Cisco ONS 15530 Hardware Installation Manual

Hide thumbs Also See for ONS 15530:

Advertisement

Quick Links

Note
Cisco ONS 15530 Chassis
78-14228-02
7 A u g u s t
Cisco ONS 15530 Overview
The Cisco ONS 15530 is a modular and scalable optical switching and
aggregation platform designed to supplement the Cisco ONS 15540 ESP. With the
Cisco ONS 15530, users can take advantage of the availability of dark fiber to
build a common infrastructure that supports data, SAN (storage area network),
and TDM (time-division multiplexing) traffic. For more information about
DWDM technology and applications, refer to the Introduction to DWDM
Technology publication and the Cisco ONS 15530 Planning and Design Guide.
The Cisco ONS 15530 is designed to meet or exceed stringent ISP (Internet
service provider) requirements for product availability and reliability.
Before you install, operate, or service the system, read the Regulatory
Compliance and Safety Information for the Cisco ONS 15500 Series for important
safety information you should know before working with the system.
This chapter includes the following sections:
Cisco ONS 15530 Chassis, page 1-1
Cisco ONS 15530 Components, page 1-11
The Cisco ONS 15530 is available in two configurations. Both have two vertically
stacked half-height slots specifically for the optical OADM (optical add drop
multiplexing) modules, and 10 vertically oriented slots that hold the CPU switch
2 0 0 3
C H A P T E R
Cisco ONS 15530 Hardware Installation Guide
1
1-1

Advertisement

Table of Contents
loading

Summary of Contents for Cisco ONS 15530

  • Page 1 The Cisco ONS 15530 is a modular and scalable optical switching and aggregation platform designed to supplement the Cisco ONS 15540 ESP. With the Cisco ONS 15530, users can take advantage of the availability of dark fiber to build a common infrastructure that supports data, SAN (storage area network), and TDM (time-division multiplexing) traffic.
  • Page 2 WE R SU PPL FAI L GO OD 100 -24 0V 8.0- 3.5A 50- 60H Z The chassis configurations differ in how cooling air is routed through the chassis and where the lifting handles are placed. Cisco ONS 15530 Hardware Installation Guide 78-14228-02...
  • Page 3 7 A u g u s t 2 0 0 3 Cisco ONS 15530-CHAS-E Chassis The dimensions of the Cisco ONS 15530 CHAS-E chassis are 14.4 x 17.3 x 10.1 inches (H x W x D) See Figure 1-2. Handles for lifting the chassis are located on the sides.
  • Page 4 Cisco ONS 15530 Chassis 7 A u g u s t 2 0 0 3 The air ramp baffle for the Cisco ONS 15530 CHAS-E chassis redirects the cooling air intake as shown in Figure 1-4. The air ramp baffle must be installed when installing the Cisco ONS 15530 CHAS-E type chassis.
  • Page 5 Air ramp baffle intake Bottom Cisco ONS 15530 CHAS-N Chassis The dimensions of the Cisco ONS 15530 CHAS-N chassis are 14.4 x 15.7 x 10.1 inches (H x W x D). (See Figure 1-5.) Handles for lifting the chassis are located on the top.
  • Page 6 Chapter 1 Cisco ONS 15530 Overview Cisco ONS 15530 Chassis 7 A u g u s t 2 0 0 3 Figure 1-5 Cisco ONS 15530 CHAS-N Chassis Cisco ONS 15530 Hardware Installation Guide 78-14228-02...
  • Page 7: Fan Assembly

    Fan assembly Bottom Fan Assembly The Cisco ONS 15530 fan assembly is located at the bottom of the chassis. The assembly contains six individual fans and a fan controller board (see Figure 1-8). The controller board monitors the status of each fan and reports the status to the CPU switch modules.
  • Page 8 7 A u g u s t 2 0 0 3 Figure 1-7 Fan Assembly LED Fan assembly Table 1-1 Fan Assembly Status Fan Failure Status None Green Normal Yellow Minor Two or more Major Cisco ONS 15530 Hardware Installation Guide 78-14228-02...
  • Page 9: Power Supplies

