Carcomm CMIC-103 Installation Manual

Mobile iPhone Cradle Mobile iPhone Cradle
CMIC-103 Apple iPhone 3G / Apple iPhone 3GS / Apple iPod Touch 2G CMIC-103 Apple iPhone 3G / Apple iPhone 3GS / Apple iPod Touch 2G

Introduction

This installation manual has been prepared to provide the basic information needed to
install this product. This manual is not intended to be definitive, because there are
different models and types of vehicles which will require different installation work.
The information given is for general guidance only.
The terms of warranty demand that this mobile cradle is installed by an experienced
installer. An end-user should never attempt to install this mobile cradle without
professional assistance as the installation requires special tools and knowledge.
Note: Thoroughly read the manual before beginning the installation procedure.

WARNINGS

1. Ensure that the vehicle's battery is disconnected before you start the installation
procedure and that it remains disconnected during the procedure.
2. Do not smoke or use open flames when working near the vehicle's fuel system.
3. Ensure that the vehicle's electrical cables, hydraulic lines, fuel lines and safety
equipment are not damaged during the installation.
4. Ensure that normal control and operation of the vehicle is not obstructed by the
installation,particularly the brakes and steering. Ensure that airbag operation is not
obstructed.
5. Electronic and other sophisticated systems (for example speed control, ABS anti-lock
brake,fuel injection-, navigation- and airbag systems) are relatively immune to
malfunction caused by the iPhone. However, should you experience false
operation of these systems or are in any doubt whatsoever as to their functionality,
please consult the vehicle's dealer.
6. The mobile cradle is suitable for use only in vehicles with a 12V / 24V negative
grounding. Use on other supply voltages or alternative polarity will damage the
equipment.
7. The iPhone should not be left switched on for extended periods without running the
vehicle's engine. Failure to comply could drain the vehicle's battery.
Before starting the installation of the mobile iPhone cradle please check if the following
contents are present :
- Carcomm iPhone® cradle
- Audio-Out cable and 12/24V cigarette lighter plug
- Cable with fuse for a permanent power supply
- Rotating swivel
- Window mount with suction cup
- Surface cleaner
- Screw sets
- Manual
Additional free extras :
- Protective film
© Copyright Carcomm International BV 2007. Subject to change without previous notice. All used brandnames and logos are owned by their respective owners

Compatible devices

Apple iPhone 3G
Apple iPhone 3GS
Apple iPod Touch 2G
Safety-Mount® pattern
www.carcomm.nl www.carcomm.nl 1
