O O W W N N E E R R ' ' S S M M A A N N U U A A L L
Operation
Maintenance
Specifications
All information in this Owner's Manual is current at the time of publication.
However, Hyundai reserves the right to make changes at any time so that
our policy of continual product improvement may be carried out.
This manual applies to all Hyundai models and includes descriptions and
explanations of optional as well as standard equipment. As a result, you may
find material in this manual that does not apply to your specific vehicle.
Please note that some models are equipped with Right-Hand Drive (RHD).
The explanations and illustrations for some operations in RHD models are
opposite of those written in this manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the i40 and is the answer not in the manual?

Questions and answers

Douglas Blenkinsop
March 20, 2025

How long should it take for the oil pressure warning light to extinguish when starting a cold 2015 Hyundai i40 diesel engine?

0
1 comments:
Mr. Anderson
May 14, 2025

It may take 3–4 seconds for the oil pressure warning light to turn off after a cold start in a 2015 Hyundai i40 diesel engine.

This answer is automatically generated

0

Related Manuals for Hyundai i40

Summary of Contents for Hyundai i40

  • Page 1: Maintenance Specifications

    Specifications All information in this Owner's Manual is current at the time of publication. However, Hyundai reserves the right to make changes at any time so that our policy of continual product improvement may be carried out. This manual applies to all Hyundai models and includes descriptions and explanations of optional as well as standard equipment.
  • Page 2 Introduction Your vehicle at a glance Safety system of your vehicle Features of your vehicle Driving your vehicle table of contents What to do in an emergency Maintenance Specifications & Consumer information Index...
  • Page 3 Introduction How to use this manual / 1-2 Fuel requirements / 1-2 Vehicle break-in process / 1-5 Indicator symbols on the instrument cluster / 1-6...

  • Page 4: How To Use This Manual

    Introduction HOW TO USE THIS MANUAL FUEL REQUIREMENTS We want to help you get the greatest You will find various WARNINGS, CAU- Gasoline engine possible driving pleasure from your vehi- TIONS, and NOTICES in this manual. Unleaded cle. Your Owner’s Manual can assist you These were prepared to enhance your For Europe in many ways.

  • Page 5: Introduction

    (also known as grain alcohol), the catalytic converter and will ask an authorized HYUNDAI dealer and gasoline or gasohol containing damage the engine control sys- whether leaded gasoline in your vehicle methanol (also known as wood alcohol) tem’s oxygen sensor and affect...
  • Page 6 Introduction Use of MTBE Fuel Additives Diesel engine HYUNDAI recommends avoiding fuels HYUNDAI recommends that you use Diesel fuel containing MTBE (Methyl Tertiary Butyl good quality gasolines meet Europe Fuel Diesel engine must be operated only on Ether) over 15.0% vol. (Oxygen Content standards (EN228) or equivalents.

  • Page 7: Vehicle Break-In Process

    Introduction VEHICLE BREAK-IN PROCESS Biodiesel No special break-in period is needed. By CAUTION following a few simple precautions for the Commercially supplied Diesel blends of first 1,000 km (600 miles) you may add to Do not let any gasoline or water no more than 7% biodiesel, commonly the performance, economy and life of enter the tank.

  • Page 8: Indicator Symbols On The Instrument Cluster

    Introduction INDICATOR SYMBOLS ON THE INSTRUMENT CLUSTER Adaptive Front Lighting System AFLS Seat belt warning light ABS warning light (AFLS) malfunction indicator* Electronic stability program Air bag warning light Front fog light indicator* (ESP) indicator Electronic stability program Immobilizer indicator Rear fog light indicator* (ESP) OFF indicator Auto stop for ISG system...
  • Page 9 Introduction Malfunction indicator Engine coolant temperature warning light Glow indicator (Diesel only) Fuel filter warning light (Diesel only) Charging system warning light Overspeed warning light* km/h * : if equipped ❈ For more detailed explanations, refer to section 4, “Instrument cluster”.

  • Page 10: Your Vehicle At A Glance

    Your vehicle at a glance Instrument panel overview / 2-2 Interior overview / 2-4 Engine compartment / 2-5...

  • Page 11: Instrument Panel Overview

    Your vehicle at a glance INSTRUMENT PANEL OVERVIEW ■ Left-Hand drive type ❈ The actual shape may differ from the illustration. OVF021002...

  • Page 12: Table Of Contents

    Your vehicle at a glance 1. Seat warmer/Air ventilation seat* ........3-10/3-11 16. Climate control system ..........4-112/4-121 2. Front passenger's seat belt warning light* ........3-19 17. Center console storage ............4-136 3. Passenger's front air bag ON/OFF indicator*......3-44 18. Glove box ................4-136 4.

