- Page 1 LCD Monitor Series 19.0 TFT Active Matrix LCD Panel 194X Series User’s Manual All Information in this manual may change from time to time without prior notice.
-
Page 2: Table Of Contents
19.0 TFT Active Matrix LCD Panel User Manual Table of Content Table of Content .................. …2 Safety Instructions................…3 View of Monitor ..................4 Unpacking....................6 Warning....................6 Cleaning Notes..................7 Precaution ....................7 Features ....................7 Hardware Installation................8 Hardware Installation Step by Step ............ -
Page 3: Safety Instructions
19.0 TFT Active Matrix LCD Panel User Manual Safety Instructions Please read these safety instructions carefully. Please keep this User‘s Manual for later reference. Please disconnect this equipment from connecter before cleaning. Don‘t use liquid or sprayed detergent for cleaning. Use moisture sheet or cloth for cleaning. -
Page 4: View Of Monitor
19.0 TFT Active Matrix LCD Panel User Manual View of Monitor Front View Type 1 (1) Front View Type 2 (2) English 4... - Page 5 19.0 TFT Active Matrix LCD Panel User Manual View of Monitor Back View (3) Side View (4) English 5...
-
Page 6: Unpacking
19.0 TFT Active Matrix LCD Panel User Manual Unpacking Thank you for your purchase. Please first check the following package content of the 19” LCD monitor. Contact your dealer or store where you purchased the LCD monitor if anything is missing. 19”... -
Page 7: Cleaning Notes
19.0 TFT Active Matrix LCD Panel User Manual Cleaning Notes Be gentle to clean the screen. Never use any kind of corrosiveness chemical dissolvent to clean the screen, it may hurt your screen surface. We suggest that a camel hair brush or a soft, lint-free cloth be used to clean the screen. -
Page 8: Hardware Installation
19.0 TFT Active Matrix LCD Panel User Manual Hardware Installation Be careful to your LCD monitor. It’s very delicate and easy to break. Turn off LCD’s and PC’s power before installation. Follow the installation step by step described below. Input 【1】... -
Page 9: Hardware Installation Step By Step
19.0 TFT Active Matrix LCD Panel User Manual Hardware Installation Step by Step 1. Get ready with your Quick-Stand and hold your monitor firmly but gentle with your hands and let the panel facing you to pedestal the monitor on the Quick-stand. -
Page 10: How To Remove Quick-Stand Of Monitor
19.0 TFT Active Matrix LCD Panel User Manual Hardware Installation Step by Step Connect the audio cable to AUDIO-IN on the monitor, and the other side to computer line out. 5. Plug power cord onto the Power jack of the monitor. 6. -
Page 11: Monitor Setup Button
19.0 TFT Active Matrix LCD Panel User Manual Monitor Setup Button Menu control button Down OSD Menu Power Auto Adjust There 5 keys for user to set up the monitor, including “Power”, “MENU “, “AUTO”, ” <-> Down”, ” <+> Up”. Please refer to the introduction below. “Power”: Turn the LCD power on and off. -
Page 12: Troubleshooting
19.0 TFT Active Matrix LCD Panel User Manual Troubleshooting If you encounter any trouble in using the monitor, make sure your monitor is properly installed according to the following steps before you call for service. ˙ There is no picture on the screen. Check: 1. - Page 13 19.0 TFT Active Matrix LCD Panel User Manual OSD (On-Screen Display) Menu Mode (PC Mode) BRIGHTNESS: Adjust the difference between light and dark area. BRIGHTNESS COLOR ADJUST: Adjust the RED, GREEN, and BLUE colors of the display Click “ENTER” to adjust the R.G.B.
- Page 14 19.0 TFT Active Matrix LCD Panel User Manual OSD (On-Screen Display) Menu Mode (PC Mode) COLOR TEMP: Adjust the color temperature of the display COLOR TEMP BACK : Return to the Main Menu Screen BACK COLOCK: Adjust the re-flash ratio of the vertical scanning area.
- Page 15 19.0 TFT Active Matrix LCD Panel User Manual OSD (On-Screen Display) Menu Mode (PC Mode) AUTO ADJUST: Automatically adjust the re-flash ratio of both vertical and horizontal scanning areas of the display AUTO ADJUST H. POSITION: Adjust the horizontal viewing area of the display H.
- Page 16 19.0 TFT Active Matrix LCD Panel User Manual OSD (On-Screen Display) Menu Mode (PC Mode) OSD H. POS: Adjust the Horizontal position of the OSD OSD H. POS OSD V. POS: Adjust the Vertical position of the OSD OSD V. POS OSD TIME: Adjust the displaying time of the OSD OSD TIME...
- Page 17 19.0 TFT Active Matrix LCD Panel User Manual OSD (On-Screen Display) Menu Mode (PC Mode) OSD ALPHA: Adjust the Alpha volume of the OSD displaying OSD ALPHA BACK: Return to the Main Menu Screen BACK LANGUAGE: Change the language support to the language displaying of the OSD.
- Page 18 19.0 TFT Active Matrix LCD Panel User Manual OSD (On-Screen Display) Menu Mode (PC Mode) VOLUME: Adjust the sound volume of the embedded speaker of the display VOLUME MUTE: Silence the embedded speaker of the display MUTE BACK : Return to the Main Menu Screen BACK VGA / DVI: Switch to the VGA / DVI Signal inputs of...
-
Page 19: Display Mode
19.0 TFT Active Matrix LCD Panel User Manual Display Mode Incoming Display Mode Resolution Horizontal Frequency (KHz) Vertical Frequency (Hz) 720X400 (50Hz) 31.5KHz 50.0Hz 720X400 (60Hz) 31.5KHz 59.9Hz 720X400 (70Hz) 31.5KHz 70.1Hz 640X480 (50Hz) 31.5KHz 50.0Hz 640X480 (60Hz) 31.5KHz 59.9Hz 640X480 (66Hz) 35.0KHz 66.7Hz... -
Page 20: Specification
19.0 TFT Active Matrix LCD Panel User Manual Specification LCD Panel Type 19.0” TFT Active Matrix LCD Display Viewing Angle H:160° , V:150° Contrast Ratio 700:1(MAX) , 500 : 1(Typical) Brightness 250 cd/m (Typical) Response Time 8 ms(Typical) Display Colors 16.7M colors Max Resolution 1280X1024(SXGA) @75Hz...
