Konig CMP-PRESENT40 Instructions

CMP-PRESENT40
Wireless RF Presenter
I. Instruction of Smart Pointer
It consists of laser pointer, wireless mouse, and wireless keyboard. It is designed as a handy-tool for
presentation, teaching, meeting, speech, training that associated with computer applications.
Package Contents :
- Remote control
- USB receiver
- USB extension cable
Setup :
Plug the receiver to the USB port of PC. The system will automatically search for the suitable driver,
please follow the instruction when prompted.
CAUTION :

keep the area in front of the receiver.

if the USB port is at the rear of PC, use the extension cable provided to reposition it.
II. Function :
A) When the switch is put on "KEYBOARD", it functions as a wireless keyboard as below :

Laser key: press to generate red laser light.

Page up Key : as the Page Up in ordinary keyboard.

Page down Key : as the Page Down in ordinary keyboard.
 Start : press " ∧ "Key and generate start function of computer.

Blank screen : press " ∨ " Key to blank screen ( Press again to return to show status ).

ENGLISH
Start slide show : press "< " Key to start the slide show through shortcut after you open one
file under PowerPoint.
INSTRUCTIONS

Escape : press "> " Key to make escape function on computer.
B).When you select the switch on "MOUSE", it functions as a wireless mouse as below:

Laser Key : press to generate red laser light.

Mouse Left Click: press "LEFT" key.

Mouse Right Click: press "RIGHT" key.

Mouse Pointer up : press " ∧ "Key.

Mouse Pointer down : press " ∨ " Key.

Mouse Pointer left : press "<" Key.

Mouse Pointer right : press ">" Key.
( Tip: hold down the arrow keys to faster the cursor move speed .)
III. Technical Parameters:
Transmitter
Control distance
Laser distance
Battery
Working voltage
Sleep current
Wavelength
Max output
Class
Dimension
Weight
Receiver
System
Compatible plug
Working voltage
Dimension
Weight
Class Ⅱ Class Ⅲ
＞20m ＞20m
＞200m ＞400m
AAA x 2pcs AAA x 2pcs
2.4-3.5V 2.4-3.5V
1uA 1uA
650nm 650nm
＜1mW ＜5mW
Class Ⅱ Class Ⅲ
11.9x3.1x1.7cm 11.9x3.1x1.7cm
58g 58g
Windows 98, SE, Me, 2000, XP, Mac OS, Linux
USB1.1, USB2.0
4.5-5.5V
7.35x2.7x1.7cm
16g
EN
