Wireless Keychain
Remote Control
Model 3150C
Operating Instructions and
Owner's Manual
Control Garage Door Opener
and HomeSettings System
from your car
Thank you for purchasing the 3150C Wireless Keychain Remote Control. HomeSettings products by
Wayne-Dalton allow you to control your home by remote control. You can create a complete Home Control
and Access Network by combining your Wireless Keychain Remote Control with other
HomeSettings products. Indoor and outdoor lighting, security systems, garage door openers, and
thermostats are just a few of the items you can easily control with additional HomeSettings products.
Your new Wireless Keychain Remote Control is compatible with Wayne-Dalton garage door openers,
the Garage Door Opener Conversion Module and the Wireless Gateway to give you control of Z-Wave™
enabled modules.
Home Control Basics
HomeSettings products will allow you to easily control multiple devices in a home with the push of a button
in what is known as a "scene". Turning on all of the lights as you come home is an example of a scene.
Dimming lights and closing your curtains to watch TV, it's also a scene.
Visit www.wayne-dalton.com/access to get ideas on how to create scenes with your Remote Control and
other Z-Wave™ enabled HomeSettings products.
PACKAGE CONTENTS
Manual
User
Package Content ....................................................................................................... 1
Warnings and Glossary ............................................................................................. 2
Setup .....................................................................................................................3-4
Examples .................................................................................................................. 5
Advanced Features ................................................................................................... 6
Troubleshooting .....................................................................................................6-7
Compliance .............................................................................................................. 8
Look for the
3150C Transmitter
Table of Contents
Quick
symbol for basic instructions.
Sta rt
Visor Clip
Key Chain Ring
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 3150C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Wayne-Dalton 3150C

  • Page 1 Thank you for purchasing the 3150C Wireless Keychain Remote Control. HomeSettings products by Wayne-Dalton allow you to control your home by remote control. You can create a complete Home Control and Access Network by combining your Wireless Keychain Remote Control with other HomeSettings products.
  • Page 2 GLOSSARY Copy – See Replicate. Delete – Erase transmitter or SCENE information from Controller. Also known as Exclude. Device – Any item that is connected to a module (for example, lamps). Exclude – Remove a module from the controller. Include – Add a module to the controller. Module –...
  • Page 3 Quick Sta rt Programming to Operator NOTE: Any of the three transmitter buttons TRANSMITTER can be programmed to activate the door. In BUTTONS multi-door installations, each button can be programmed to activate a separate door. Only one button at a time (per-transmitter) can be programmed to activate a door.
  • Page 4 Programming to Conversion Module Use the following procedure to program the Program Button Wireless Keychain Remote transmitter button to a Wayne-Dalton Garage Door Opener Conversion Module, Model WDRR-372R. This module will allow your Keychain Remote Control to operate any brand Garage Door Opener.
  • Page 5 Wireless Gateway can be used. For further ideas, please visit our website at www. Examples require the following modules: wayne-dalton.com/access. 1. Approaching your home in your car, you wish 1 - Wireless Gateway, WDHA-12R to turn on the outside lights near the garage,...
  • Page 6 Button Combinations Use this procedure to program your Keychain Remote for up to 6 actions. In any of the previous programming instruc- tions at the point where you need to activate a transmitter button to complete the programming step, simply simultaneously press a combina- tion of any two buttons.
  • Page 7 Troubleshooting Problem: The Wayne Dalton Wireless Gateway can be activated by up to 12 transmitter programs. • One of my Wireless Gateway SCENES is not When exceeded the last one programmed will be working. dropped. • My operator no longer works with my remote. The Wayne Dalton operator can be activated by up to six remote control devices (including wall station and keyless entry controls).
  • Page 8 © Copyright 2007 Wayne-Dalton Corp. Part No.0001766 RevA New 08/27/07 You can reach us via email at homesettings@wayne-dalton.com for Consumer Assistance or online at www.wayne-dalton.com/access...
