- Page 1 DC-715DX DVD PLAYER DviX/MPEG-4 - MULTI-CARD READER 6 in 1 USB FRONT PANEL DVD/CD PLAYER www.quartek-system.com PLEASE CAREFULLY READ THIS MANUAL BEFORE OPERATING THIS UNIT...
-
Page 2: Table Of Contents
17 – Repeat a specific segment on the disc that you define ……………………… 18 – 3D Surround mode …………………………………………………………………….. 19 – Volume control …………………………………………………………………………….. 3 – P JPEG ………………………………….. HAPTER LAYING DISCS 4 – MPEG-4 ……………………………………………….. HAPTER DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 2/33... - Page 3 – Video setup …………………………………………………………………………….. e – Speaker setup …………………………………………………………………………….. f – Digital setup …………………………………………………………………………….. ………………………………………………… OW TO IDENTIFY ISC WITH …………………………………………………………………. ROUBLE HOOTING …….…………………………………………………………… PECIFICATIONS …………….…………………………………………………… ACCESSORIES …………………………………………………………………. HOW TO CONTACT US DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 3/33...
-
Page 4: Safety Information
17) shock do not perform any servicing other than that contained in the operating instructions unless you are qualified to do HE MANUFACTURER SAVES HIMSELF THE RIGHT TO MODIFY WITHOUT ANY PRELIMINARY OPINION TECHNICAL SPECIFICATIONS OF THE PRODUCT DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 4/33... -
Page 5: Dvd Player User S Manual
12cm 74min CD-DA: Digital Audio 20min HD-CD 12cm 74min HD-CD: Digital Audio MP3/JPEG 12cm 600min Compressed Digital Audio Note: DVD-R, CD-R, CD-RW discs can be played in this DVD player. DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 5/33... -
Page 6: Front And Rear Panel Illustration
5.1 Channels Subwoofer Audio Out Coaxial output YPbPr Component Video Out S-Video output Composite Video Out Optical output 5.1 Channels Surround (left/right) Scart output (optional) Audio Out AC 110-240V 5060Hz DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 6/33... -
Page 7: Remote Controller
EMOTE ONTROLLER DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 7/33... -
Page 8: Battery Installation
– The operating range between the remote controller and the equipment shall be no more than 5 meters (16 feet). When the operating range becomes shorter, replace the batteries with the new ones DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 8/33... -
Page 9: Ystem Onnection
YSTEM ONNECTION YSTEM ONNECTION DO NOT Connect the AC power socket to the wall outlet before the system connection is completed. DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 9/33... -
Page 10: System Connection To Atv Set
DVD Composite broadcast reception mode to one of the audio output to the Mono TV audio input. A/V signals, your TV should have more than one A/V input. DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 10/33... -
Page 11: System Connection To An Amplifier
YSTEM CONNECTION TO AN AMPLIFIER Audio connecting to a stereo Amplifier Digital audio connection to a digital Amplifier DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 11/33... -
Page 12: Chapter 1 - Basic Operation
Stop button at first. After taking out the disc, press Open/Close again to close the tray. If you’re not going to use the DVD player for a long time, be sure to remove the electronic plug. DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 12/33... -
Page 13: B - Title Play
To modify the programmed order, use Arrow buttons to highlight the modifying item and enter the new chapter / ack you want to p ogram direc ly. 6 – Meanwhile the program indicator in the VFD illuminate, and the playing chapter/track also illuminate. DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 13/33... -
Page 14: Chapter 2 - Additional Operation
Fast Forward Playback gets to the beginning of the next track, it resumes normal playback. Press Play button to resume normal playback. During CD, HD-CD, MP3 playback, with the speed FF x2, the player has audio output. DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 14/33... -
Page 15: Multispeed Slow Motion Playback
There are four repeat options: Off, Track repeat, Directory repeat, and Disc Repeat. With each consecutive press of the button, the repeat mode switches. If you press the button five times, repeat mode cycles back to off. DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 15/33... -
Page 16: Using The Display Feature
Note : This fea ure does not work in Program Play mode If PBC is on, it will turn off automatically when search playback s arts. When playing MP3/JPEG discs, search feature does not work. DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 16/33... -
