53 8 steering-tex_4-husq PART PART DESCRIPTION DESCRIPTION 532 19 39-43 Wheel, Steering 873 94 08-00 Nut Hex Jam Toplock 1/2-20 unf 532 19 59-68 Axle Asm., Front...

  • Page 11: Seat Assembly

    TRACTOR - MODEL NO. GTH26K54 (96043003101), PRODUCT NO. 960 43 00-31 SEAT ASSEMBLY seat-tex_5-husq PART PART DESCRIPTION DESCRIPTION 532 40 66-21 Seat 873 80 05-00 Nut, Lock 5/16-18 unc 532 19 76-61 Handle Slide Seat 532 18 01-66 Bracket Pivot Fender...

  • Page 12: Wheels And Tires

    TRACTOR - MODEL NO. GTH26K54 (96043003101), PRODUCT NO. 960 43 00-31 DECALS PART PART DESCRIPTION DESCRIPTION 532 18 09-41 Decal, Cust. Resp. 532 19 91-14 Decal, Operator's 532 40 21-28 Decal, Hood Insert 532 40 28-32 Decal, Hood Logo 532 40 84-67 Decal, Replacement...

  • Page 13: Mower Deck

    TRACTOR - MODEL NO. GTH26K54 (96043003101), PRODUCT NO. 960 43 00-31 MOWER DECK 25 26 mower_deck 54-tex_3...
  • Page 14 TRACTOR - MODEL NO. GTH26K54 (96043003101), PRODUCT NO. 960 43 00-31 MOWER DECK PART PART DESCRIPTION DESCRIPTION 532 40 31-25 Deck Weldment Mower 873 90 06-00 Nut, Lock Flg. 3/8-16 unc 532 19 60-66 Cover Mandrel LH 872 11 06-16 Bolt Carriage 3/8-16 x 2 Gr. 5...

  • Page 15: Mower Lift

    TRACTOR - MODEL NO. GTH26K54 (96043003101), PRODUCT NO. 960 43 00-31 MOWER LIFT lift-tex_3 PART PART DESCRIPTION DESCRIPTION 532 19 52-23 Shaft Asm., Lift 532 19 42-08 Pin Cotter 5/16 Bow Tie Lock 532 19 52-30 Lever Asm., Lift Rh...
