Summary of Contents for Powervar GPI Series 1
Page 1
POWERVAR Single Phase Power Conditioners User’s Guide • Industrial Conditioners • GPI Series B Conditioners • GPI Series 1 Conditioners • 2-15 kVA Single Phase Conditioners • GPI Series 1 Conditioners RoHS Compliant...
Page 2
POWERVAR to update information and/or product that has been delivered earlier. POWERVAR assumes no liability for typographical errors in this documentation. POWERVAR shall not be liable for technical or editorial errors or omissions contained hererin, nor for incidental...
CUSTOMER SERVICE For service, obtain the model number, part number, and serial number from the rear panel data plate. Then contact POWERVAR via phone or web to obtain a Return Material Authorization (RMA) number. This number must be marked on the shipping container and packing slip of the unit being returned.
APPENDIX A – INSTALLATION – INDUSTRIAL POWER CONDITIONERS GENERAL INSTALLATION This device is designed for permanent mounting inside a control cabinet or to a wall or other solid structure using #10 hardware. The conditioner has a dustproof and splashproof enclosure and may be mounted in any position. This device is intended for use in hardwired installations.
APPENDIX B – INSTALLATION – GPI SERIES B AND GPI SERIES 1 GENERAL INSTALLATION POWERVAR GPI Series B and GPI Series 1 power conditioners utilize an isolation transformer permitting the user to select from one of four different input voltages. Series B models are designed for hardwire installation and may be mounted in any orientation using the mounting holes provided.
Page 8
• If nominal output voltage is 120 volts, turn all load equipment on. GPI Series 1 • Plug GPI Series 1 into appropriate power receptacle and turn input breaker ON. • Using a voltmeter, measure output voltage to verify that output is nominal 120 volts.
Page 9
Figure 2 INPUT VOLTAGE ADJUSTMENT GPI SERIES B AND GPI SERIES 1 ABC500-XX ABC1000-XX ABC1500-XX ABC2000-XX, ABC3000-XX...
APPENDIX C – INSTALLATION – 2 to 15 kVA SINGLE PHASE CONDITIONERS GENERAL INSTALLATION This device may be permanently mounted using ¼ inch hardware. Sheet CC in this manual is provided for your use as a mounting/installation template. IMPORTANT NOTE: Models ending with the suffix “-2S” may be configured for either 208 or 240 volt input.
Page 11
Figure 3 2 kVA – 6 kVA NOTE: For input voltage conversion on models ending with suffix “-2S” only: • To convert 208 volt input to 240 volt input, move circuit breaker lead from point E2 of the printed circuit filter assembly to point •...
Page 12
Figure 4 8, 10, 15 kVA Input voltage adjustment taps this side of transformer NOTE: For input voltage conversion on models ending with suffix “-2S” only, adjust taps on left side of transformer (when viewed from rear of conditioner). Moving taps permits changing of input operating voltage between 208 and 240 volts.
Page 13
Access additional product information and support on the web at http://www.powervar.com You may register your ownership of POWERVAR products on our website at http://www.powervar.com. This will enable us to communicate with you if product issues, which might affect your satisfaction or safety, should arise.