    7 A u g u s t 2 0 0 3 Figure 1-8 Fan Assembly Power Supplies The Cisco ONS 15530 chassis supports redundant 120–240 VAC (see Figure 1-9) or –48 VDC (see Figure 1-10) power. The power supplies are located at the right...
  • Page 10 8.0- 3.5A 50-60 HZ Figure 1-10 –48 VDC Power Supply FAIL GOOD -48 TO -60V 17/A See the “Powering Up the Shelf” section on page 2-47 for more information about the power supplies. Cisco ONS 15530 Hardware Installation Guide 1-10 78-14228-02...
  • Page 11: Table Of Contents

    Cisco ONS 15530 Components The following hardware components can be installed in the Cisco ONS 15530: CPU Switch Modules, page 1-12 •...
  • Page 12: Cpu Switch Modules

    2 0 0 3 CPU Switch Modules The Cisco ONS 15530 supports two CPU switch modules for redundancy, one in active mode and the other in hot-standby mode. CPU switch modules are installed in slot 5 and slot 6. Each CPU switch module has a processor, a switch fabric, a...
  • Page 13 Chapter 1 Cisco ONS 15530 Overview Cisco ONS 15530 Components 7 A u g u s t 2 0 0 3 Figure 1-11 Cisco ONS 15530 CPU Switch Module Cisco ONS 15530 Hardware Installation Guide 1-13 78-14228-02...
  • Page 14 A system wide critical alarm exists. MAJOR Yellow A system wide major alarm exists. MINOR Yellow A system wide minor alarm exists. HIST Yellow A system wide major or minor alarm has occurred. Cisco ONS 15530 Hardware Installation Guide 1-14 78-14228-02...
  • Page 15 Green Module is running full-duplex. Module is running half-duplex. 100MBPS Green Module is running at 100 Mbps. Module is running at 10 Mbps. LINK Green Link is up. Link is down. Cisco ONS 15530 Hardware Installation Guide 1-15 78-14228-02...
  • Page 16 CompactFlash Card Slot A CompactFlash card slot (see Figure 1-11) can store the Cisco IOS image or a system configuration file on a CompactFlash memory card. The system can also boot from the software stored on the CompactFlash memory card.
  • Page 17: Osc Modules And Carrier Motherboards

    33rd wavelength (channel 0), the OSC allows control and management traffic to be carried without requiring a separate Ethernet connection to each Cisco ONS 15530 in the network. Up to two OSC modules can be installed in the carrier motherboard, one module for the west direction and one for the east direction.
  • Page 18: Psm

    A PSM can be installed in subslots 0/0 and 0/1 of the Cisco ONS 15530 chassis. The PSM for the Cisco ONS 15530 has a front panel with four MU connector...
  • Page 19 Cisco ONS 15530 Components 7 A u g u s t 2 0 0 3 Figure 1-13 PSM Rx/Tx West ports Rx/Tx East ports East/West LEDs East/West Optical Monitor ports Common In/Out ports Cisco ONS 15530 Hardware Installation Guide 1-19 78-14228-02...
  • Page 20: Transponder Line Cards

    ITU wavelength, or channel. The transponder line cards have tunable lasers and you can configure the line cards to work in two different wavelengths. The Cisco ONS 15530 holds up to four transponder line cards, one for each wavelength supported by the OADM modules.
  • Page 21 Chapter 1 Cisco ONS 15530 Overview Cisco ONS 15530 Components 7 A u g u s t 2 0 0 3 Figure 1-14 Transponder Line Card LEDs (Nonsplitter) Cisco ONS 15530 Hardware Installation Guide 1-21 78-14228-02...
  • Page 22 Callout Description Callout Description Card status LED Client side transmit LED ITU side port Client side transmit port ITU transmit LED Client side receive LED ITU receive LED Client side receive port Cisco ONS 15530 Hardware Installation Guide 1-22 78-14228-02...
  • Page 23 7 A u g u s t 2 0 0 3 Figure 1-15 Transponder Line Card LEDs (Splitter) W ITU TX W ITU RX E ITU TX E ITU RX 1310 TX 1310 RX Cisco ONS 15530 Hardware Installation Guide 1-23 78-14228-02...
  • Page 24 Yellow System clock is not present. EAST Green Card is listening to the east side signal. TX (Trunk port) Green Port is up and transmit laser is enabled. Cisco ONS 15530 Hardware Installation Guide 1-24 78-14228-02...
  • Page 25: Optical Add Drop Multiplexing Modules

