Summary of Contents for Sineoji PL504E

  • Page 1 User Manual PL504E 500Mbps 4-Port HomePlug AV...
  • Page 2 Safety This equipment has been tested and found to comply with Part 15 Class B of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment is in compliance with the requirements of the following regulations: CE Mark, 89/336/EEC RoHS This product is RoHS compliant.

  • Page 3: Table Of Contents

    Table of Contents HomePlug power line..........................4 System Diagram............................4 Casing Details ...............................5 Front Casing ......................................5 Status Lights......................................5 Bottom Casing ......................................6 Left Casing and Buttons ..................................6 Initial Setup ..............................7 Connect the 500Mbps HomePlug AV 4-Port Fast Through to a Computer or Modem/Router..............7 Individual HomePlug AV Network Setup (Optional) ................8 Creating a new individual HomePlug AV network (Network AB) ..............8 Adding Bridge C to existing Network AB (Network ABC)................9...

  • Page 4: Homeplug Power Line

    Add high-speed Internet access to any room in your home with this HomePlug AV Ethernet Bridge. You can stream HD movies and music, play online multi-player games and much more. The best part of this PL504E has built-in 4 ports so up to 4 network enabled devices nearby can be networked at the same time.

  • Page 5: Casing Details

    1.3 Casing Details Front Casing The front casing contains 3 types of status lights: Power, PLC Link, and Ethernet Link Port 1 ~ 4. Power Light PLC Link Light 4 Ethernet Link Light Status Lights Power On: This HomePlug Ethernet Bridge is receiving electrical power Off: Power off Flashing Green ( 1 second ON, 4 second OFF ) : Device in standby mode.

  • Page 6: Bottom Casing

    Bottom Casing The bottom casing contains 4 Ethernet ports. Ethernet Ports Left Casing and Buttons The left casing contains a recessed Reset button, a Security button. Reset button Security button Security This button is designed to generate an individual HomePlug AV network group under multiple nodes environment. Please refer to the optional Individual HomePlug AV Network Setup section below for more details.

  • Page 7: Initial Setup

    Initial Setup HomePlug is a plug and play device; user is able to plug and play without any complex configuration and settings. You can use HomePlug AV Ethernet Bridge to connect networkable devices like computers and game consoles di- rectly to each other. You can also connect devices like a computer or Blu-ray Disc™ player to a router or modem for Internet access.

  • Page 8: Individual Homeplug Av Network Setup (Optional)

    2 Individual HomePlug AV Network Setup (Optional) All HomePlug AV Ethernet Bridges ship with a default security key so they will automatically link to all other Home- Plug AV Ethernet Bridges sharing the same electrical lines. If there are other HomePlug AV Ethernet Bridges in the building (such as in an office or apartment building), you may want to create your own individual HomePlug AV network group so other HomePlug AV Ethernet Bridges cannot connect to your network.

  • Page 9: Adding Bridge C To Existing Network Ab (Network Abc)

    2.2 Adding Bridge C to existing Network AB (Network ABC) One unassociated Bridge C is added to an existing Network AB. The procedure is as follows: 1. Press and hold the security button on Bridge A for 2 seconds. The Power light on Bridge A starts to flash. 2.

  • Page 10: Removing Bridge B From Bridge A & C Network And Join With Bridge D & E (Network Bde)

    2.3 Removing Bridge B from Bridge A & C Network and join with Bridge D & E (Network BDE) The procedure is as follows: 1. Press and hold the Reset button on Bridge B for 2~3 seconds, then release. The password to Bridge B has just been set to default setting and removes itself from Bridge A &...
  • Page 11 Ethernet Bridges to link the different circuits together. This will allow the HomePlug AV Ethernet Bridges from different circuit breaker boxes to connect.

  • Page 12: Specification

    4 Specification Main Chipset Qualcomm Atheros AR7420 Computer Interface IEEE802.3 ; IEEE802.3u ; IEEE802.3ab ; IEEE1901/HomePlug AV Data PHY Rate Up to 500Mbps Standards HomePlug AV Network Interface Four RJ-45 (10/100Base-T Ethernet) One 500Mbps Power Line Port supporting co-existence with HomePlug 1.0 (14/85Mbps) Security 128-bit AES Link Encryption with Key Management...
