Casio 2514 User Manual

Getting Acquainted
Congratulations upon your selection of this CASIO watch. To get the most out of your
purchase, be sure to carefully read this manual and keep it on hand for later reference
when necessary.
Expose the watch to bright light to charge its battery before using it.
You can use this watch even as its battery is being charged by exposure to bright
light.
• • • • • Be sure to read "Battery" of this manual for important
information you need to know when exposing the watch to bright light.
If the display of the watch is blank...
If the sleep indicator ( ) is on the display, the display is
blank because the watch's Power Saving function has
Sleep indicator
shut it to conserve power. Power Saving automatically
turns off the display and puts the watch into a sleep state
whenever your watch is left in an area where it is dark for
a certain period.
• The initial factory default setting is Power Saving on.
• The watch recovers from the sleep state if you move it to
a well-lit area
* It can take up to five seconds for the display to turn on.
• See "Power Saving Function" for more information.
General Guide
• Press C to change from mode to mode.
• In any mode, press L to illuminate the display.
Timekeeping Mode
Press C.
Timekeeping
Use the Timekeeping Mode to set and view the current time and date.
• Pressing A displays the Last Signal screen (date and time the time calibration
signal was last received) in the Timekeeping Mode.
Month – Day Day of week
Press A.
PM
Seconds
indicator
Hour : Minutes
Current Time Setting
This watch automatically adjusts its time setting in accordance with a time calibration
signal. You can also perform a manual procedure to set the time and date, when
necessary.
• Before using the watch in the Continental United States, first use the procedure
under "Setting Up the Watch for Use in the Continental United States" to set the time
in accordance with a time calibration signal.
• Note that after you set your Home City (the city where you normally use the watch)
code, you must also turn on the watch's time calibration signal receiver if you want to
enable auto time calibration. See "About Auto Receive" for more information.
• See "Setting the Time and Date Manually" for information about manual settings.
• Before using the watch in Japan, first specify your Home City, select the DST setting
you want to use, and then perform the procedure under "To perform manual time
calibration signal reception".
Setting Up the Watch for Use in the Continental United States
You need to make the following three settings before using this watch in the
Continental United States. The following provides a general overview of the setting
procedure. For full details, see "Setting the Time and Date Manually" and "Time
Calibration Signal Reception".
• Specify the city code for your Home City (the city where you will normally use the
watch).
• Select the auto summer time (DST) setting.
• Perform the manual time calibration signal receive operation to set the current time.
To set up the watch for use in the Continental United States
1. In the Timekeeping Mode, press B. This causes the
GMT differential City code
current auto receive on/off setting (the receive indicator)
to flash, which indicates the setting screen.
2. Press C twice to move the flashing to the city code
setting.
3. Use D(+) and A(–) to select the city code you want to
use as your Home City.
• The following are the city codes for major cities in the
Continental United States time zones.
Receive indicator
LAX: Los Angeles, San Francisco, Las Vegas, Seattle
DEN: Denver, El Paso
CHI: Chicago, Houston, Dallas/Fort Worth, New Orleans
NYC: New York, Detroit, Miami, Boston
4. Press C to display the summer time (DST) setting
screen.
5. Use D to select AUTO DST.
• AUTO DST specifies auto switching between Daylight
Saving Time and Standard Time.
6. Press B to exit the setting screen.
USER'S GUIDE 2514
or if you press any button.
*
World Time Mode
Receive date
Receive time
Last Signal Screen
About This Manual
• Button operations are indicated using the letters shown
in the illustration.
• Each section of this manual provides you with the
information you need to perform operations in each
mode. Further details and technical information can be
found in the "Reference" section.
Alarm Mode
Stopwatch Mode
7. Hold down A for about two seconds until the watch
beeps.
• Release A and the message receiving appears to
indicate that signal reception has started.
• Time calibration signal reception takes from two to six
minutes. Take care that you do not move the watch
during this time.
• If the watch is indoors, we recommend that you place
the watch near a window to allow better signal
Receive indicator
reception.
• After signal reception is complete, the display of the
watch changes to the Last Signal screen.
Time Calibration Signal Reception
This watch is designed to pick up a time calibration signal and update its time setting
in accordance with the signal. There are two different methods you can use to receive
the signal: Auto Receive and Manual Receive. With Auto Receive, the watch
automatically receives the calibration signal three times each day and makes
appropriate adjustments. With Manual Receive, you perform a specific button
operation to receive the calibration signal.
Before performing a signal receive operation, remove the watch from you wrist and
position it as shown in the illustrations below.
• If your watch has a resin band, pass the end of the band through the band loop and
place the watch on a stable surface.
Resin band
Pass through band loop.
Note
• If you are using the time calibration signal to set the time for this watch, be sure to
correctly set your Home City. Otherwise, there is the chance that the watch will not
set the correct time. See "Setting the Time and Date Manually" for details.
• Note that signal reception is possible only when the watch is within range of a time
calibration signal transmitter, and a city code that supports signal reception is
selected as the Home City code.
• The current time setting in accordance with the time calibration signal takes priority
over any time settings you make.
• Auto receive is turned on when the watch is shipped from the factory.
• See the information under "Time Calibration Signal Reception" if you experience
problems with time calibration signal reception.
To perform manual time calibration signal reception
1. Place the watch on a stable surface so its top (12 o'clock side) is facing in the
general direction of the signal transmitter.
• Note that signal reception is poor if the watch is on its back or side.
2. In the Timekeeping Mode, hold down A for about two
seconds until the watch beeps.
• Release A and the message receiving appears to
indicate that signal reception has started.
• Time calibration signal reception takes from two to six
minutes. Take care that you do not move the watch
during this time.
• After signal reception is complete, the display of the
watch changes to the Last Signal screen.
• The receive indicator indicates that the calibration time
reception attempt was successful.
Receive indicator
Data Memory Mode
Metal band