    ITU wavelengths. The OADM modules supported by the Cisco ONS 15530 each add and drop a specified band of four channels at a node and pass the other bands through. To support the 32-channel spectrum, there are...
  • Page 26: Wide-Band Variable Optical Attenuator And Per-Band Optical Equalizer Modules

    Equalizer Modules The WB-VOA (wide-band variable optical attenuator) and PB-OE (per-band power equalizer) modules are half-width modules that allow the ONS 15530 to extend the internodal and ring circumference distances and number of nodes supported for point-to-point, hub ring, and mesh ring networks by equalizing power levels.
  • Page 27 These modules are installed into a carrier motherboard. This motherboard is installed into and operates on the Cisco ONS 15530 chassis. The carrier motherboard can be installed in slots 1 to 4 or 7 to 10. All optical connectors are located on the front panel and the connectors are angled.
  • Page 28 Light reception exists at the port. Green Card is properly initialized. Figure 1-18 Dual WB-VOA Module Callout Description Callout Description PM2 LED OUT1 port PM1 LED Handle Card status LED IN2 port IN1 port OUT2 port Cisco ONS 15530 Hardware Installation Guide 1-28 78-14228-02...
  • Page 29 Light reception exists at the port. STATUS Green Card is properly initialized. Figure 1-19 Single-Band PB-OE Module Callout Description Callout Description PM1 LED OUT port Card status LED UPG IN port IN port UPG OUT port Handle Cisco ONS 15530 Hardware Installation Guide 1-29 78-14228-02...
  • Page 30 Card is properly initialized. Figure 1-20 Dual-Band PB-OE Module PM2 PM1 STA Callout Description Callout Description PM2 LED Handle PM1 LED OUT port Card status LED UPG IN port IN port UPG OUT port Cisco ONS 15530 Hardware Installation Guide 1-30 78-14228-02...
  • Page 31: Escon Aggregation Cards

    SFPs (small form factor pluggables) and MT-RJ connectors for the client signals. (See Figure 1-21.) The SFPs (part number 15500-XVRA-01A2 ONS 15530 ESCON-1310nm Note MM-MTRJ) must be purchased separately. A patch cable to adapt MT-RJ connectors to standard ESCON connectors directly Note or intermediately to SC-type connectors may be required.
  • Page 32 Chapter 1 Cisco ONS 15530 Overview Cisco ONS 15530 Components 7 A u g u s t 2 0 0 3 Figure 1-21 Cisco ONS 15530 ESCON Aggregation Card Cisco ONS 15530 Hardware Installation Guide 1-32 78-14228-02...
  • Page 33: 8-Port Fc/Ge Aggregation Cards

    Light reception exists at the port. 8-Port FC/GE Aggregation Cards The Cisco ONS 15530 supports a line card specifically for FC (Fibre Channel) and GE (Gigabit Ethernet) traffic. The 8-port Fibre Channel/Gigabit Ethernet aggregation card accepts up to eight SFP (small form-factor pluggable) optics for client traffic.
  • Page 34 Channel (1 Gbps) 1. 1000BaseSX 2. FC-0-100-M5-SN-S and FC-0-100-M6-SN-S standards 3. 1000BaseLX 4. FC-0-100-SM-LC-S standard The Cisco ONS 15530 supports up to four 8-port FC/GE aggregation cards for a total of 32 client signals. Cisco ONS 15530 Hardware Installation Guide 1-34 78-14228-02...
  • Page 35 Chapter 1 Cisco ONS 15530 Overview Cisco ONS 15530 Components 7 A u g u s t 2 0 0 3 Figure 1-22 8-Port FC/GE Aggregation Card Cisco ONS 15530 Hardware Installation Guide 1-35 78-14228-02...
  • Page 36: 2.5-Gbps Itu Trunk Cards