  • Page 13: Interior Overview

    Your vehicle at a glance INTERIOR OVERVIEW ■ Left-Hand drive type 1. Seat............3-2 2. Inside door handle ........4-16 3. Power window switch ......4-26 4. Power window lock switch......4-29 5. Hood release lever ........4-30 6. Driver position memory seat* ....4-39 7. Steering wheel ........4-41 8.
  • Page 14 Your vehicle at a glance ENGINE COMPARTMENT ■ ■ Gasoline (1.6L) 1. Engine oil dipstick......7-44 2. Engine oil filler cap ......7-44 3. Engine coolant reservoir....7-46 4. Radiator cap ........7-47 5. Brake/clutch* fluid reservoir.....7-48 6. Windshield washer fluid reservoir..7-49 7. Air cleaner ........7-51 8.
  • Page 15 Your vehicle at a glance ■ ■ Diesel Engine (1.7L) 1. Engine oil dipstick......7-44 2. Engine oil filler cap ......7-44 3. Engine coolant reservoir....7-46 4. Radiator cap ........7-47 5. Brake/clutch* fluid reservoir.....7-48 6. Windshield washer fluid reservoir..7-49 7. Fuel filter ..........7-50 8.
  • Page 16 Seat / 3-2 Seat belts / 3-18 Child restraint system / 3-29 Airbag-supplemental restraint system / 3-40 Safety system of your vehicle...

  • Page 17: Safety System Of Your Vehicle

    Safety system of your vehicle SEAT Front seat (1) Forward and backward (2) Seatback angle (3) Seat cushion height* (4) Lumbar support (5) Seat warmer*/ Seat warmer with air ventilation* (6) Headrest Rear seat (7) Seatback folding (8) Headrest (9) Armrest (10) Seat warmer* * : if equipped OVF031001...

  • Page 18: Seat.

    Safety system of your vehicle WARNING WARNING WARNING Loose objects Driver respon- - Driver’s seat sibility for front seat pas- • Never attempt to adjust seat Loose objects in the driver’s foot while the vehicle is moving. This senger area could interfere with the opera- could result in loss of control, tion of the foot pedals, possibly Riding in a vehicle with a front seat-...
  • Page 19 Safety system of your vehicle (Continued) WARNING WARNING - Rear seatbacks • When resetting the seatback to • The rear seatback must be • Use extreme caution so that the upright position, make sure it securely latched. If not, passen- hands or other objects are not is securely latched by pushing it gers and objects could be thrown...
  • Page 20 Safety system of your vehicle OVF031002 OVF031003 OVF031004 Front seat Seatback angle Seat cushion height (if equipped) To recline the seatback: To change the height of the seat cushion, Manual adjustment push the lever upwards or downwards. 1. Lean forward slightly and lift up on the Forward and backward seatback recline lever.
  • Page 21 Safety system of your vehicle Automatic adjustment (if equipped) CAUTION The front seat can be adjusted by using • The power seat is driven by an the control switches located on the out- electric motor. Stop operating side of the seat cushion. Before driving, once the adjustment is complet- adjust the seat to the proper position so ed.
  • Page 22 Safety system of your vehicle OVF031006 OVF031007 OVF031008 Seatback angle Seat cushion height (if equipped) Lumbar support (if equipped) 1. Push the control switch forward or 1. Pull the front portion of the control The lumbar support can be adjusted by backward to move the seatback to the switch up to raise or down to lower the pressing the lumbar support switch on...
  • Page 23 Safety system of your vehicle WARNING • For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the same height of the center of gravity of an occupant's head. Generally, the center of gravity of most peo- ple's head is similar with the height of the top of their eyes.
  • Page 24 Safety system of your vehicle OVF031010 OVF031012 HNF2041-1 Adjusting the height up and down Removal and installation Active headrest To raise the headrest, pull it up to the To remove the headrest, raise it as far as The active headrest is designed to move desired position (1).
  • Page 25 Safety system of your vehicle ■ During mild weather or under conditions Type A CAUTION where the operation of the seat warmer is not needed, keep the switches in the • When cleaning the seats, do not "OFF" position. use an organic solvent such as thinner, benzene, alcohol and •...
  • Page 26 Safety system of your vehicle • When the air ventilation seat is turned WARNING - Seat warmer on, the seat may get cooler after about 5 minutes. burns • The air ventilation seat defaults to the Passengers should use extreme OFF position whenever the ignition caution when using seat warmers switch is turned to the ON position.
  • Page 27 Safety system of your vehicle OVF031016 OVF031068 OPA039053 Seatback pocket Headrest Rear seat The seatback pocket is provided on the The rear seat is equipped with headrests Seatback angle back of the front passenger’s and driver’s in all the seating positions for the occu- To recline the seatback: seatbacks.
  • Page 28 Safety system of your vehicle WARNING • For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the same height of the center of gravity of an occupant's head. Generally, the center of gravity of most peo- ple's head is similar with the height of the top of their eyes.
  • Page 29 Safety system of your vehicle ✽ ✽ NOTICE With the seat warmer switch in ON position, the heating system in the seat turns off or on automatically depending on the seat temperature. CAUTION • When cleaning the seats, do not use an organic solvent such as thinner, benzene, alcohol and gasoline.
  • Page 30 Safety system of your vehicle Folding the rear seat WARNING - Seat warmer The rear seatbacks can be folded to facil- burns itate carrying long items or to increase the luggage capacity of the vehicle. Passengers should use extreme caution when using seat warmers due to the possibility of excess WARNING heating or burns.
  • Page 31 Safety system of your vehicle OVF031031 OVF031021 OVF031022 2. Insert the rear seat belt buckle in the 5. Pull on the seatback folding lever, then 6. To use the rear seat, lift and pull the pocket between the rear seatback and fold the seat toward the front of the seatback backward.
  • Page 32 Safety system of your vehicle CAUTION - Damaging rear WARNING WARNING - Cargo seat belt buckles When you return the rear seatback Cargo should always be secured to When you fold the rear seatback or to its upright position after being prevent it from being thrown about put luggage on the rear seat cush- folded down:...
  • Page 33 Safety system of your vehicle SEAT BELTS Seat belt restraint system (Continued) (Continued) • Avoid wearing twisted seat belts. Care should be taken to avoid con- WARNING A twisted belt can't do its job as tamination of the webbing with pol- •...

