Installation, Operation and Maintenance
Owner's Manual
SC200-DWS11, SCM200-DWS11
SC320-DWS12, SC320-DWS22,
SCM320-DWS12, SCM320-DWS22
Manufactured in Canada by:
425 Clair Road West P.O. Box 1719
Guelph, ON N1L 1R1 Canada
EPA# 57987-CN-001
t. 519.763.1032
f. 519.763.5069
•
June 2008
e. water@r-can.com
i. www.r-can.com
•
P/N 520114
Advertisement
Table of Contents
Summary of Contents for Sterilite Cobalt SC200-DWS11
- Page 1 Installation, Operation and Maintenance Owner’s Manual SC200-DWS11, SCM200-DWS11 SC320-DWS12, SC320-DWS22, SCM320-DWS12, SCM320-DWS22 Manufactured in Canada by: 425 Clair Road West P.O. Box 1719 Guelph, ON N1L 1R1 Canada EPA# 57987-CN-001 t. 519.763.1032 f. 519.763.5069 • June 2008 e. water@r-can.com i. www.r-can.com •...
- Page 2 Why buy original factory specified lamps... • All Sterilight systems are third-party verified in actual biodosimetry tests (complete ® bacteriological evaluation of the system, not just electrical output of the lamp). • All Sterilight UV systems are CSA certified with Sterilume lamps.
- Page 3 Congratulations , you have just purchased the Sterilight Cobalt™ ® drinking water system. By purchasing this device, you have taken the first step in ensuring the safety of your water supply by using a totally non-intrusive, physical disinfection method. Your Sterilight system uses the most advanced UV technology on the market and is designed to provide you with...
-
Page 4: Table Of Contents
Table of Contents: Parts / Schematic Breakdown Safety Instructions Water Chemistry Installing Your UV Disinfection System Disinfection Procedure Operating and Maintenance Instructions 7-10 Operation 11-14 Troubleshooting 15-16 Dose Flow Chart Specifications 17-18 Manufacture’s Warranty *CSA/UL certification with approved power cord and lamps only. Symbols: Protective Caution... - Page 5 Parts: Hard glass, coated Sterilume ®- Ho UV lamps for long, consistent life (9000 hours) Controller S200RL-HO FOR 200 SERIES pOWEr - 100-240V/50-60Hz S320RL-HO FOR 320 SERIES BA-ICE-C COBALT “BASIC” SYSTEM BA-ICE-CM COBALT “PLUS” SYSTEM lamp connector 214 fused quartz sleeves retaining clip with fire polished ends qS-200...
-
Page 6: Safety Instructions
Safety Instructions: WARNING - to guard against injury, basic safety precautions should be observed, including the following: 1. READ AND FOLLOW ALL SAFETY INSTRUCTIONS. 2. CAUTION - Always disconnect power before servicing. 3. DANGER - To avoid possible electric shock, special care should be taken since water is present near electrical equipment. -
Page 7: Water Chemistry
Water Chemistry: Water quality is extremely important for the optimum performance of your UV disinfection system. The following levels are recommended for installation: • Iron: < 0.3 ppm (0.3 mg/L) • Hardness*: < 7 gpg (120 mg/L) • Turbidity: < 1 NTU •... - Page 8 optional 4-20Ma “Y” cable 2. Select a suitable location for the disinfection system and its related components. As it is recommended to install a ground fault protected circuit (GFCI), make sure that this is taken into consideration prior to any installation. When selecting a mounting location, you must leave enough space to allow for the removal of the UV lamp/quartz sleeve, as well as enough space to change out the filter cartridges (typically leave a space equal to the size of the reactor chamber itself above...
- Page 9 8. Once it is determined that there are no leaks, plug the system into the ground fault interrupter, and check controller to ensure the system is operating properly. The controller is designed to detect both power to the system and lamp illumination. It is important to NEVER LOOk DIRECTLY AT THE GLOWING UV LAMP.
-
Page 10: Disinfection Procedure
Disinfection Procedure: UV disinfection is a physical disinfection process and does not add any potentially harmful chemicals to the water. As UV does not provide a disinfection residual, it is imperative that the entire distribution system located after the UV be chemically disinfected to ensure that the water is free from any bacteriological contaminants. -
Page 11: Operating And Maintenance Instructions
OPERATION • Always disconnect power before performing any work on the disinfection system. • Regularly inspect your disinfection system to ensure that the power indicators are on and no alarms are present. • Replace the UV lamp annually (or biennially if seasonal home use) to ensure maximum disinfection. - Page 12 4. Once the lamp is fully seated on the connector, slide the connector over the aluminum retaining nut. Make sure the metal retaining ring on the connector is pulled away from the body of the connector in order that the connector may slide fully over the retaining nut.
