2.1 - Functional description

The ADR 155C is an optical STM1 add-drop multiplexer used to build STM-1 point-to-point links,
STM-1 rings, or mesh networks, so achieving the mismatch of links at 2 Mbit/s, Ethernet or
STM1.
The ADR 155C can also be connected to an equipment of the synchronous digital hierarchy in
accordance with UIT-T recommendations G.707 and G.783.
The ADR 155C modelling in functional blocks according to standard G.783 is presented below:
RST : Regeneration Section Termination
HPOM : Higher order Path Overhead Monitor
LUG : Lower order path Unequipped Generator
LPOM : Lower order Path Overhead Monitor
LPA Lower order Path
Adaptation (VC12)
PPI : plesiochronous physical
Interface (VC12)
No reproduction or communication without the written consent of SAGEM SA
SPI : SDH Physical Interface
MST: Multiplex Section Termination
MSP : Multiplex Section Protection
MSA : Multiplex Section Adaptation
HPC : Higher order Path Connection
HPT : Higher order Path Termination
HPA : Higher order Path Adaptation
LPC : Lower order Path Connection
LPT : Lower order Path Termination
plesiochronous physical
Lower order Path
Adaptation (VC3)
Interface (VC3)
Installation and User Guide - N56717020101

2 - OPERATION

2. OPERATION
OHA : OverHead Access
SETS : Synchronous Equipment
Timing Source
SETPI : Synchronous Equipment
Timing Physical Interface
SEMF : Synchronous Equipment
Management Function
MCF : Message
Communication Function
