Mitsubishi Electric HC7800D Brochure & Specs

Specifications
Model
Projection system
Panel size
Number of pixels
Panel specs
Drive system
Array
1
Zoom / focus operation *
Lens
f (mm) 1
*
Optical specs
Light source lamp
Optical system
Colour wheel
Projection screen size (inches)
1 2
Brightness (lm) * *
Contrast ratio 1
*
Images
Resolution PC input
Horizontal (kHz)
Scan frequency
Vertical (Hz)
Input signal Video
system
PC
Analog RGB Mini D-sub 15pin
Digital RGB
Image HDMI terminal
Input Components RCA terminal
Serial Serial terminal
LAN terminal (RJ45)
LAN
Picture mode
Digital keystone (Vertical)
Power source voltage
Functions
Power consumption (W)
Weight (kg)
Main unit dimensions (W x H x D)
Other Supplied accessories
*1 Varies depending on conditions. *2 Compliant with ISO21118-2005 *3 All the brand names and product names are trademarks, registered trademarks or trade names of their respective holders.
The Trident Logo is a trademark or registered trademark of Trident Microsystems (Far East) Ltd. or its affiliates in the U.S. and other countries.
3D Viewing Precautions
Each person perceives 3D images differently. There may be times when viewing causes a person to feel uneasy.
If a person begins to feel tired or uncomfortable when viewing 3D images, they should stop watching immediately.
When watching 3D programs, be sure to take occasional breaks and do not watch continuously for long periods of time.
The viewing of 3D images is not recommended for children under the age of 5~6.
The proper viewing form for 3D images is to wear 3D Glasses and have both eyes horizontal to the screen as much as possible.
3D Glasses are fragile and may break if the frames are twisted or if handled recklessly. Do not watch 3D programs if the 3D Glasses are defective or there is a problem with them.
When viewing 3D images, it is recommended to sit at a viewing distance equal to at least three times the effective screen size.
MITSUBISHI ELECTRIC AUSTRALIA PTY LTD
348 Victoria Rd Rydalmere, NSW 2116 Phone: (02) 9684 7777 Fax: (02) 9684 7208
To find out more about HC7800D and our projectors,visit us at
www.MitsubishiElectric.com.au
HC7800D
DLP TM system
0.65 DMD, Aspect ratio 16:9
1920x1080
DMD reflection system
Stripe pattern
1.5x manual zoom / manual operation
20.6-30.1
240W (at standard mode), 190W (at low mode)
Time-division colour separation / composition system
6 segment (RGB RGB), 4x
50-300
1500 (maximum)
100,000:1 (when the Iris is closed)
VGA 640x480 - UXGA1600x1200,1920x1080
15-85
24-85
Video input: 480i/p, 576i/p, 1080i 60/50, 1080p 60/50/24, 720p 60/50
PC/AT compatibles, Mac, PC98
1 terminal
2 terminals (3D/Deep Color compatible)
1 terminal (component can be also input to Mini D-Sub 15 pin)
1 terminal (Mini D-sub 9pin )
1 terminal
3 patterns + 3 AV memories
±15 steps
AC100-240V 50/60Hz AC100V 50/60Hz
370 (0.5W in standby)
5.6kgs
396 x 142 x 328 mm (Not including protrusion)
Power source cord (1.8m), Remote control, AA batteries (x2), 3D Emitter, Emitter cable (1.8m),
RGB signal cable, Lens cap, Lamp replacement attachment
Specifications are subject to change without notice.
HOME THEATRE PROJECTOR
HC7800D
