Gentner TX-37A Specifications

T X - 3 7 A T r a n s m i t t e r
The TX-37A Transmitter is the core of Gentner Assistive
Listening Systems. The transmitter utilizes leveling multi-
band compression, peak limiting, and the patented Aphex
Aural Exciter ® to process audio for maximum
intelligibility and loudness. While other assistive listening
transmitters simply increase volume, Gentner's TX-37A
actually enhances the sound quality to increase audio
clarity at louder levels. It also eliminates the potential for
clipping and overmodulation.
The transmitter can be set to 37 different frequencies,
allowing you to use multiple transmitters in one location
while reducing the possibility for audio interference. This
is especially useful for education and simultaneous
translation applications. Its universal input stage accepts
audio from mic, line, or speaker levels producing
exceptional audio quality at all levels. Connection is made
to the existing audio system via a tape or mixer
auxiliary output.
The transmitter is designed with a compact, steel, 1/2
rack unit chassis. The shielded steel chassis protects the
unit from damage and keeps out hum as well as other
system noise. Gentner provides a rack mount kit* (sold
separately) to store the transmitter in a standard 1U
rack space.
Applications
• Theatrical productions, such as the
opera, ballet, symphony, and plays
• Concerts in auditoriums or stadiums
• Lectures in convention centers
• Outdoor, sporting events
• Church services
Assistive Listening Systems
Transmitters
Gentner 's TX-37A actually enhances the sound
quality to increase audio clarity at louder leve l s .
Features and Benefits
• Only transmitter to combine multiband compression,
automatic gain control, and peak limiting so there is no
clipping or overmodulation
• Superior overall sound quality, and dynamics control
• Transmits to an area of more than 700,000 square feet,
so the TX-37A is low cost for large venues
• Easily connects to any source—universal input stage
provides input for mic, line, or speaker level, balanced
or unbalanced
• Field selectable channels (37) with digital tuning for
lower risk of interference
• Built-in test tone aid for quick and easy receiver tuning
• Supplied with flex antenna, remote mount, and 50'
RG174 type cable
• Audio input level meter for visible indication of audio
input and levels
• Adjustable RF level allows control of RF coverage
• Rugged steel chassis for enhanced RF quality
• Audio monitor jack with volume control
®
• Aphex
• Wide area FM system works outdoors in bright light,
no line of sight restrictions
* single rack mount kit
processing for increased intelligibility