- Page 13 UV Sensor Replacement / Cleaning (SCM models only): The UV sensor is very delicate instrument. Extreme care is required when handling and cleaning. The sensor window itself is constructed from quartz which is extremely fragile, be careful you do not chip or break this quartz window. Manufacturer’s warranty does not cover damage due to neglect or misuse.
- Page 14 Cartridge Change: It is recommended to change the filter cartridges every six months (or earlier). A gradual drop in water pressure after the filtration device is an accurate method of determining that the pre-filter cartridges are nearing the end of their useful life! To change the cartridges, please follow the following procedures: Note: Prior to performing any work on the whole home system, ALWAYS DISCONNECT THE pOwER SUppLy FIRST.
-
Page 15: Operation
Operation: Basic Systems incorporating BA-ICE-C controller: 1. Lamp life remaining (days): The controller tracks the number of days of operation of the lamp and the controller. The default screen will display the total lamp life remaining (in days). The controller will count down the number of days remaining until the lamp requires changing (365 days to 1 day). - Page 16 “plus” Systems incorporating BA-ICE-CM controller: 1. UV intensity (%): The Cobalt “Plus” series of products incorporate a UV sensor which detects the discrete 254 nm wavelength of the UV lamp. This information is relayed to the Cobalt “Plus” controller and is the default display shown in “% UV output”. The system will display the UV output between 50 to 99 percent.
-
Page 17: Operation
Possible causes for low UV alarm conditions: a) The UV lamp has perhaps reached a level whereby it can no longer adequately provide a sufficient level of disinfection due to age (> 9000 hours). The lamp should be replaced with a new lamp from the manufacturer of the same size and type. b) The quartz sleeve and/or the sensor window have become stained or dirty. - Page 18 6. 4-20mA output (optional): For those looking for the capability to transmit the UV intensity data to a remote location via a 4-20 mA signal, an optional “Y” cable is available from your dealer (Figure 5A). Please order PN 260134. This “Y” cable comes with 20 meters (65‘) of cable for the 4-20 mA signal.
-
Page 19: Troubleshooting
Troubleshooting: TRoUBLESHooTING GUIDE Symptom Possible Causes Solutions • replace filter cartridge with appropriate Sediment pre-filter 5 micron cartridge clogged Note: check source water supply as pressure Drop fluctuations may occur in source pressure • flow regulator will result in pressure drop Flow regulator when approaching full flow •... -
Page 20: Dose Flow Chart
DISPLAy FAULT MoDES LED display reads • lamp life expired - countdown is at “0” days “A3” • press reset button for a deferred alarm, replace UV lamp • controller is in lamp failure mode LED display is • power system down, allowing it to reset itself; apply power in order to blank confirm that the controller is able to power lamp •... -
Page 21: Specifications
Specifications – 200 series: MODEL SC200-dwS11 SCM200-dwS11 56.8 lpm 56.8 lpm US public Health (15 gpm) (15 gpm) 16mJ/cm (3.4 m /hr) (3.4 m /hr) 30.3 lpm 30.3 lpm R-Can Standard (8 gpm) (8 gpm) 30 mJ/cm (1.8 m /hr) (1.8 m... -
Page 22: Specifications
Specifications – 320 Series: MODEL SC320-dwS12 SC320-dwS22 SCM320-dwS12 SCM320-dwS22 94.6 lpm 94.6 lpm 94.6 lpm 94.6 lpm US public Health (25 gpm) (25 gpm) (25 gpm) (25 gpm) 16mJ/cm (5.7 m /hr) (5.7 m /hr) (5.7 m /hr) (5.7 m /hr) 49.2 lpm 49.2 lpm... -
Page 23: Manufacture's Warranty
Manufacture’s Warranty: Manufacturer warrants the ultraviolet disinfection system hardware and electrical systems to be free from defects in material and workmanship for a period of five (5) years from the date of purchase by the original owner (consumer) on a pro-rated basis.