  • Page 34: Front Passenger's Seat Belt Warning Light

    Safety system of your vehicle ■ Type A WARNING • No modifications or additions should be made by the user which will either prevent the seat belt adjusting devices from oper- ating to remove slack, or prevent the seat belt assembly from being adjusted to remove slack.
  • Page 35 Safety system of your vehicle ✽ ✽ NOTICE As a reminder to the driver and passenger, ■ Front seat the seatbelt warning light will blink or illu- • You can find the front passenger’s minate and warning chime will sound as seat belt warning light on the center follows: fascia panel.
  • Page 36 Safety system of your vehicle To raise the height adjuster, pull it up (1). The seat belt automatically adjusts to the To lower it, push it down (3) while press- proper length only after the lap belt por- ing the height adjuster button (2). tion is adjusted manually so that it fits snugly around your hips.
  • Page 37 Safety system of your vehicle WARNING ■ Rear center seat B210A01NF ■ Rear center seat B200A01NF OVF031066 Always have the plate (1) and the WARNING buckle (A) locked together. Make You should place the lap belt por- sure the belt is not twisted. tion as low as possible and snugly across your hips, not on your waist.
  • Page 38 Safety system of your vehicle When the vehicle stops suddenly, or if the occupant tries to lean forward too quickly, the seat belt retractor will lock into position. In certain frontal collisions, the pre-tensioner will activate and pull the seat belt into tighter contact against the occupant's body.
  • Page 39 Wash all exposed skin areas thor- being driven, please have an oughly after an accident in which the authorized HYUNDAI dealer inspect 2. Be sure you and your passen- pre-tensioner seat belts were activat- the pre-tensioner seat belt or SRS gers always wear seat belts prop- air bag system as soon as possible.
  • Page 40 Without a seat belt, occupants belts yourself. This must be done could be shifted too close to a by an authorized HYUNDAI dealer. Every person in your vehicle needs deploying air bag, strike the interior • Do not strike the pre-tensioner...
  • Page 41 Safety system of your vehicle ✽ ✽ NOTICE Larger children If the shoulder belt portion slightly touch- es the child’s neck or face, try placing the Children who are too large for child Small children are best protected from child closer to the center of the vehicle. If restraint systems should always occupy injury in an accident when properly the shoulder belt still touches their face...
  • Page 42 Safety system of your vehicle Pregnant women Injured person WARNING The use of a seat belt is recommended A seat belt should be used when an for pregnant women to lessen the chance injured person is being transported. Riding with a reclined seatback of injury in an accident.
  • Page 43 This should be done even if no damage serious injury. If the webbing or is visible. Additional questions concern- buckles are damaged, get them ing seat belt operation should be directed replaced immediately. to an authorized HYUNDAI dealer.
  • Page 44 Safety system of your vehicle CHILD RESTRAINT SYSTEM (IF EQUIPPED) Children riding in the car should sit in the WARNING WARNING rear seat and must always be properly restrained to minimize the risk of injury in • A child restraint system must be To reduce the chance or serious or an accident, sudden stop or sudden placed in the rear seat.
  • Page 45 Forward-facing child restraint system • Never allow two children, or any • After an accident, have an author- two persons, to use the same ized HYUNDAI dealer check the seat belt. child restraint system, seat belt, • Children often squirm and repo- tether anchor and lower anchor.
  • Page 46 Installing a child restraint system by the system checked immediately lap/shoulder belt by your authorized HYUNDAI To install a child restraint system on the dealer. outboard or center rear seats, do the fol- • Failure to observe this manual's...
  • Page 47 Safety system of your vehicle OEN036101 OEN036104 3. Buckle the seat belt and allow the seat 2. Fasten the lap/shoulder belt latch into belt to take up any slack. After installa- the buckle. Listen for the distinct “click” sound. tion of the child restraint system, try to move it in all directions to be sure the Position the release button so that it is child restraint system is securely...
  • Page 48 Safety system of your vehicle Child Seat Restraint Suitability for Seat Position using the Seat Belt - For Europe Use child safety seats that have been officially approved and are appropriate for your children. When using the child safety seats, refer to the following table. Seating Position Age Group Front passenger...
  • Page 49 Safety system of your vehicle WARNING WARNING - Child restraint check A child can be seriously injured or killed in a collision if the child Check that the child restraint sys- restraint is not properly anchored tem is secure by pushing and to the car and the child is not prop- pulling it in different directions.
  • Page 50 Safety system of your vehicle ISOFIX Anchor Position Indicator ISOFIX Anchor OLM039035 OVF031035 OVF031036 Securing a child restraint system There are ISOFIX symbols located on Both rear outboard seats are equipped with “ISOFIX” system and “Tether the lower portion of each side of the rear with a pair of ISOFIX anchorages as well Anchorage”...
  • Page 51 Safety system of your vehicle The installing and the use of a child-seat To secure the child restraint seat WARNING has to be done according to the 1. To engage the child restraint seat to installing-manual, which is added to the the ISOFIX anchor, insert the child •...
  • Page 52 Safety system of your vehicle (Continued) WARNING • Attach the ISOFIX or ISOFIX-com- • Do not install a child restraint patible child restraint seat only to seat at the center of the rear seat the appropriate locations shown using vehicle's ISOFIX in the illustration.

