Summary of Contents for Summit Systems DIGITAL VIDEO RECORDER
-
Page 1: Digital Video Recorder
SUMMIT SYSTEMS DIGITAL VIDEO RECORDER OPERATIONS MANUAL Summit Systems Digital Recorder - 1 - Operations Manual Ver. 1.0 March 2008... - Page 2 Setup – (Configuring Passwords to log into the DVR) TV-MD (Spot monitor image configuration) Adjust the time (minutes & seconds) – Set time Adjustment 31 – 32 Camera channels Button. Summit Systems Digital Recorder - 2 - Operations Manual Ver. 1.0 March 2008...
- Page 3 Press the white dot on the switch and then release. The switch will spring back to its original position. Your DVR will boot up into Microsoft Windows XP and the SS3 software will start automatically. Summit Systems Digital Recorder - 3 - Operations Manual Ver. 1.0 March 2008...
- Page 4 The red and green lights on the unit will flash on and you will be left with a permanently on green light once the unit is active. Summit Systems Digital Recorder - 4 - Operations Manual Ver. 1.0 March 2008...
- Page 5 LOCKER Tab between the Control Bar and the Viewing Area DEFUALT Tab at the far left of the screen INFORMATION BAR OPERATIONS STATUS WINDOW LOCAL CAMERA RECORDING STATUS LOCKER DEFAULT VIEWING AREA CONTROL BAR Summit Systems Digital Recorder - 5 - Operations Manual Ver. 1.0 March 2008...
- Page 6 Shows the current time, hover mouse over clock to see current date, refer to the section on changing the current time to change minutes and seconds of the system. Summit Systems Digital Recorder - 6 - Operations Manual Ver. 1.0 March 2008...
-
Page 7: Question Mark
INFORMATION BAR (Cont) QUESTION MARK Left click the mouse cursor once on the Question mark and then click on any tab or box for a text information screen Summit Systems Digital Recorder - 7 - Operations Manual Ver. 1.0 March 2008... - Page 8 EXIT - Exits the Summit DVR software and returns you to Windows Interface, note that once Exited the system is no longer recording Summit Systems Digital Recorder - 8 - Operations Manual Ver. 1.0 March 2008...
-
Page 9: Logging Into The System
Once you have entered your code and pressed the enter button, the light blue screen along the Information Bar will advise that the screen has been successfully unlocked. The interface buttons can now be utilised. Summit Systems Digital Recorder - 9 - Operations Manual Ver. 1.0 March 2008... - Page 10 To create your own layouts, right click on Default and then left click on Add to Defaults, give the new Default a distinctive name and click OK. Summit Systems Digital Recorder - 10 - Operations Manual Ver. 1.0 March 2008...
- Page 11 Note: - you can also copy the record playing back directly to a CD/DVD by pausing playback, selecting Backup and then copy Record; the currently playing record will be copied to disk. (Requires a blank CD/DVD to be inserted.) Summit Systems Digital Recorder - 11 - Operations Manual Ver. 1.0 March 2008...
- Page 12 & is not edited in any way by an image editing application, this is known as watermarking. Summit Systems Digital Recorder - 12 - Operations Manual Ver. 1.0 March 2008...
- Page 13 If you click on a camera that does not have audio attached their will be no audio level to adjust. Summit Systems Digital Recorder - 13 - Operations Manual Ver. 1.0 March 2008...
- Page 14 To adjust the iris by opening or closing it, left mouse click & hold on the left or right arrow of the IRIS tab to open or close the iris. Summit Systems Digital Recorder - 14 - Operations Manual Ver. 1.0 March 2008...
-
Page 15: Play Control
Playback box will disappear, to return it to the screen simply left click on PLAY and the box will re-appear. Summit Systems Digital Recorder - 15 - Operations Manual Ver. 1.0 March 2008... - Page 16 To auto sequence through the cameras when in 1, 4 or 9 screen view click on the circular tab, the screen will begin to switch from 1 image or group of images to the next image or group. Summit Systems Digital Recorder - 16 -...
- Page 17 Auto Sequence on the Control Tab, the cameras that are selected to play back together will now sequence from 1 to the other. Summit Systems Digital Recorder - 17 - Operations Manual Ver. 1.0 March 2008...
-
Page 18: Backup Tab
1 after the other. Summit Systems Digital Recorder - 18 -... - Page 19 I.E. “papers thief”, (without the quotation marks) then left mouse click on Save and the file will be saved to this location. Summit Systems Digital Recorder - 19 - Operations Manual Ver. 1.0 March 2008...
- Page 20 CDROM or DVD with other images. Note:- once saved the record will continue to playback from where it was previously paused. Summit Systems Digital Recorder - 20 - Operations Manual Ver. 1.0 March 2008...
- Page 21 There are now a number of ways to select individual times and cameras for copying. Summit Systems Digital Recorder - 21 - Operations Manual Ver. 1.0 March 2008...
- Page 22 264 after this is merely the type of file created by the Summit system and holds no relevance. Summit Systems Digital Recorder - 22 - Operations Manual Ver. 1.0 March 2008...
- Page 23 CD /DVD. Summit Systems Digital Recorder - 23 - Operations Manual Ver. 1.0 March 2008...
- Page 24 Microsoft Windows operating system, by 1 running the application and then following the prompts on the screen (refer page 25, SSViewer) Summit Systems Digital Recorder - 24 - Operations Manual Ver. 1.0 March 2008...
- Page 25 These images can be reviewed later on the CD / DVD disk by way of the application SSViewer. These images are a native Microsoft Bitmap file and can also be viewed by any version of Windows from 95 to Vista Summit Systems Digital Recorder - 25 - Operations Manual Ver. 1.0 March 2008...
- Page 26 Double click on any of the records in the directory to commence playback of that record. Summit Systems Digital Recorder - 26 - Operations Manual Ver. 1.0 March 2008...
- Page 27 DVD and select another record to playback. When playing back click the pause button to pause, click the speed buttons 4, 2, 1 ½ , ¼, 1/25 increase / decrease playback speed. Summit Systems Digital Recorder - 27 - Operations Manual Ver. 1.0 March 2008...
- Page 28 To set individual cameras for specified times of the day click the required camera, drag across the time squares so they are highlighted and then click motion and save. Summit Systems Digital Recorder - 28 - Operations Manual Ver. 1.0 March 2008...
- Page 29 / edit Motion and External alarm settings LogView allows the user to see the system log screen System/Misc - allows the user full access to all system functions (master access) Summit Systems Digital Recorder - 29 - Operations Manual Ver. 1.0 March 2008...
- Page 30 The time will re-adjust itself to the new settings. Note: due to the nature of the Windows XP system the adjustment may take several seconds to show but will be correct when changed. Summit Systems Digital Recorder - 30 - Operations Manual Ver. 1.0 March 2008...
- Page 31 Once you have this open, make sure the camera browser is out of the way of camera channel 1, like so: Summit Systems Digital Recorder - 31 - Operations Manual Ver. 1.0 March 2008...
- Page 32 This same procedure can be repeated for remote cameras as well. Just click, point and click again and SS3 will automatically connect to the corresponding DVR (where connected) and start to view its live feed. Summit Systems Digital Recorder - 32 - Operations Manual Ver. 1.0 March 2008...
