ViewSonic N5 Specifications page 2

High-resolution TV tuner
1 2 3
1. 4.
Headphone Jack
2. 5.
Input
3.
Volume Set
1 2
5 6 7 8 9 10
1. 6.
Component Video
2. 7.
RF In
3. 8.
RGB Output
4. 9.
RGB Input
5. 10.
DC In
ViewSonic recommends any of its CRT
and LCD displays be used with the N5
for the ultimate TV experience.
ViewSonic Corporation • 381 Brea Canyon Road, Walnut, CA 91789
Phone (800) 888-8583 or (909) 444-8888 • In Canada (866) 262-1967 • Fax (909) 839-7922 • SalesInfo@ViewSonic.com • ViewSonic.com
*Parental control, closed caption and MTS/SAP may not be available in all regions. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete details. Corporate names, trademarks stated herein are the property of their
respective companies. Copyright © 2004 ViewSonic Corporation. All rights reserved. [11753-00B-02/04]
For more product information, visit us on the web at ViewSonic.com
N5 TV/Video Processor
TV TUNER AND VIDEO PROCESSOR WITH V-CHIP
ANTENNA/
CABLE (RF)
INPUT SIGNAL
VIDEO OUTPUT Bit Performance 24-bit RGB 700mV±10%
4 5
Channel Select
OUTPUT MODE Resolution
Power (excluding RGB
pass-through)
3 4
AUDIO OUTPUT MTS*
POWER
CONNECTOR
Audio Out
Audio In
CONTROLS
Audio In (l/r)
Video In
S-Video Input
OPERATING
CONDITIONS
REGULATIONS
ACCESSORIES
ViewSonic Corporation's QMS & EMS have been registered to
ISO 9001 & ISO 14001, respectively, by the British Standards Institution.
Tuner FI1236MK2 (North America)
Freq Range 55.25–801.25 MHz
Numbers of Channels 2–69 off air
2–125 NTSC cable
Type RF, component video (YPbPr), S-video, composite (RCA),
RGB pass-through
3.5mm mini stereo audio in, and RCA (left/right) audio in
(excluding RGB pass-through)
640x480 @ 60Hz/75Hz
Refresh rate 800x600 @ 60Hz/75Hz
852x480 @ 60Hz
(Integrated or
1024x768 @ 60Hz/75Hz
progressive scan)
1280x768 @ 60Hz
1280x1024 @ 60Hz
Mono/stereo/SAP (available in RF mode)
Input 120V AC, 60Hz
Output 12V DC, 1.2 A
Type Power adapter
Signal F connector for RF, 3.5mm mini stereo jack for audio in
and audio out. RCA left/right for audio in, component
video (YPbPr), S-video, composite (RCA), 15-pin mini D-
sub for RGB input and RGB output, front headphone
3.5mm
Power DC-in jack
Basic Power, input, channel +/- and volume +/-
OnView ® Contrast, brightness, saturation, sharpness, hue, MTS, OSD
language (English, Spanish, French, traditional Chinese),
resolution, refresh rate, input signal, tuner input (antenna,
CATV std, CATV HRC, CATV IRC), sleep, autoscan, channel
add/remove, parental control (rating selection and
password), closed caption
Remote Control 28-key IR remote control. Power, volume +/-, channel +/-,
four navigation arrows, select, menu, enter, mute, input,
PC/TV, channel scan, display, recall, 10 numbering keys.
Temperature 0–40° C (32–104° F)
Humidity 5–90%, non-condensing
Altitude -150–12,000 feet above sea level
UL, cUL, FCC Class B
Included Power adapter, VGA extension cable, 3.5mm mini stereo
cable, A/V cable, user's guide, remote control with one
lithium battery.