  • Page 53: Safety System Of Your Vehicle

    Safety system of your vehicle Child seat restraint suitability for vehicle ISOFIX positions - For Europe Vehicle ISOFIX positions Mass Group Size Class Fixture Rear Outboard Rear Outboard Front Passenger Rear Center (Driver side) (Passenger side) ISO/L1 Carrycot ISO/L2 0 : UP to 10kg ISO/R1 ISO/R1 0+ : UP to 13kg...
  • Page 54 Safety system of your vehicle Recommended child restraint systems – For Europe ECE-R44 Mass Group Name Manufacturer Type of Fixation Approval No. Rearward facing with vehicle E4 03443416 (Seat) BIMBO G0/1 S FAIR E4 04443718 (Platform) Group 0-1 specific ISOFIX platform type “G” (0-18kg) Baby Safe Plus II Britax Römer...

  • Page 55: Passenger's Front Air Bag On/Off Indicator

    Safety system of your vehicle AIR BAG - SUPPLEMENTAL RESTRAINT SYSTEM (IF EQUIPPED) (1) Driver’s front air bag (2) Passenger’s front air bag* (3) Side impact air bag* (4) Curtain air bag* (5) Driver’s knee air bag* (6) Passenger’s front air bag ON/OFF switch* * : if equipped WARNING...
  • Page 56 Safety system of your vehicle How does the air bag system It is virtually impossible for you to see WARNING the air bags inflate during an accident. operate It is much more likely that you will sim- • To avoid severe personal injury •...
  • Page 57 Safety system of your vehicle Noise and smoke WARNING When the air bags inflate, they make a loud noise and they leave smoke and When the air bags deploy, the air powder in the air inside of the vehicle. bag related parts in the steering This is normal and is a result of the igni- wheel and/or instrument panel tion of the air bag inflator.
  • Page 58 Safety system of your vehicle When the ignition switch is turned ON, WARNING the warning light should illuminate for approximately 6 seconds, then go off. • Extreme Hazard! Do not use a Have the system checked if: rearward facing child restraint on a seat protected by an air bag in •...

  • Page 59: Passenger's Front Air Bag

    ON/OFF switch is set to the OFF position. If this occurs, have an authorized HYUNDAI dealer inspect the pas- senger’s front air bag ON/OFF switch and the SRS air bag system...

