Duraflame illuma 61000 Owner's Manual

Bio-ethanol fireplace burner and log set

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Distributed by:

Duraflame, Inc., Stockton, CA 95201

For questions about Assembly and Operating instructions or Warranty Claims

contact Duraflame, Inc. Consumer Affairs

info@duraflame.com

1 (866) 552-3015

www.duraflame.com/illuma

Patents Pending

Tested to UL 1370 for "unvented bio-ethanol burners" by PFS Corporation

WARNING: If the information in this manual is not followed exactly, a fire or explosion may

result, causing property damage, personal injury, or loss of life.

Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any

other appliance.

WHAT TO DO IN THE EVENT OF AN ALCOHOL SPILL: DO NOT light the burner. Extinguish

any open flame near the spill. Wipe up the spill, and wait several minutes for the residue to

evaporate.

WARNING: Improper installation, adjustment, alteration, service, or maintenance can cause

injury or property damage. Refer to this manual for correct installation and operational

procedures.

WARNING: This appliance is for installation only in a solid-fuel-burning masonry fireplace, a

UL127 factory-built fireplace, or in an ANSI Z21.91 ventless firebox. It is design certified for

these installations in accordance with UL1370. Exception: Do not install this appliance in a

factory-built fireplace that includes instructions stating that it has not been tested or should

not be used with unvented gas logs.

This appliance may be installed in a fireplace or firebox approved for aftermarket, permanently

located, manufactured (mobile) homes, where not prohibited by local codes.

This appliance is for use only with duraflame

rating plate. This appliance is not convertible for use with other fuels, nor should you use

illuma-fuel

with any product other than duraflame

Save this manual for future reference.

Bio-ethanol fireplace burner and log set

Model # 61000

illuma-fuel

or types of fuel indicated on the

illuma

log sets.

™

-1-

Table of Contents

Need help?

Do you have a question about the illuma 61000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Duraflame illuma 61000

