TP-Link TL-WDN4200 Quick Installation Manual page 2

3
Connect to Network
(
You can skip to Appendix: Connect to Wireless Router by WPS to quickly connect to a network if your Wireless Router or Access Point features WPS or QSS function
After installation, the con guration page will pop up
1
on your desktop.
The icon will appear on your desktop. Double-clicking
on the icon can start the utility.
Appendix: Connect to Wireless Router by WPS
If your wireless Router features the WPS or QSS function you can also set up a wireless connection in this way.
For more con guration methods of WPS, please refer to the User Guide on the Resource CD.
Push the WPS/Reset button for 2~3 seconds on the Router.
1
(Here we use Wireless Router TL-WDR4900 as an example.)
Click Network in the tools section to display a list of available
2
wireless networks. Highlight the target network name (e.g.
TP-LINK_Network1) and then click Connect to build a
connection.
Here we only choose a wireless network with the security
type of WPA/WPA2-Personal as an example to elaborate
the following steps.
If you want to know more about the connection to a
wireless network with the security type of WPA/WPA2-
Enterprise, please refer to the User Guide on the resource
CD included.
Press and hold the WPS button on the adapter for 2~3
2
seconds until Figure 2 appears.
Figure 1
Figure 2
Figure 2
If the network is unsecured, you will directly connect to it.
3
If it is secured (with WPA/WPA2-Personal , there are two ways
to connect to it.
Method One:
Input the password into the Security Key eld and then click
OK to continue.
Method Two:
Without entering a key, push the WPS or QSS button on your
Router as hinted "You can also connect by pushing the button
on the router". Then click OK to continue.
Wait for the connection process to complete.
3
The following screen indicates successful connectivity.
Click OK to nish the WPS connection.
)
.
The following screen indicates successful connectivity.
4
Click Close to enjoy the Internet.
5 To view more information about the network connected,
click Status in the tools section.