  • Page 60: Srs Components And Functions

    SRS. Have an authorized The SRSCM continually monitors all ele- HYUNDAI dealer inspect the air bag ments while the ignition switch is ON to system as soon as possible. determine if a frontal, near-frontal impact •...
  • Page 61 Safety system of your vehicle Driver’s front air bag (1) Driver’s front air bag (2) Driver’s front air bag (3) OHM039103N OHM039102N OHM039104N The front air bag modules are located Upon deployment, tear seams molded A fully inflated air bag, in combination both in the center of the steering wheel, directly into the pad covers will separate with a properly worn seat belt, slows the...
  • Page 62 If this occurs, have your vehicle Always wash all exposed skin B240B05L immediately inspected by an areas thoroughly with lukewarm authorized HYUNDAI dealer. water and a mild soap after an WARNING • Before you replace a fuse or dis- accident in which the air bags •...
  • Page 63 Safety system of your vehicle ■ The indications of the system's presence Driver’s front air bag ■ Passenger’s front air bag are the letters "AIR BAG" embossed on the air bag pad cover in the steering wheel and/or on the cover of the driver’s side knee bolster located below the steering wheel and the passenger's side front panel pad above the glove box.
  • Page 64 • Air bags can only be used once – • No objects should be placed over have an authorized HYUNDAI To reduce the chance of serious or or near the air bag modules on dealer replace the air bag imme-...
  • Page 65 Safety system of your vehicle (Continued) (Continued) • For maximum safety protection in • Front air bags are not intended to all types of crashes, all occu- deploy side-impact, rear- pants including the driver should impact or rollover crashes. In always wear their seat belts addition, front air bags will not whether or not an air bag is also...
  • Page 66 Safety system of your vehicle ✽ ✽ NOTICE ■ The passenger’s front air bag OFF indi- Type A cator ( ) will illuminate and stay on until • When the passenger’s front air bag the passenger’s front air bag is reactivat- ON/OFF switch is set to the ON position, the passenger’s front air bag is activated To reactivate the passenger’s front air...
  • Page 67 WARNING If this occurs, have an authorized • Even though your vehicle is • The driver is responsible for the HYUNDAI dealer inspect the pas- equipped with the passenger's proper position of the passen- senger’s front air bag ON/OFF front air bag ON/OFF switch, do ger’s front air bag ON/OFF switch.
  • Page 68 Safety system of your vehicle ■ Your vehicle is equipped with a side Front WARNING impact air bag in each front and outboard rear seat. The purpose of the air bag is to • The side impact air bag is sup- provide the vehicle's driver and/or the plemental to the driver's and the front passenger with additional protec-...
  • Page 69 HYUNDAI dealer. Inform that your They are designed to help protect the vehicle is equipped with side heads of the front seat occupants and impact air bags.
  • Page 70 HYUNDAI dealer. restraint system. Failure to follow the above men- Make sure to put the child tioned instructions can result in restraint system as far away from injury or death to the vehicle occu- the door side as possible, and pants in an accident.
  • Page 71 Safety system of your vehicle Why didn’t my air bag go off in a collision? (Inflation and non-infla- tion conditions of the air bag) There are many types of accidents in which the air bag would not be expect- ed to provide additional protection. These include rear impacts, second or third collisions in multiple impact accidents, as well as low speed...
  • Page 72 Have the vehi- result in serious personal injury cle checked and repaired by an or death. authorized HYUNDAI dealer. • If the installation location or • Your vehicle has been designed angle of the sensors is altered in...
  • Page 73 Safety system of your vehicle Although the front air bags (driver’s and front passenger’s air bags) are designed to inflate only in frontal collisions, they also may inflate in other types of colli- sions if the front impact sensors detect a sufficient impact.
  • Page 74 Safety system of your vehicle OED036100 OVF031061 OED036102 • Air bags are not designed to inflate in • Front air bags may not inflate in side • In an angled collision, the force of rear collisions, because occupants are impact collisions, because occupants impact may direct the occupants in a moved backward by the force of the move to the direction of the collision,...
  • Page 75 Safety system of your vehicle OED036103 OED036104 OVF031063 • Just before impact, drivers often brake • Air bags may not inflate in rollover acci- • Air bags may not inflate if the vehicle heavily. Such heavy braking lowers the dents because air bag deployment collides with objects such as utility front portion of the vehicle causing it to would not provide protection to the...
  • Page 76 • If components of the air bag sys- with plain water. Solvents or formed by an authorized HYUNDAI deal- tem must be discarded, or if the cleaners could adversely affect er. Improper handling of the SRS system...
  • Page 77 Safety system of your vehicle Additional safety precautions • Keep occupants away from the air WARNING bag covers. All occupants should sit • Never let passengers ride in the upright, fully back in their seats with • Sitting improperly or out of posi- cargo area or on top of a folded- their seat belts on and their feet on the tion can cause occupants to be...
  • Page 78 Safety system of your vehicle Note that these government warnings ■ Type A focus on the risk of children. We also want you to be aware of the risks which adults are exposed to which have been described in previous pages. OVF031064 ■...

  • Page 79: Features Of Your Vehicle

    Keys / 4-3 Remote keyless entry / 4-5 Smart key / 4-9 Theft-alarm system / 4-12 Door locks / 4-15 Tailgate / 4-20 Windows / 4-26 Hood / 4-30 Features of your vehicle Fuel filler lid / 4-32 Panorama Sunroof / 4-35 Driver position memory system / 4-39 Steering wheel / 4-41 Mirrors / 4-44...
  • Page 80 Manual climate control system / 4-112 Automatic climate control system / 4-121 Windshield defrosting and defogging / 4-133 Storage compartment / 4-136 Interior features / 4-140 Exterior features / 4-151 Audio system / 4-153 Features of your vehicle...
  • Page 81 Your immobilizer system is comprised of number will enable an authorized WARNING a small transponder in the key and elec- HYUNDAI dealer to duplicate the keys tronic devices inside the vehicle. Use only HYUNDAI original parts easily. Remove the bar code tag and for the ignition key in your vehicle.
  • Page 82 If you need additional keys or lose your changed to the ON position, the immobi- In order to prevent theft of your vehi- keys, consult an authorized HYUNDAI lizer system checks and verifies if the key cle, do not leave spare keys any- dealer.
  • Page 83 Features of your vehicle REMOTE KEYLESS ENTRY (IF EQUIPPED) ■ ■ Type A Type A CAUTION Do not fold the key without press- ing the release button. This may damage the key. Type B • To remove the mechanical key, press and hold the release button and remove the mechanical key.
  • Page 84 Features of your vehicle ✽ ✽ NOTICE Tailgate unlock (3) Power tailgate 1. Press the tailgate unlock button for Non-powered tailgate. The doors will not lock if any door is more than 1 second. opened. 1. Press the tailgate unlock button for 2.
  • Page 85 If you are unsure not be covered by your manufactur- how to use or replace the battery, contact er vehicle warranty. an authorized HYUNDAI dealer.
  • Page 86 3. Install the rear cover. battery, contact an authorized HYUNDAI dealer. For transmitter or smart key replace- ment, see an authorized HYUNDAI deal- • Using the wrong battery can er for reprogramming. cause the transmitter or smart key to malfunction. Be sure to use the correct battery.
  • Page 87 Features of your vehicle SMART KEY (IF EQUIPPED) Locking 1. Carry the smart key. 2. Close all doors, engine hood and tail- gate. 3. Press the button of the outside door handle. 4. The hazard warning lights will blink once. 5.
  • Page 88 • The button will only operate when the the outside door handle. authorized HYUNDAI dealer to pro- smart key is within 0.7 m (28 in.) from • When the smart key is recognized in tect it from potential theft.
  • Page 89 Features of your vehicle CAUTION Keep the smart key away from water or any liquid. If the keyless entry system is inoperative due to exposure to water or liquids, it will not be covered by your manufactur- er’s vehicle warranty. OVF041215 Door lock/unlock in an emer- gency situation...
  • Page 90 Features of your vehicle THEFT-ALARM SYSTEM (IF EQUIPPED) Armed stage Using the smart key Park the vehicle and stop the engine. Armed Arm the system as described below. stage 1. Turn off the engine. 2. Make sure that all doors, the engine hood and tailgate are closed and latched.
  • Page 91 Features of your vehicle • Lock the doors by pressing the lock Using the transmitter Theft-alarm stage button on the smart key. Park the vehicle and stop the engine. The alarm will be activated if any of the After completion of the steps above, Arm the system as described below.
  • Page 92 - The engine is started. malfunction and should only be Then the system will be disarmed. - The ignition switch is in the “ON” posi- serviced by an authorized HYUNDAI • With smart key system tion for 30 seconds or more.

