56K USB Modem
Easy Start
Version 2.0
Product warranty does not apply to damage caused by lightning, power surges or wrong voltage usage.
This product is for use only in UL Listed computers.
To reduce the risk of fire, use only No. 26 AWG or larger telecommunication line cord.
Easy Start
Easy Start
Page 1 of 16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 56K and is the answer not in the manual?

Questions and answers

Related Manuals for Aztech 56K

Summary of Contents for Aztech 56K

  • Page 1 Easy Start 56K USB Modem Easy Start Version 2.0 Product warranty does not apply to damage caused by lightning, power surges or wrong voltage usage. This product is for use only in UL Listed computers. To reduce the risk of fire, use only No. 26 AWG or larger telecommunication line cord.

  • Page 2: Table Of Contents

    Easy Start Table of Contents Preliminary Pages Page Table of Contents ........................2 Chapter 1 - About this Easy Start..................6 Minimum System Requirements ............6 Package.....................6 Chapter 2 - Connecting The Modem To Your Computer............7 Chapter 3 - Installing Your Modem Driver .................8 Installing your Modem Driver for Windows 98 Second Edition ..8 Installing your Modem Driver for Windows 2000......10 Installing your Modem Driver for Windows ME......12...
  • Page 3 Easy Start Warning & Safety Messages… WARNING! Before installing the Modem card ensure the PC is switched OFF and the mains cord removed. If servicing the Modem card ensure the PC is switched OFF, the mains cord unplugged and the Telecommunications Line cord is disconnected from the Modem Card EUROPEAN NETWORK COMPATIBILITY DECLARATION This product is designed to interwork with the Public Switched Telecommunication Networks in...
  • Page 4 Easy Start Pan European Approval Regulatory Note The equipment has been approved under CTR21. For such product, the following statement is required: “This equipment has been approved in accordance with Council Decision 98/482/EC for Pan European single terminal connection to the Public Switched Telephone Network (PSTN). However, due to differences between the individual PSTNs provided in different countries the approval does not, of itself, give an unconditional assurance of successful operation on every PSTN network termination point.
  • Page 5 Easy Start 1. There shall be no more than 10 call attempts to the same number within any 30 minute period for any single manual call initiation. 2. The equipment shall go on-hook for a period of not less than 30 seconds between the end of one attempt and the beginning of the next attempt.

  • Page 6: Chapter 1 - About This Easy Start

    Easy Start Chapter 1 - About this Easy Start This booklet contains information on setting up your 56K USB Modem. It touches on the key installation procedures and allows you to setup your modem within minutes! Minimum System Requirements Pentium ® MMX 233MHz •...

  • Page 7: Chapter 2 - Connecting The Modem To Your Computer

    Chapter 2 - Connecting The Modem To Your Computer The 56K USB Modem is a 'plug-n-play' device. You may connect your modem to your computer anytime without having to power down your system. Connect as follow and your Windows will immediately detect the new hardware and prompt for its driver.

  • Page 8: Chapter 3 - Installing Your Modem Driver

    Easy Start Chapter 3 - Installing Your Modem Driver Installing your Modem Driver for Windows 98 Second Edition If your modem is connected as illustrated in Chapter 2 , you will be prompted for the modem driver. Figure 1 : Prompted for Driver Place the Installation CD into your CD-ROM Drive and click Next .
  • Page 9 Easy Start Figure 3 : Specifying Location Windows will prompt that it has located the driver. Click Next to proceed. See Fig 4 . Figure 4 : New Driver Found (Depending on your system configurations you may be prompted for your Windows CD-ROM .

  • Page 10: Installing Your Modem Driver For Windows 2000

    Easy Start Installing your Modem Driver for Windows 2000 If your modem is connected as illustrated in Chapter 2 you will be prompted for the modem driver. Place the Installation CD into your CD-ROM Drive and click Next . See Fig 6 . Figure 6 : Prompted for Driver Click Search for a suitable driver for my device.
  • Page 11 Easy Start Click Specify a location and click Next. See Fig 8 . Figure 8 : Specifying Location Click Browse . Navigate to the '\ Win2000 ' folder on your Installation CD. Click OK . (The screen shot uses the CD-ROM drive letter D as an example. You should see the letter of your CD-ROM drive.) See Fig 9 .

  • Page 12: Installing Your Modem Driver For Windows Me

    Easy Start Click Finish to complete driver installation. See Fig 11 . Figure 11 : Installation Completed Installing your Modem Driver for Windows ME If your modem is connected as illustrated in Chapter 2 , you will be prompted for the modem driver.
  • Page 13 Easy Start Click Specify a location . Click Browse . Navigate to the ' \WinMe ' folder on the Installation CD and click OK . Click Next to proceed. See Fig 13 . Figure 13 : Navigate Folder Windows will prompt that it has located the driver. Click Next . See Fig 14 . Click Finish to to complete driver installation.

  • Page 14: Installing Your Modem Driver For Windows Xp Service Pack 1

    Easy Start Installing your Modem Driver for Windows XP Service Pack 1 If your modem is connected as illustrated in Chapter 2 , you will be prompted for the modem driver. Place the Installation CD into your CD-ROM Drive. Click Install from a list or specific location and click Next. See Fig 16. Figure 16 : Prompted for Driver Click Include this location in the search .

  • Page 15: Installing Your Modem Driver For Windows Xp Service Pack 2

    Easy Start Installing your Modem Driver for Windows XP Service Pack 2 Place the Installation CD into your CD-ROM Drive and run the Setup.exe file in the ' \WinXP ' folder on the Installation CD. Click on >> to proceed. See Fig 19 . Installation will start automatically as shown in Fig 20 .

  • Page 16: Chapter 4 - Uninstalling Your Modem Driver

    Easy Start Figure 22 : WIN 2000/XP Figure 23 : WIN 98SE/ME If you see a yellow exclamation mark besides SmartUSB56 Modem , it means that your driver is not installed successfully. Right-click on the device and then uninstall the modem. Restart the system and then install your modem driver again.