Page 1 This appliance may be installed in a fireplace or firebox approved for aftermarket, permanently located, manufactured (mobile) homes, where not prohibited by local codes. This appliance is for use only with duraflame illuma-fuel or types of fuel indicated on the ®...
Page 2: Table Of Contents
TABLE OF CONTENTS page Safety Information ................ 3 Air for Ventilation and Combustion ..........5 III. Setup .................... 7 Minimum Firebox Dimensions ............9 Installation and Clearances ............9 Installing Damper Stop ..............9 VII. Installation ..................9 VIII. Installing the Fuel Canister ............12 Operation ..................
Page 3: Safety Information
I. SAFETY INFORMATION IMPORTANT: Read this owner’s manual carefully and completely before trying to assemble, operate, or service this appliance. Improper use of this appliance or failure to comply with the safety rules can cause serious injury or death from burns, fire, explosion, or carbon monoxide poisoning.
Page 4 For contact with skin, rinse well with cool water. If irritation develops, see your doctor. Do not remove a duraflame illuma-fuel canister from the appliance until the canister is completely empty. WHAT TO DO IN THE EVENT OF A FUEL SPILL OR FUEL LEAK: DO NOT light the burner.
Page 5: Air For Ventilation And Combustion
In case of burns, seek treatment from your doctor or hospital. Duraflame accepts no responsibility for any damage that might result if this appliance is improperly installed, incorrectly operated, used for purposes other than that for which it is intended, or if it is repaired by unqualified persons.
Page 6 Example 1: The appliance is to be installed in a room that is 15 ft x 20 ft with 8 ft ceilings. There are no doorless passageways or vents between rooms, and there is a 40,000 Btu/hr gas wall heater in the room. Step 1: Total Btu/hr = 12,000 (this duraflame illuma appliance) + 40,000 (gas wall heater) = ®...
Page 7: Setup
Step 5: Compare the numbers: 84 (Step 4) is larger than 52 (Step 2), so the space is unconfined. You may install the appliance in the room. If your space is confined, additional ventilation air must be provided, either from within the building or from outside.
Page 8 Sliding Burner Cover Burner Slot Heat Shield Fuel Reservoir Tank Tray Burner Tube Sparker Piercer Handle Fuel Tank Bracket Screw-down Hole (Another hole on opposite side) Grate Burner / Base Ignition Button Figure 1 Appliance Overview Install this appliance in compliance with all local building codes. In the absence of local codes, use the latest edition of The National Fuel Gas Code (ANSZ223.1, also known as NFPA54), available from: American National Standards Institute...
Page 9: Minimum Firebox Dimensions
• Two (2) appliance base screws inside a small bag. • One AA battery. If components are missing, contact Duraflame Consumer Affairs. 2. Remove all these components from their packaging. When handling the logs, take care not to damage them. Keep packing materials away from children, as they could be a choking or...
Page 10 If after remedying both issues the sparker still does not create a spark, contact the installer, the store where you purchased the product or Duraflame, Inc. -10-...
Page 11 Figure 3 Figure 4 Logs Placement of Rear Log Figure 5 Figure 6 Placement of Front Log Showing space between tray and log inside wall on the left Figure 7 Figure 8 Showing space between tray All logs properly placed and log inside wall on the right -11-...
Page 12: Installing The Fuel Canister
Figure 9 Proper placement of front log with a gap between the back of the tray and the hinge plate VIII. INSTALLING THE FUEL CANISTER NOTE: Use only 1 liter duraflame illuma-fuel bio-ethanol canisters with this appliance. The ® ®...
Page 13 The burner should light. If it does not, hold down the igniter button until it does. You may need to wait a minute or so to allow the duraflame illuma-fuel to drain into the burner reservoir. Initially, the flames might be low with a bluish hue. The flames should grow in height and become yellow and orange as the fuel heats up.
Page 14: Refueling
4. To extinguish the flames, grasp the handle of the snuffer device, and slide the cover forward over the burner slot. The slot must be completely covered to extinguish the flames. This appliance can be relit at any time—even immediately after extinguishing, if desired, using the igniter.
Page 15: Adjustments
4. Install a new canister as described above (see INSTALLING THE FUEL CANISTER, Steps 2 and 3). 5. After the canister has been installed, close the door of the front log. The appliance is now ready for continued use. 6. If the flame is out by this time, use the igniter to start it again. *NOTE: Burn times will vary depending on conditions such as temperature, draft and how level the surface is.
Page 16 2. Metal components of the appliance should be cleaned using a damp cloth and a mild dish detergent. Never use abrasive cleaners, as they can damage the metal. 3. Remove the logs carefully. 4. Lift out the piercer and clean underneath. 5.
Page 17: Troubleshooting
XIII. TROUBLESHOOTING Use the following guide to solve any problems you might encounter in operating this appliance. PROBLEM SOLUTION 1. You see fuel on the ground near the • DO NOT light the burner. Extinguish any appliance. open flame near the spill. Wipe up the spill, and wait several minutes for the residue to evaporate.
Page 18: Parts List
XIV. PARTS LIST Part Number 61001 Burner / Base 61002 Igniter 61003 Front Log 61004 Back Log 61005 Left Small Log 61006 Right Small Log 61007 Canister Tray & Piercer 61008 Heat Shield 61009 Grate 61010 Masonry Screws -18-...
Page 19: Warranty
Correction in the manner provided above shall constitute a fulfillment of all liabilities of Duraflame, Inc. with respect to the quality of the product. The product MUST be installed by a person capable of following all instructions in accordance with all local codes and instructions furnished with the unit.
Page 20 This warranty gives you specific legal rights, and you may also have other rights that vary from state to state. For information about this warranty write to: Attn: Consumer Affairs, Duraflame, Inc., 2894 Monte Diablo Ave., Stockton, CA 95203, www. duraflame.com -20-...
