Yamaha RGX 121S Service Manual

This document is printed on chlorine free (ECF) paper with soy ink.

011535

ELECTRIC GUITAR

RGX 121S

SERVICE MANUAL

CONTENTS

....................................................................... 4

............................................... 2

.................................................... 4

.................................................... 5

HAMAMATSU, JAPAN

0.78K-441

Printed in Japan '00.09

Table of Contents

Need help?

Do you have a question about the RGX 121S and is the answer not in the manual?

Page 1 ELECTRIC GUITAR RGX 121S SERVICE MANUAL CONTENTS OVERALL ASSEMBLY ..........2 CIRCUIT DIAGRAM ............ 4 WIRING ............... 4 This document is printed on chlorine free (ECF) paper with soy ink. SPECIFICATIONS ............ 5 011535 HAMAMATSU, JAPAN 0.78K-441 Printed in Japan ’00.09...
Page 2: Overall Assembly
RGX 121S OVERALL ASSEMBLY Bridge Assembly: YS-11 (Black) A01a A seal is attached on the rear of the neck. RGX 121S E07 E08 E10 E11 Jack Installation E20 E21 F01d E27a F01a E27b F08 F09 F10 MASTER VOLUME: 15A 500KΩ...
Page 3 RGX 121S PART NO. DESCRIPTION REMARKS RANK REF NO. OVERALL ASSEMBLY RGX 121S AAX19490 Neck Assembly A01a Seal (QC59460) Body QC296300 Tuning Machine Assembly RM1273 (Black) 1set QC201700 String Guide Black QC370200 Spacer Black EA620080 Round Head Wood Screw 2.1X10 (Black)
Page 4: Circuit Diagram
RGX 121S CIRCUIT DIAGRAM FRONT PICKUP MASTER MASTER TONE VOLUME OUTPUT 05A 250Kohm 15A 500Kohm CENTER PICKUP REAR PICKUP PICKUP SWITCH (2pole 5P Lever Switch) GP21-04 WIRING FRONT PICKUP CENTER PICKUP REAR PICKUP to spring plate FRONT & REAR PICKUPS...
Page 5: Specifications
RGX 121S SPECIFICATIONS STANDARD SPECIFICATIONS Scale Length ......648mm Body-Neck Construction ..Bolt On Length ........975.5mm Width ......... 315.8mm Net Weight ........ 3.4kg COLOR Body SBL ........... Satin Black SLB ........... Sheiby Blue MRB ......... Mist Raspberry MPP ......... Mist Purple Neck SBL ...........
