Summary of Contents for Rockford Fosgate Punch PP4-T
- Page 2 • (1) Punch Pro Tweeter • Mounting hardware red ring.
- Page 3 Punch Pro Tweeters PP4-T PP8-T Nominal Diameter - inch (mm) 1.5 (38.1) 1.5 (38.1) For the PP4-T and PP8-T, the crossover is Description Pro tweeter Pro tweeter integrated into the back cover of the tweeter. This crossover allows for easy connection of Nominal Impedance (ohms) 4Ω...
- Page 4 5.28" (134.00mm) 3.45" 4.88" (87.68mm) (124.00mm) Diameter 3.24" 2.59" (82.27mm) (65.80mm) 4.33" (110.00mm)
- Page 5 La borne positive du haut-parleur est indiquée par un anneau rouge. Pour les modèles PP4-T et PP8-T, le filtre de coupure est intégré au haut-parleur, si Para el PP4-T y el PP8-T, el cruce es un diseño integral del altavoz. Por lo tanto, no se...
- Page 6 Der positive Anschluss des Lautsprechers ist mit einem roter Ring markiert. identificato dal anello rosso. Bei den Modellen PP4-T und PP8-T ist das Crossover ein integrales Design des Per progettazione, il crossover del PP4-T e del PP8-T è incorporato nel diffusore.
- Page 7 Mounting Template Mounting Holes 4.88" (124.00mm) Hole Cutout 4.375" (111.00mm) Verify Scale Before Using 1.00" (25.40mm) Template 1.00" (25.40mm)
- Page 8 Pro Tweeter Diaphragm Replacement 5, Take out new diaphragm/coil assemly, align holes in plastic with rivets on top plate and fit to motor carefully. 1, Hold the phase plug firmly,release screw from back of motor to remove phase plug. 6, Align the pins on housing with holes in 2, Disconnect the connectors and plastic then secure housing with screws.
