Topeak BabySeat II User Manual

Suspension child carrier
Hide thumbs

Advertisement

Table of Contents

BabySeat II
User's Guide
GB
Suspension Child Carrier
It is recommended a professional bicycle shop assemble and
install the BabySeat II to your bike.
It is imperative that you read this owner's manual prior to installation.
Load Class: A22 (22kgs/48.5lbs)
TOOLS REQUIRED FOR ASSEMBLY:
5mm Allen Key
Topeak Babyseat II
Art No. TCS-2201 /TCS-2202
EN 14344

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BabySeat II and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Topeak BabySeat II

  • Page 1 User's Guide Suspension Child Carrier It is recommended a professional bicycle shop assemble and install the BabySeat II to your bike. It is imperative that you read this owner's manual prior to installation. Load Class: A22 (22kgs/48.5lbs) TOOLS REQUIRED FOR ASSEMBLY:...

  • Page 2: Table Of Contents

    Table of Contents Getting To Know Your Topeak BabySeat Mounting Rack To Bicycle Mounting BabySeat To Rack Surface Securing BabySeat To Seat Post Opening Grab Bar Adjusting Height Of Footrests Fitting Your Child In BabySeat Release Seat Pad Caution Notes...
  • Page 3 Mounts Mounts to to rack rack Mounts to bicycle Mounts to bicycle...

  • Page 4: Getting To Know Your Topeak Babyseat

    Getting To Know Your Topeak BabySeat These pages will help you to identify the different parts of your Topeak BabySeat. ILLUSTRATED PARTS LIST: 1. SEAT 9. SLIDE LOCK WITH BUTTON (in storage position) 2. RACK 10. REFLECTOR 3. GRAB BAR 11.

  • Page 6: Mounting Rack To Bicycle

    Mounting Rack To Bicycle Follow these illustrations for mounting rack to bicycle. Make sure rack is level with ground before tightening hardware. Several adjustments are available to help level rack. Slide rack hardware forward or back to determine correct positions before tightening Philips screws on rack surface.
  • Page 7 CAUTION The Topeak BabySeat is designed to work on frames with seatstay rack mounts AND threaded dropout eyelets only. Do not use the Topeak BabySeat on frames without these fittings for safety reasons. BabySeat Rack w/o disc Mounts M5 x 15mm...

  • Page 8: Mounting Babyseat To Rack Surface

    Mounting BabySeat To Rack Surface Mount BabySeat on rack Remove slide lock from storage position Click Hook seat onto front rail of rack. Rotate seat down on Press the red button and pull the slide lock back away from seat. rack surface until snapped into positive engagement.

  • Page 9: Securing Babyseat To Seat Post

    Securing BabySeat To Seat Post "T" type loop and hook strap is a safety device designed to connect BabySeat and seat post. Please be sure to fasten it to seat post immediately after mounting BabySeat on rack. The "T" strap should only be disconnected from seat post if removing BabySeat from rack.

  • Page 10: Opening Grab Bar

    Opening Grab Bar Lift up the lever Press tabs and lift to open grab bar as shown.

  • Page 11: Adjusting Height Of Footrests

    1. Have someone help support bicycle while placing child in BabySeat. 2. Place child in comfortable position in BabySeat II. Adjust and fasten safety harness over child. 3. Note position of child's feet and legs and tighten the foot straps after placing child in comfortable position.

  • Page 12: Fitting Your Child In Babyseat

    Fitting Your Child In BabySeat BabySeat shoulder buckle straps adjust in a high or low position. Make sure they are in the correct position for your child's size. Shoulder Strap Is Too High. High Position Shoulder Strap Is Too Low. Low Position CAUTION Make sure the buckle straps are assembled correctly on the back side of...

  • Page 13: Release Seat Pad

    Release Seat Pad Release the buckle strap from back side. Remove the fastener on the both sides of BabySeat. Release strap on the bottom of seat pad and release the buckle strap. Release the buckle strap from back side of seat pad and remove the seat pad from the back hook behind BabySeat.

  • Page 14: Caution Notes

    CAUTION Carry only a child who is able to hold his/her head up while wearing a correctly sized bicycle helmet. The age and weight limits for the BabySeat rack are 1~4 years old , and 20lbs~48.5lbs (9kgs ~ 22kgs) respectively. Never exceed these limits. Bicycle operator's age must be at least 18 years old.
  • Page 15 Ensure that the restraint system is not loose or able to become trapped in any moving parts particularly the wheels, including when the cycle is ridden without a child in the seat. Please connect your nearest Topeak authorized bicycle dealer if you found any broken or damage parts of the babyseat.
  • Page 16 Remove BabySeat II From Rack Press the yellow and red Remove the slide lock then buttons at the same time push into storage position Lift off BabySeat Please contact your Topeak dealer with any questions. For USA customer service call: 1-800-250-3068 www.topeak.com...