  • Page 93: Door Locks

    Features of your vehicle DOOR LOCKS ✽ ✽ NOTICE • After removing the cover, turn the key toward the rear of the vehicle to unlock • In cold and wet climates, door lock and toward the front of the vehicle to and door mechanisms may not work lock (3).
  • Page 94 Features of your vehicle ■ Type A Lock OVF041010 ■ Type B OVF041009 OVF041008 In case of an emergency Operating door locks from inside the vehicle If the power door lock switch does not operate electrically, the only way to lock With the door handle the door(s) is with the mechanical key Front door...
  • Page 95 Features of your vehicle • If any door is unlocked, the indicator of WARNING - WARNING the central door lock switch will go off. Doors Unlocked vehicles • When you press the central door • The doors should always be fully unlock switch, all vehicle doors will closed and locked while the vehi- Leaving your vehicle unlocked can...
  • Page 96 Features of your vehicle Deadlocks (if equipped) Door lock/unlock features Speed sensing door lock system (if equipped) Some vehicles are equipped with a Impact sensing door unlock system All doors will automatically lock after the deadlock system. Deadlocks prevent All doors will automatically unlock when vehicle speed exceeds 15 km/h.
  • Page 97 Features of your vehicle 3. Close the rear door. To open the rear door, pull the outside door handle (2). Even though the doors may be unlocked, the rear door will not open by pulling the inner door handle (3) until rear door child safety lock is unlocked.

  • Page 98: Central Door Lock/Unlock Switch

    Features of your vehicle TAILGATE ✽ ✽ NOTICE In cold and wet climates, door lock and door mechanisms may not work proper- ly due to freezing conditions. WARNING The tailgate swings upward. Make sure no objects or people are near the rear of the vehicle when open- ing the tailgate.

  • Page 99: Power Tailgate Open Button

    Features of your vehicle Power tailgate (if equipped) WARNING Exhaust (1) Power tailgate open button fumes (2) Power tailgate handle switch If you drive with the tailgate (3) Power tailgate close button opened, you will draw dangerous exhaust fumes into your vehicle ✽...
  • Page 100 Features of your vehicle CAUTION Do not close or open the power tail- gate manually. This may cause dam- age to the power tailgate. If it is nec- essary to close or open the power tailgate manually when the battery is discharged or disconnected, do not apply excessive force.
  • Page 101 This 1. Press the power tailgate close button must be done by an authorized (approximately 1 second). HYUNDAI dealer. 2. The tailgate will close and lock auto- • When jacking up the vehicle to matically.
  • Page 102 HYUNDAI dealer. detect the resistance. ✽ ✽ NOTICE • If the resistance is detected while...
  • Page 103 Features of your vehicle WARNING • For emergencies, be fully aware of the location of the emergency tailgate safety release lever in the vehicle and how to open the tail- gate if you are accidentally locked in the luggage compart- ment.

  • Page 104: Power Window Switch

    Features of your vehicle WINDOWS (1) Driver’s door power window switch (2) Front passenger’s door power win- dow switch (3) Rear door (left) power window switch (4) Rear door (right) power window switch (5) Window opening and closing (6) Automatic power window up*/down* (7) Power window lock switch *: if equipped ✽...
  • Page 105 Features of your vehicle Power windows The ignition switch must be in the ON position for power windows to operate. Each door has a power window switch that controls the door’s window. The dri- ver’s door has a master power window switch that controls all the windows in the vehicle.
  • Page 106 Features of your vehicle ✽ ✽ NOTICE ✽ ✽ NOTICE If the power window does not operate The automatic reverse feature is only normally, the automatic power window active when the “auto up” feature is system must be reset as follows: used by fully pulling up the switch.

  • Page 107: Power Window Lock Switch

    Features of your vehicle CAUTION WARNING - Windows • To prevent possible damage to • NEVER leave the ignition key in the power window system, do not the vehicle. open or close two windows or • NEVER leave any child unattend- more at the same time.
  • Page 108 Features of your vehicle HOOD Closing the hood 1. Before closing the hood, check the fol- lowing: • All filler caps in engine compartment must be correctly installed. • Gloves, rags or any other com- bustible material must be removed from the engine compartment.
  • Page 109 Features of your vehicle WARNING - WARNING Hood • Before closing the hood, ensure • Always double check to be sure that all obstructions are removed that the hood is firmly latched from the hood opening. Closing before driving away. If it is not the hood with an obstruction latched, the hood could fly open present in the hood opening may...

