Summary of Contents for Pertech 6100 Series
-
Page 1: Users Guide
6100 Series Scanner USERS GUIDE www.pertechresources.com 220350A -REV 01 July 2010... - Page 2 Pertech Resources Inc. July 2010 220350A...
- Page 3 A shielded (360 degree) USB certified interface cable must be used with this product. The shield must be connected to the frame or earth ground reference at each end of the cable. Use of a cable other than the described here will require that you test this cable with the Pertech scanner and your system for FCC and USB mark certification. Power cord For North America a NRTL Recognized detachable power cord must be used.
-
Page 4: Table Of Contents
LED Indicators ....................7 ID Card Scanning Process .................7 Stamp Installation & Replacement..............8 Preventive Maintenance ................9 Clearing Jams .....................9 Feed Issues ....................9 6100 Scanner Specifications ..............10 Dimensions ....................10 Service & Support ..................11 Warranty Information ................11 Pertech Resources Inc. July 2010 220350A... -
Page 5: Where To Get Additional Information
Preface This manual has been written to help you Install and Operate your Pertech® 6100 Series Scanner. Feel free to contact us if you need further assistance after reading this manual. Please see the Troubleshooting Scanner Problems section of this manual and determine the complete part number of your scanner prior to calling. -
Page 6: Unpacking The Scanner
The maximum distance from the scanner to the host and the power supply is: 6 feet (USB interface). The scanner should be placed in a location that minimizes Electro-Magnetic Interference (EMI), a minimum of 1 foot away from monitors. Pertech Resources Inc. July 2010 220350A... -
Page 7: About The 6100 Scanner
9. Mechanism Feed Sensor 10. LED Indicator 11. Entrance Tray 12. ID Card Diverter 13. Mid-Field Sensor 1. Rear Deck 2. ID Card Exit Path 3. USB Interface 4. Power Connector 5. Power Switch Pertech Resources Inc. July 2010 220350A... -
Page 8: Cables And Connections
The USB cable may be attached or detached when the system is on. When Using the USB interface the Win- dows® Operating System will automatically install the USB port driver. Pertech has available scanner drivers Warning: When Hot Swapping USB cable at www.pertechresources.com. -
Page 9: Power Supply
Power Supply Connector Windows XP, 2000, Vista Drivers 1.Download the 6100 USB driver from the Pertech Website. Unzip the file to a directory of your choosing . Make a note of this location. 2.Next, plug in the 6100 into the host computer’s USB 2.0 bus and power up the unit. -
Page 10: Operating The Scanner
If the second sensor does not activate, as in the case of a inserted form being skewed, the user will need to realign the form with the right side of the scanner Entrance Tray before feeding the form. Pertech Resources Inc. July 2010 220350A... -
Page 11: Led Indicators
Insert form Blink Green Error Note: LED functions can also be defined via control commands. Application developers see the 6100 programing manual for details. Contact your Pertech Representative for the necessary files and documentation. Pertech Resources Inc. July 2010 220350A... -
Page 12: Stamp Installation & Replacement
Stamp Tab Must Be Rotated Clockwise Step 3 is 90º from the back of the stamp slot. 90° For Stamp Installatiion Insert the stamp and rotate clockwise to lock into the mechanism. To Reorder Call 800-800-6614 Pertech Resources Inc. July 2010 220350A... -
Page 13: Preventive Maintenance
It is recommended that this be done on a regular basis, such as once a month. Clean the cabinet as needed to remove finger marks and dust. Use any household cleaner designed for plastics, but test it first on a small, inconspicuous area. Additionally, contact sensors should be cleaned with an approved Pertech Cleaning Wipe. -
Page 14: 6100 Scanner Specifications
Document Speed 10 Inches Per Second OS Compatibility XP/2000 / Vista (Nov 2007) API Interface Pertech Proprietary API. TWAIN 2.1 Diagnostics Command Based Self Test Feature Maintenance General Periodic Cleaning takes less than 2 min and Can be performed by the operator. -
Page 15: Service & Support
Service & Support Pertech provides Technical Support for this product by calling 307-856-4821 between the hours of 8AM to 5PM Monday through Friday MST, or by submitting a Support Inquiry at the Pertech web site. www.pertechresources.com under the service/support section. - Page 16 Web site. www.pertechresources.com Pertech ® Copyright© 2007 Pertech Resources, Inc.. All Rights Reserved. Patents pending. All trademarks or registered trademarks are the property of their respective owners. Printed in U.S.A. Prod- uct specifications are subject to change.