    OADM module, and can be used for unprotected, line card protected, or switch fabric protected applications. The card supports 32 channels as shown in Table A-2 on page A-3. Cisco ONS 15530 Hardware Installation Guide 1-36 78-14228-02...
  • Page 37 Cisco ONS 15530 Components 7 A u g u s t 2 0 0 3 Figure 1-23 2.5-Gbps ITU Trunk Card (Splitter) W ITU TX W ITU RX E ITU TX E ITU RX Cisco ONS 15530 Hardware Installation Guide 1-37 78-14228-02...
  • Page 38 7 A u g u s t 2 0 0 3 Card status LED Receive LED West side port LED East side port LED West side port East side port Transmit LED Cisco ONS 15530 Hardware Installation Guide 1-38 78-14228-02...
  • Page 39 Cisco ONS 15530 Components 7 A u g u s t 2 0 0 3 Figure 1-24 2.5-Gbps ITU Trunk Card (Nonsplitter) W ITU TX W ITU RX E ITU TX E ITU RX Cisco ONS 15530 Hardware Installation Guide 1-39 78-14228-02...
  • Page 40: 10-Gbps Itu Trunk Cards

    OADM modules, and is designed for splitter protected applications (see Figure 1-26). The Cisco ONS 15530 supports up to four 10-Gbps ITU trunk cards for a total of four channels. Cisco ONS 15530 Hardware Installation Guide 1-40...
  • Page 41 Chapter 1 Cisco ONS 15530 Overview Cisco ONS 15530 Components 7 A u g u s t 2 0 0 3 Figure 1-25 10-Gbps ITU Trunk Card (Nonsplitter) Cisco ONS 15530 Hardware Installation Guide 1-41 78-14228-02...
  • Page 42 Chapter 1 Cisco ONS 15530 Overview Cisco ONS 15530 Components 7 A u g u s t 2 0 0 3 Card status LED Transmit LED ITU port Receive LED Cisco ONS 15530 Hardware Installation Guide 1-42 78-14228-02...
  • Page 43 Cisco ONS 15530 Components 7 A u g u s t 2 0 0 3 Figure 1-26 10-Gbps ITU Trunk Card (Splitter) W ITU TX W ITU RX E ITU TX E ITU RX Cisco ONS 15530 Hardware Installation Guide 1-43 78-14228-02...
  • Page 44: 10-Gbps Uplink Cards

    Figure 1-27, sends and receives a 10-GE 1310-nm signal to and from a 10-GE uplink card on another Cisco ONS 15530, or to and from a 10-GE transponder module on a Cisco ONS 15540 ESP or Cisco ONS 15540 ESPx. This card accepts up to four (3.125-Gbps line rate) electrical signals from 10-port ESCON aggregation cards and 8-port FC/GE aggregation cards, and combines them into one 10-GE signal.
  • Page 45 Cisco ONS 15530 Overview Cisco ONS 15530 Components 7 A u g u s t 2 0 0 3 The Cisco ONS 15530 supports up to four 10-Gbps uplink cards for a total of four signals. Cisco ONS 15530 Hardware Installation Guide 1-45...
  • Page 46 Chapter 1 Cisco ONS 15530 Overview Cisco ONS 15530 Components 7 A u g u s t 2 0 0 3 Figure 1-27 10-Gbps Uplink Card Cisco ONS 15530 Hardware Installation Guide 1-46 78-14228-02...
  • Page 47 10-Gbps uplink line card LED status. Table 1-16 10-Gbps Uplink Line Card LEDs Status Description STATUS Green Card is properly initialized. Green Port is up and transmit laser is enabled. Green Light reception exists at the port. Cisco ONS 15530 Hardware Installation Guide 1-47 78-14228-02...
  • Page 48 Chapter 1 Cisco ONS 15530 Overview Cisco ONS 15530 Components 7 A u g u s t 2 0 0 3 Cisco ONS 15530 Hardware Installation Guide 1-48 78-14228-02...