  • Page 110: Fuel Filler Lid

    Features of your vehicle FUEL FILLER LID Closing the fuel filler lid 1. To install the cap, turn it clockwise until it “clicks”. This indicates that the cap is securely tightened. 2. To close the lid, press the edge of the lid.
  • Page 111 Features of your vehicle (Continued) WARNING WARNING - - Refueling Refueling dan- • Do not get back into a vehicle gers • If pressurized fuel sprays out, it once you have begun refueling can cover your clothes or skin Automotive fuels are flammable since you can generate static and thus subject you to the risk materials.
  • Page 112 Electric current and/or replacement, use only a genuine ment. Follow any safety instruc- electronic interference from cel- HYUNDAI cap or the equivalent tions they provide. lular phones can potentially specified for your vehicle. An ignite fuel vapors causing a fire.
  • Page 113 Features of your vehicle PANORAMA SUNROOF (IF EQUIPPED) ✽ ✽ NOTICE CAUTION • In cold and wet climates, the sunroof • Do not continue to move the sun- may not work properly due to freez- roof control lever after the sunroof ing conditions.
  • Page 114 Features of your vehicle ✽ ✽ NOTICE The sunroof cannot tilt when it is in the slide position but can slide while in a tilt position. WARNING • Never adjust the sunroof or sun- shade while driving. This could result in loss of control and an accident that may cause death, serious injury, or property dam- OYF049214...
  • Page 115 Features of your vehicle Closing the sunroof To close the sunroof glass only Push the sunroof control lever forward to the first detent position or pull the lever downward. To close the sunroof glass with the sunshade Push the sunroof control lever forward to the second detent position.
  • Page 116 Features of your vehicle Resetting the sunroof WARNING - Sunroof Whenever the vehicle battery is discon- • Be careful that no head, hands nected or discharged, you must reset and body parts are obstructed by your sunroof system as follows: a closing sunroof.
  • Page 117 Features of your vehicle DRIVER POSITION MEMORY SYSTEM (IF EQUIPPED) Storing positions into memory WARNING using the buttons on the door Never attempt to operate the driver Storing driver’s seat positions position memory system while the 1. Change the ignition switch to the ON vehicle is moving.
  • Page 118 Features of your vehicle Recalling positions from memory Easy access function (if equipped) 1. Change the ignition switch to the ON position. The system will move the driver's seat 2. To recall the position in the memory, automatically as follows: press the desired memory button (1 or •...

  • Page 119: Steering Wheel

    • The steering effort increases if the vehicle operation, have the power steer- steering wheel is rotated continuously ing checked by an authorized HYUNDAI when the vehicle is not in motion. dealer. However, after a few minutes, it will return to its normal conditions.

  • Page 120: Heated Steering Wheel*

    Features of your vehicle Tilt steering A tilt steering wheel allows you to adjust the steering wheel before you drive. You can also raise it to give your legs more room when you exit and enter the vehicle (if equipped). The steering wheel should be positioned so that it is comfortable for you to drive, while permitting you to see the instru-...

  • Page 121: Horn

    Features of your vehicle CAUTION Do not install any grip to operate the steering wheel. This causes damage to the heated steering wheel system. OVF041033 Horn To sound the horn, press the horn sym- bol on your steering wheel. Check the horn regularly to be sure it operates properly.
  • Page 122 Features of your vehicle MIRRORS Inside rearview mirror Electric chromic mirror (ECM) (if equipped) Adjust the rearview mirror so that the The electric rearview mirror automatical- center view through the rear window is ly controls the glare from the headlights seen.
  • Page 123 Features of your vehicle Outside rearview mirror CAUTION Be sure to adjust mirror angles before Do not scrape ice off the mirror driving. face; this may damage the surface Your vehicle is equipped with both left- of the glass. If ice should restrict hand and right-hand outside rearview movement of the mirror, do not mirrors.
  • Page 124 Features of your vehicle CAUTION • The mirrors stop moving when they reach the maximum adjust- ing angles, but the motor contin- ues to operate while the switch is pressed. Do not press the switch longer than necessary, the motor may be damaged.
  • Page 125 Features of your vehicle CAUTION In case it is an electric type outside rearview mirror, don’t fold it by hand. It could cause motor failure. OVF041037 Electric type To fold the outside rearview mirror, press the button. To unfold it, press the button again. CAUTION The electric type outside rearview mirror operates even though the...

