PROFESSIONAL LOUDSPEAKERS
KEY FEATURES
1" (25.8 mm) edgewound aluminium ribbon
●
voice coil
Great power handling: 15 w AES
●
Similar model to the CP 16, with higher
●
sensitivity: 107 dB
Designed for outdoor applications,
●
semi-professional systems and high
fidelity designs.
GENERAL DESCRIPTION
The model CP 12/N is a professional lightweight compression tweeter, featuring an aluminium voice coil-diaphragm
assembly. This device has a smooth response in all its frequency range with an incredibly high sound pressure
(107 dB), as well as a narrow controlled dispersion for long throw applications. This model is well suited for use in two
or three-way compact size enclosures.
The diaphragm assembly is field replaceable without soldering.
FREQUENCY RESPONSE AND DISTORTION CURVES
HORIZONTAL POLAR PATTERN
CP12/N
Compression Tweeter
FREE AIR IMPEDANCE CURVE
CP12/N
Advertisement
Table of Contents
Summary of Contents for beyma CP12/N
- Page 1 CP12/N CP12/N PROFESSIONAL LOUDSPEAKERS Compression Tweeter KEY FEATURES 1" (25.8 mm) edgewound aluminium ribbon ● voice coil Great power handling: 15 w AES ● Similar model to the CP 16, with higher ● sensitivity: 107 dB Designed for outdoor applications, ●...
-
Page 2: Technical Specifications
ú s t i c a b e y m a , s . a . Polígono Industrial Moncada II . C/. Pont Sec, 1c . 46113 MONCADA - Valencia (Spain) . Tel. (34) 96 130 13 75 . Fax (34) 96 130 15 07 . http://www.beyma.com . E-mail: beyma@beyma.com .