Page 17: Using The Browse / Scan / Index Feature
When playing a dual language VCD movie disc, press the L/R button to select the desired language. DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 17/33... -
Page 18: Changing The Audio Language
For example: ‘Angle icon [*/*] or [Off]’; ¼ indicates that angle one is being displayed, and there are four different angles avalaible. (This feature is disc-dependent. If no additional camera angles are available, INVALID KEY will be displayed.) DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 18/33... -
Page 19: Changing The Tv System
SVCD, VCD or CD disc, you can repeat a specific segment only in one track. When the next track begins, A-B repeat turns off automatically. When playing a DVD disc, you can repeat a specific segment only in one title/chapter. DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 19/33... -
Page 20: 3D Surround Mode
‘EQ:[STANDARD]’ is highlighted, as the ‘EQ:[JAZZ]’ is highlighted, as the graph graph showed below: showed below: ‘EQ:[CLASSIC]’ is highlighted, as the graph ‘EQ:[POP]’ is highlighted, as the graph showed below: showed below: DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 20/33... -
Page 21: Volume Control
2 – Pressing the Vol+ button on the remote allow you to amplify the sound level; 3 – Pressing Vol- will reduce the sound level. Notes: During DVD PCM outpu playback, this feature does not work. DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 21/33... -
Page 22: Chapter 3 - Playing Mp3 And Jpeg Discs
You can also select and play a picture in full screen by press that number on the remote. DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 22/33... -
Page 23: Chapter 4 - Mpeg-4
2 – Due to the limit o authority, DVD player can’t support Xd card 3 – Microdrive and CF card use the same slot, Microdrive’s consume is less than CF card. DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark... -
Page 24: Chapter 6 - The Setup Menu System
P/N, subtitle, F.F, F.R, Vol +/-, PBC, Title, Return, Play, Stop, Resume, Pause/Step, Next, P ev, S.F, S.R, Zoom, Preview, GoTo, Program, Repeat, A-B, Angle, Language, Soundtrack, 3D, Record, Display, Mute, Setup. DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 24/33... -
Page 25: Setup Items Introduction
This feature can protect the screen from damage. On: choose this setting to activate the screen saver Off: choose this setting to cancel the screen saver The default setting is ON. DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 25/33... - Page 26 EFAULT Choose this option to resume all the setup options to default setting. DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 26/33...
-
Page 27: B - Language Setup
Japan, Portuguese, German and Latin. Notes: - If your prefered language isn’t available, the disc’s default language will be played. - The défault language of your DVD player is English DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 27/33... -
Page 28: C - Audio Setup
ETUP Use the up and down arrow buttons to move the scroll and adjust the key. There are 2 MIC settings in the MIC SETUP option: Auto and OFF. When DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 28/33... -
Page 29: D - Video Setup
4 – Video Setup The audio setup options are illustrated bellow: RIGHTNESS Use the up and down arrow buttons to Use the up and down arrow buttons to move the scroll and adjust the hue. move the scroll and adjust the brightness. ATURATION ONTRAST Use the up and down arrow buttons to... -
Page 30: F - Digital Setup
Note: This option will be validated when the DOWNMIX is OFF. DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 30/33... -
Page 31: How To Identify Disc With Hub
‘Generic USB Hub’ item as well as ‘USB Mass Storage Device’ item. which represents PC’s USB port collects USB Hub and USB Mass Storage Class Device. Hereby, you can identify if a uDisk is with Hub or not. DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 31/33... -
Page 32: Trouble Shooting
Check if the batteries of the remote control have been loaded with correct polarities. Replace the batteries of the remote control if without power Type of disc DVD / CD-DA / CD-MP3 / CD-R / CD-RW DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 32/33... -
Page 33: Specifications
OW TO CONTACT US O IN QUARTEK SYSTEM CHOOSE THE COUNTRY WHERE YOU BOUGHT THE PRODUCT AND SEND A EMAIL TO THE DISTRIBUTOR RADEMARK , 33154 BAY HARBOR MIAMI FL QUARTEK SYSTEM DC-715DX - User Manual– English V.2 QUARTEK USA TradeMark 33/33...
