- Page 1 USB 2.0 VGA Adapter USER MANUAL...
-
Page 2: Table Of Contents
ONTENTS ..........................3 NTRODUCTION ..........................3 EATURES ......................3 YSTEM EQUIREMENTS .......................3 ACKAGE ONTENTS ............................3 2000/XP 2000/XP ................4 EVICE NSTALLATION ON INDOWS EVICE NSTALLATION ON INDOWS ....................4 EVICE RIVER NSTALLATION USB 2.0 VGA A .............5 NSTALLATION OF INGLE DAPTER USB 2.0 VGA A ..........6 NSTALLATION OF ULTIPLE... -
Page 3: Introduction
2.0 VGA Adapter User Manual NTRODUCTION Thank you for purchasing the USB 2.0 VGA Adapter. The USB 2.0 VGA Adapter enables you to connect one or multiple display devices (CRT/LCD monitor, projector) to your desktop or notebook PC. The connected display can act as mirrored or extended desktop of the main display on your PC. -
Page 4: Device Nstallation On Evice Installation On Windows 2000/Xp
USB 2.0 VGA Adapter once it’s connected. Please check your operating system and refer to the appropriate installation procedure to begin installing the device driver. Please make sure the USB 2.0 VGA Adapter is unplugged from your PC or Notebook before executing the setup program. This section illustrates the simple device driver installation procedure for computer running Windows 2000 / XP operating system. -
Page 5: Installation Of Single Usb 2.0 Vga Adapter
2.0 VGA Adapter User Manual Step 4. Connect the external display device (monitor/projector) to the VGA (DB15) connector of USB 2.0 VGA Adapter and switch it on. Step 5. Click “Finish” to exit the Driver Wizard. Then plug the USB 2.0 VGA Adapter into an available USB 2.0 port of your... -
Page 6: Installation Of Multiple Usb 2.0 Vga Adapters
USB 2.0 port of your PC. The driver installation will be proceeding automatically. d. If you wish to install additional USB 2.0 VGA Adapter, please follow the procedure a~ c. e. Otherwise, please select “Yes, I want to restart my computer now.”... -
Page 7: Verifying Device Driver Nstallation River Installation
2.0 VGA Adapter User Manual The following procedure allows you to verify the device driver installation. Please right click “My Computer” → “Properties” → “Hardware” → “Device Manager”. Please double click “Display adapters”, and “Universal Serial Bus controllers”. USB 2.0 VGA A INGLE DAPTER INSTALLATION ON THE COMPUTER... - Page 8 2.0 VGA Adapter User Manual USB 2.0 VGA A ULTIPLE DAPTER INSTALLATION ON THE COMPUTER...
-
Page 9: Device Driver U N - Installation
Select “USB 2.0 VGA Device (Multiple) driver version no.” item. Click “Remove” button. Step 2. Unplug the USB 2.0 VGA Adapter and click “OK” to continue. Step 3. Select “Yes, I want to restart my computer now” and click “Finish”... -
Page 10: Device Nstallation On Evice Installation On Windows Vista
Please check your operating system and refer to the appropriate installation procedure to begin installing the device driver. Please make sure the USB 2.0 VGA Adapter is unplugged from your PC or Notebook before executing the setup program. This section illustrates the simple device driver installation procedure for computer running Windows Vista operating system. - Page 11 Setup is searching for installed features… Step 6. Connect the external display device (monitor/projector) to the VGA (DB15) connector of USB 2.0 VGA Adapter and switch it on. Step 7. Click “Finish” to exit the Driver Wizard. Then, plug the USB 2.0 VGA Adapter into an available USB 2.0 port of your PC or...
-
Page 12: Installation Of Single Usb 2.0 Vga Adapter
Adapter into an available USB 2.0 port of your PC. The driver installation will be proceeding automatically. d. If you wish to install additional USB 2.0 VGA Adapter, please follow the procedure a~ c. e. Otherwise, please select “Yes, I want to restart my computer now.” and click “Finish”... -
Page 13: Verifying Device Driver Nstallation River Installation
2.0 VGA Adapter User Manual The following procedure allows you to verify the device driver installation. Please right click “Computer” → “Properties” → “Device Manager”. Please double click “Display adapters”, and “Universal Serial Bus controllers”. Installed one unit of USB 2.0 VGA Adapter:... - Page 14 2.0 VGA Adapter User Manual...
-
Page 15: Device Driver U N - Installation
→ “Program and Features”. Select “USB 2.0 VGA Device (Multiple) (driver version number)” item. Click “Uninstall” button. Step 2. Unplug the USB 2.0 VGA Adapter and click “OK” to continue. Step 3. Select “Yes, I want to restart my computer now” and click “Finish”... -
Page 16: Function Description
2.0 VGA Adapter User Manual This section describes the main functions provided by the USB 2.0 VGA Adapter. - It can support the LCD or CRT monitor; it can attach the D-SUB interface LCD or CRT monitor and it supports 4 kinds of selections,... -
Page 17: Primary" Mode
The monitor connected to the USB 2.0 VGA Adapter will now act as the primary Windows desktop. Please be advised that some display utility and drivers that shipped with certain AGP and built-in display adapters may prevent this option from working on some systems. -
Page 18: Mirror" Mode
1024x768x32bit, and the secondary monitor’s resolution will be the same. But if the selected resolution setting is not supported by the primary screen, a warn ing dialogue ox will be displayed and the suggested screen resolution will be shown. “OFF” Mode This option disables the USB 2.0 VGA Adapter on the system. -
Page 19: Rotation" Mode
2.0 VGA Adapter User Manual “Rotation” Mode This feature enables setting the orientation of the secondary CRT/LCD monitor. Several options such as “0 degrees”, “90 degrees”, “180 degrees” or “270 degrees” are available under the Extended or Primary mode. -
Page 20: Supported Common Display Resolution
2.0 VGA Adapter User Manual UPPORTED OMMON ISPLAY ESOLUTION Aspect Ratio Resolution 16:10 1920 * 1200 16:9 1920 * 1080 16:10 1680 * 1050 16, 32 16:10 1440 * 900 16 / 32 16, 32 16:10 1280 * 800 16, 32 16, 32 15:9 1280 * 768... -
Page 21: Q&A
This section describes the common Q&A regarding to the installation or operation of the USB 2.0 VGA Adapter. Q: Why can’t I make the USB 2.0 VGA Adapter the primary display? A: Some video cards ship their product with a utility that prevent other video cards from being set as the primary card. -
Page 22: Troubleshooting Tips
2.0 VGA Adapter User Manual The following troubleshooting tips may help if you are experiencing any difficulties using our device. Contact your dealer for additional assistance if needed. - Check to make sure that all connectors are plugged in correctly. - Make sure that the USB port that you are using is USB 2.0. -
Page 23: Regulatory Compliance
Copyright© 2008 Magic Control Technology Corporation. All rights reserved. All trade names are registered trademarks of their respective owners. Features and specifications are subject to change without notice. Product may not be exactly as shown in the diagrams.
