MODEL 2202

(1989 - MSRP $549.00)

OWNER'S OPERATION MANUAL AND

INSTALLATION GUIDE

INTRODUCTION

Power Supply: Self oscillating for reliability and efficiency. The transformer is

epoxy dipped for extreme vibration resistance. Banks of high-speed TO-3

switching transistors provide massive current reserves.

Output Stages: Transformerless, direct coupled and fully complimentary. Output

transistors are high current and low distortion TO-3 devices, operating at a

fraction of their limitations.

Protection: Our stable amplifier design is made virtually indestructible by three

protection circuits. One is a precision thermal protection circuit, which prevents

damage from high frequency oscillation, or an excessive ambient temperature.

The second protection circuit is a current sensing device guarding against

instantaneous abnormalities, such as short circuits. Both of these circuits

automatically reset. The third form of protection guards against component

damage from reversed power connections.

Construction Features: Our unique, variable input sensitivity control permits

optimal signal matching for lowest noise and lowest distortion with virtually any

source. All components used are rated for at least 150% of their intended use,

and are mounted on double-sided fiberglass epoxy circuit boards.

Quality Control: In-house construction of critical components like transformer

and chassis, as well as total assembly, allows LINEAR POWER™ to maintain

uniform quality. 100% of the finished units are tested, then burned in for four

hours, and tested again. Amplifiers, which pass this rigorous test, have truly

earned the LINEAR POWER™ logo.

LINEAR POWER™ is a trademark of Linear Power, Inc
