Page 1: User Manual
User Manual Model 1550 Field Setup Display Series 1500™ Intercom Systems... -
Page 2: Liability Statement
1500 SYSTEM CALIBRATION AND SETUP The Model 1550 is a liquid crystal display that shows the setup menus and settings for Series 1500 Intercom Systems. The entire system can be calibrated from one Counter Station (except for Model 1533*). Connect the 1550 Field Setup Display to RECESSED JACK the RJ45 jack on the underside of any live CAT 5E/6 (ANGLED) Counter Station. (The jack is at an angle.) Upon connection, the 1550 displays “Series 1500 EQUIPMENT CALIBRATION PLATFORM”. • Hold the SETUP key on the Counter Station for one second to enter Setup Mode. The 1550 displays the top level of the menu shown on page 4. • To navigate the menus, use the VOLUME UP and VOLUME DOWN keys to move the cursor. 1500A COUNTER STATION (UNDERSIDE) WARNINGS • Read these instructions before installing or using this product. • To reduce the risk of fire or electric shock, do not expose this unit to rain or moisture. • This product must be installed by qualified personnel. • Do not open the cover—there are no user-serviceable parts inside. • Do not expose this unit to excessive heat. - Page 3 Lane or Counter Station) 9 10 11 12 PRIVACY = Go Back to 13 14 15 16 previous menu SETUP = Enter or Confirm POWER USER TIPS • For faster menu navigation, submenus may be selected by touching the key that is lit RED corresponding to the menu item (see the numbered keys above). For instance, to enter BLOWER MOTOR DELAY, press 1 and then 1. • To Exit Setup Mode from any menu, hold SETUP for one second and follow the prompts on the 1550. • After adjusting a Lane Station or Counter Station, use the CAMERA UP or CAMERA DOWN keys to select other stations for adjustment without leaving the submenu. * Model 1533 Intercom / Telephone Interface requires separate programming using the 1550. After setting up the intercom system, connect the 1550 to each 1533 in the system and perform setup tasks as outlined in the 1533 manual.
- Page 4 1500 SETUP MENU MAP WITH DEFAULT VALUES Firmware Version 4.07 May 31, 2013 See 1533 manual for special telephone interface menu map. Root Menu First Menu Subset Second Menu Subset 1: System Parameters 1: Blower Motor Delay 2: Power Save Delay** 3: Supervisor Teller* 4: Lane Mirror Disable** 5: Traffic Sensor Tone 6: Background Threshold 7: Allow Video Scroll 8: Master Teller 2: Lane Parameters 1: Single Lane 1: Inbound Volume Level 2: Auto Select Lane 2: Outbound Volume Level 3: Group of Lanes 3: Open Loop Gain 4: All Lanes 4: Handset Mic Level 5: Cancel 5: Handset Speaker Level 6: Ringtone Override 7: Half Duplex Only 8: Program Audio Abate 9: Relay Operation 10: Swap Camera Up/Down 11: Suppress Video...
- Page 5 Financial Default Value Pharmacy Default Value None None Use Lane Ringtone Use Lane Ringtone None None None Selection Activates Selection Activates *Not Available with 1-on-1 configurations **Not available with 1509SD mini hub configurations Note: See the 1533 manual for definitions and setup instructions.
- Page 6 DEFINITIONS AUTO-SELECT 1 LANE Allows installer to configure lane audio settings using live audio from the lane. Useful for adjusting inbound and outbound audio levels. ALLOW HANDSFREE Allow communication using speaker and gooseneck microphone. ALLOW VIDEO SCROLL Inactive Counter Stations view all available cameras in sequence; when video scroll is disabled, inactive Counter Stations see only the wideview camera (if installed). BACKGRND THRESHOLD Adjustment for level of background audio rejected by Counter Station microphone. 0 = no rejection. BLOWER MOTOR DELAY If enabled, the period between disengagement of blower and microphone audio un-mute. FIRMWARE UPGRADE This menu allows the firmware of system components to be upgraded. HANDSET MIC LVL Inbound handset volume level adjustment. HANDSET SPKR LVL Outbound handset volume level adjustment. HALF DUPLEX ONLY Enables ‘push-to-talk’ operation. INBOUND VOLUME LVL Inbound volume level adjustment. KEY ASSIGNMENT This menu enables lane selection keys to be redefined in any configuration desired. First select the lane number to be assigned using the VOLUME keys. Then touch the key to be assigned to that lane. If the desired key is already assigned, touch it twice. For 20 lane systems use “Page Mode”. Page Mode allows the user to flip between two “pages” of keys. The first page contains lane 1-10, the second 11-20.
- Page 7 OPEN LOOP GAIN Adjustment for adapting to different acoustic environments. Lower this setting for Lane Station acoustical environments with too much microphone and speaker coupling. Increase this setting to hear more of the customer while operator is talking. PGM AUDIO ABATE ON = Program Audio heard ONLY when lane is on hold. OFF = Program Audio heard when lane is idle OR on hold. PHARMACY SETTINGS See the Model 1533 Telephone Intercom Interface Manual for details. POWER SAVE DELAY If enabled, the length of time the system must be idle before entering Power Save (LCD sleep). This feature only applies to lane montiors, not Counter Sation monitors. READ FROM MEM. CARD System settings are restored from hub memory card. RELAY OPERATION Allows configuration of Lane Station relay contacts (Model 1520 terminal block pos. 9 & 10). The contacts can be set to close using the HOLD key, or while the lane is selected. (See Operator Card l for HOLD key operation details.) RINGTONE OVERRIDE Press a key to select a unique ringtone for the selected Lane Station(s). 1 = no override (plays the ringtone set by each Counter Station). All other keys represent unique ring tones which override any Counter Station settings. SINGLE LANE Allows installer to configure lane audio settings without using live audio from the lane. Useful when lanes are in use or audio is not required for adjustments.
-
Page 8: Firmware Upgrade Instructions
FIRMWARE UPGRADE INSTRUCTIONS These instructions are applicable to Series 1500 Intercom systems with v4.0 or higher firmware. If your system is not SD card-compatible, or has v3.9 or earlier firmware, call Audio Authority technical support. Download the latest firmware version from http://www.audioauthority.com/page/series1500firmware and follow the instructions to copy the necessary files onto an SD card. Note: Series 1500 equipment with firmware prior to version 1.5 may not be upgraded to version 4.07 using older hubs. To upgrade to version 4.07, these systems must have a new 1509SD hub, or a new 1517SD hub card. This upgrade may take several minutes. The system cannot be used during this time, so plan for adequate down-time to complete and verify the upgrade. • Insert the SD memory card into the 1509SD or 1517SD card slot. • Connect a 1550 Installer Setup Tool to the underside of a Model 1500 Counter Station that has firmware v4.0 or higher. • Press Setup for 2 seconds • Press Key 5 (1st button on second row) • Press Key 4 (last button on top row) • Press the Mirror key • Press the Setup key twice After a successful upgrade, “Firmware upgrade complete” is displayed on the 1550 screen. The menu on the 1550 now shows several new selection options that apply only to the new 1500A, 1500AH, and 1533. Once the upgrade is complete, all indicators on the hub will return to normal operation. * 1-on-1 systems may be upgraded by temporarily connecting a hub. 2048 Mercer Road, Lexington, Kentucky 40511-1071 Phone: 859/233-4599 •...
