Abocom WB1500H Specification

IEEE802.11b Wireless
PC Card With High Power
The 802.11b Wireless PC Card is a device that lets you
connect your notebook to a wireless local area network
(LAN).
The 802.11b Wireless PC Card features high power which
delivers a ultra strong signal capable of reaching those "hard
to reach" locations.
The 802.11b Wireless PC Card allows you to take full
advantage of your PC's mobility with access to real-time
information and online services anytime and anywhere.
Plus, with the network installation simplicity and flexibility,
you can eliminate the need to pull cable through walls and
ceilings and allow the network to go where wires cannot go.
Exploring WWW and augmenting networks can never be
done more easily.
SPECIFICATION
Standards
Host Interface
Physical
Antenna Connector Type
Power Requirement
Frequency Range
Number of Selectable Channels
Modulation Technique
Security
Spreading
Bit Error rate
Media Access Protocol
Supported OS
EMC Certification
FEATURES
IEEE 802.11b
PC Card Type II slot
Weight: 40g
Dimension: 119 (L) x 53.94(W) x 6.88 (H) mm
Built in the card
Operating Voltage: 5V
TX consumption: 525mA (Max)
RX consumption: 250mA (Max)
Sleep mode: 50mA
2.412GHz ~ 2.4835GHz
USA, Canada: 11 channels
Japan: 14 channels
Direct Sequence Spread Spectrum (CCK, DQPSK, DBPSK)
0/64/128 bit WEP
11 chip Barker sequence
-5
Better than 10
CSMA/CA (Collision Avoidance) with ACK
Windows 95 OSR2
Windows 98
Windows ME
Windows 2000
Windows XP
FCC Part 15 in US
EN300328 and EN300826 (EN301489-17) in Europe
Complies with IEEE802.11b standard for 2.4GHz
Wireless LAN
PCMCIA Type II compliant
PC Card hot swap supported and True Plug & Play
Interoperable with existing network infrastructure
Secure information transmission
Freedom to roam while staying connected
Compatible with specialty wireless products and
services
Up to 11Mbps data rate
Support operating systems such as Window 95
OSR2/98/2000/ME/XP/NT
Easy of Installation
