Owner's Manual
&
Installation Guide
Audiophile Sound Systems

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PHD2050 and is the answer not in the manual?

Questions and answers

Summary of Contents for Audiophile Systems PHD2050

  • Page 1 Owner's Manual & Installation Guide Audiophile Sound Systems...
  • Page 2: Specification

    SPECIFICATION AMPLIFIER PHD2050 PHD2200 PHD4050 4 Ohm RMS Output 60W x 2 210W x 2 60W x 4 2 Ohm RMS Output 90W x 2 300W x 2 90W x 4 4 Ohm Bridge Output 180W x 1 600W x 1...
  • Page 3 SPECIFICATION AMPLIFIER PHD4075 PHD11000 4 Ohm RMS Output 80W x 4 350W x 1 2 Ohm RMS Output 110W x 4 670W x 1 1 Ohm RMS Output 1100W x 1 4 Ohm Bridge Output 220W x 2 Low Pass Filter (Variable) 50Hz-250Hz 50Hz-250Hz High Pass Filter (Variable)
  • Page 4: Congratulations On Your Purchase

    -ment and one year of trouble free service. Please take a few moments to read this manual thoroughly. It will explain the features and operation of your unit and help insure trouble free installation. Features PHD11000 PHD2050/2200/4050/4075 Four Class ''AB'' High-Current Class ''D'' Technology Dual Discrete Drive Stages. 1 Ohm Stable...
  • Page 5 NEVER operate the amplifier without the proper power and ground wire, 10 gauge minimum. NEVER operate the amplifier without proper fusing. Fuse holder must be located with in 0.5 meters from the battery. This fuse is to protect the car not the electronics. In case of a short, the fuse will blow instead of the wire burning up.
  • Page 6: Installation Diagram

    INSTALLATION MOUNTING: 1. After reading precaution, decide where you are going to install the unit. Also, see Fig.1. 2. Once the location has been determined, place the amplifier into position. Using a felt tip pen or pencil mark the four holes to be drilled for mounting. NEVER use the amplifier as a template for drilling.
  • Page 7: Input Connections

    CONNECTIONS INPUT CONNECTIONS This amplifier will accept low level inputs only. Low level is the same as line level. The low level signal is carried through RCA cables. It is preferred to use low level inputs to the amplifier if the head unit is equipped with the low level outputs. If not, you can use a "high to low converter"...
  • Page 8 2CHANNEL SYSTEM WIRING DIAGRAM (PHD2050, PHD2200) LINE LINE INPUT OUTPUT CROSSOVER FULL 20Hz 50Hz 12dB 50Hz 250Hz 80Hz 1.2kHz LEVEL SUBSONIC BASS L.P.F H.P.F BOOST GND REM CAR STEREO HEAD UNIT LINE LINE INPUT OUTPUT CROSSOVER FULL 20Hz 50Hz 12dB...
  • Page 9 4CHANNEL SYSTEM WIRING DIAGRAM (PHD4050) LINE LINE INPUT OUTPUT CROSSOVER CROSSOVER C H 1 C H 3 C H 3 6 dB 6 dB 80Hz 1.2kHz O F F O F F 50Hz 250Hz MIN MAX 1 2 dB 1 2 dB LEVEL TREBLE H.P.F...
  • Page 10 4CHANNEL SYSTEM WIRING DIAGRAM (PHD4075) LINE LINE INPUT INPUT CROSSOVER CROSSOVER C H1 C H3 FULL FULL MIN MAX 12dB 50Hz 250Hz 80Hz 1.2kHz 80Hz 1.2kHz 50Hz 250Hz 12dB LEVEL BASS L.P.F H.P.F H.P.F L.P.F BASS LEVEL C H2 BOOST BOOST C H4 CH1/2...
  • Page 11 1CHANNEL SYSTEM WIRING DIAGRAM (PHD11000) LINE LINE OUTPUT INPUT MASTER SLAVE MIN MAX 15Hz 50Hz 12dB 50Hz 250Hz LEVEL SUBSONIC BASS L.P.F PHASE FILTER BOOST REMOTE MASTER / SLAVE GND REM CAR STEREO HEAD UNIT LINE LINE OUTPUT INPUT MASTER SLAVE MIN MAX 15Hz...
  • Page 12: Speaker Connections

    SPEAKER CONNECTIONS This amplifier can operate in one, two or three channel mode. The minimum impedance for single channel (bridged/mono) operation is 4 or 8 ohms. Tri channel power is referred to stereo and mono at the same time. Minimum impedance remains the same for three channel (front /subwoofer) systems as long as proper passive crossovers are used.
  • Page 13 SPEAKER CONNECTIONS 4 CHANNEL SPEAKER WIRING DIAGRAM (PHD 4050) 2 SPEAKER BRIDGED POWER SPEAKER OUTPUT FUSE BRIDGED BRIDGED PROTECT 1 CH 2 CH 4-8 Ohms 2 SPEAKER + 1 SUBWOOFER POWER SPEAKER OUTPUT FUSE BRIDGED BRIDGED PROTECT 2 CH 3 CH 2-4 Ohms SUB WOOFER 4 SPEAKER STEREO...
  • Page 14 SPEAKER CONNECTIONS 4 CHANNEL SPEAKER WIRING DIAGRAM (PHD 4075) 2 SPEAKER BRIDGED POWER SPEAKER OUTPUT BRIDGED BRIDGED FUSE C H1 C H2 C H3 C H4 PROTECT 1 CH 2 CH 2 SPEAKER + 1 SUBWOOFER 4-8 Ohms POWER SPEAKER OUTPUT BRIDGED BRIDGED FUSE...
  • Page 15 SPEAKER CONNECTIONS 1 CHANNEL SPEAKER WIRING DIAGRAM (PHD 11000) The Class "D" amplifier is a SINGLE CHANNEL dedicated subwoofer amplifier. Unlike other amplifiers, the Class "D" operates as a single channel and cannot be bridged. Don't be fooled by the outputs. Two outputs are used strictly for convenience and are paralleled internally on the amplifier.
  • Page 16: Front View

    SPEAKER CONNECTIONS WIRING SUBWOOFERS (DUAL AMPS) When using dual amplifiers to power one subwoofer, the Positive terminal of the Subwoofers voice coil is connected the positive terminal of the MASTER Amplifier and the Negative terminal of the Subwoofers voice coil is connected to Positive terminal on the SLAVE Amplifier. This procedure will allow the total power of both amplifiers to be added together and act like a single powerful amplifier.
  • Page 17: Front Panel

    5.The "BASS" function can be selected to increase low frequency response output, or decrease frequency response output. The "BASS" function will be working at only "OFF" or "L.P.F" position. The BASS is adjustable from 0 ~ 12dB boost at 50Hz. FRONT PANEL PHD2050, PHD2200 LINE LINE INPUT OUTPUT...
  • Page 18 FRONT PANEL PHD4050 LINE LINE INPUT OUTPUT CROSSOVER CROSSOVER C H 1 C H 3 C H 3 6 dB 6 dB 80Hz 1.2kHz O F F O F F 50Hz 250Hz MIN MAX 1 2 dB 1 2 dB LEVEL TREBLE H.P.F...
  • Page 19: Troubleshooting Guide

    TROUBLE SHOOTING GUIDE. This section provides you with a catalog of amplifier symptoms and their probable causes and solutions. Before you consult this listing, make sure the vehicle's electrical system is working properly by verifying that other electrical items (e. g. headlights, windows, etc.) Still function correctly.
  • Page 20 Audiophile Sound Systems...

This manual is also suitable for:

Phd2200Phd4050Phd4075Phd11000