  • Page 126: Instrument Cluster

    Features of your vehicle INSTRUMENT CLUSTER ■ ■ Type A 1. Tachometer 2. Speedometer 3. Engine coolant temperature gauge 4. Fuel gauge 5. Warning and indicator lights (if equipped) 6. Turn signal indicators 7. LCD display ■ ■ Type B * The actual cluster in the vehicle may differ from the illustration.
  • Page 127 Features of your vehicle ■ Type A ■ Left-Hand drive type Speedometer The speedometer indicates the vehicle speed. The speedometer is calibrated in kilome- ters per hour and/or miles per hour. OVF041043 ■ Type B OVF041042 Instrument panel illumination The instrument panel illumination intensi- ty can be adjusted as follows: •...
  • Page 128 Features of your vehicle ■ Gasoline Engine ■ ■ ■ ■ CAUTION If the gauge pointer moves beyond the normal range area toward the “130/H” position, it indicates over- heating that may damage the engine. OVF041044 OVF041047L WARNING ■ Diesel Engine ■...
  • Page 129 Features of your vehicle ✽ ✽ NOTICE ■ ■ ■ ■ • The fuel tank capacity is given in sec- tion 8. • The fuel gauge is supplemented by a low fuel warning light, which will illu- minate when the fuel tank is nearly empty.
  • Page 130 Features of your vehicle OVF041048 OVF041049 OVF041090 Manual transaxle shift indicator Automatic transaxle shift position Icy road warning light (if equipped) indicator (if equipped) (if equipped) This indicator informs you which gear is The indicator displays which automatic This warning light is to warn the driver desired while driving to save fuel.

  • Page 131: Lcd Display Button

    Features of your vehicle ■ Type B ■ Type B ■ Type A ■ Type A ■ Type A OVF041050 ■ Type B OVF041052 OVF041053 Odometer (km or mi.) Tripmeter (km or mi.) The odometer indicates the total dis- This mode indicates the distance of indi- tance the vehicle has been driven.
  • Page 132 Features of your vehicle Trip computer ■ Type A ■ Type B Distance to empty The trip computer is a microcomputer- controlled driver information system that displays information related to driving Average fuel economy*/ when the ignition switch is in the ON Instant fuel economy* position.
  • Page 133 Features of your vehicle ✽ ✽ NOTICE ■ Type B ■ Type B ■ Type A ■ Type A • If the vehicle is not on level ground or the battery power has been interrupt- ed, the “Distance to empty” function may not operate correctly.

  • Page 134: Trip Button

    Features of your vehicle ■ Type B ■ Type B ■ Type B ■ Type A ■ Type A ■ Type A OVF041058 OVF041059 OVF041060 User Settings Average speed (km/h or MPH) Elapsed time This mode calculates the average speed This mode indicates the total time trav- 1.
  • Page 135 Features of your vehicle ■ Type B • ■ Type B ■ Type A Auto Door Unlock ■ Type A Off - The auto door unlock operation will be canceled. Key Out - All doors will be automatically unlocked when the ignition key is removed from ignition switch.

  • Page 136: Seat

    Features of your vehicle ■ Type B • ■ Type A Alarm Function If the Alarm Function is checked: The Alarm function on the transmitter and smart key will be activated. • Welcome Sound (for instrument cluster type B) On - The Welcome Sound function will be activated.
  • Page 137 Features of your vehicle LCD display informations • Door/Trunk (Tailgate) open Time adjust mode Clock (if equipped) ■ Door OVF041131/Q OVF041065 To change the time (hour/minute) : The time is displayed when the ignition 1. Press the TRIP button when in the OVF041066 switch is in the ON position.
  • Page 138 Features of your vehicle Heated steering wheel ON/OFF Illumination intensity Parking assist warning ■ Type A ■ Type B ■ Type A ■ Type B ■ Type A ■ Type B OVF041068 OVF041070 OVF041071 The indicator will appear when the heat- The illumination intensity of the instru- Displays the area an obstacle is detected ed steering wheel is turned on.
  • Page 139 Features of your vehicle Low tire pressure (if equipped) Turn on fuse switch (mode switch) Check active air flap system ■ Type A ■ Type B ■ Type A ■ Type B ■ Type A ■ Type B OVF061012 OVF041073 OVF041074 The low tire pressure position telltale will The notice appears to inform the driver to...
  • Page 140 Features of your vehicle For vehicle’s equipped with smart key system Key is not in vehicle Key is not detected Press start with smart key ■ Type A ■ Type B ■ Type A ■ Type B ■ Type A ■...
  • Page 141 Features of your vehicle Low key battery Press brake pedal to start engine Press clutch pedal to start engine (for automatic transaxle) (for manual transaxle) ■ Type A ■ Type B ■ Type A ■ Type B ■ Type A ■...
  • Page 142 Also, the warning chime sounds for about or the theft alarm system is armed. 10 seconds. (if equipped) If the warning illuminates each time you press the engine start/stop button, take your vehicle to an authorized HYUNDAI dealer and have the system checked.
  • Page 143 Features of your vehicle Press start button while turn steering Check steering wheel lock system Check stop lamp fuse (if equipped) (if equipped) ■ Type A ■ Type B ■ Type A ■ Type B ■ Type A ■ Type B OVF041086 OVF041084 OVF041085...

  • Page 144: Seat Belts

    • Door/tailgate open (LCD display) approximately 6 seconds each time you HYUNDAI dealer. turn the ignition switch ON regardless of • Heated steering wheel ON/OFF (LCD After starting the engine, check to make display) belt fastening.
  • Page 145 SRS inspected by an author- by an authorized HYUNDAI dealer. • If the indicator illuminates only for 2 sec- ized HYUNDAI dealer. onds and goes out when the engine...
  • Page 146 ON position and then it will go out. This light also comes on when the EPS has some problems. If it comes on while driving, have your vehicle checked by an authorized HYUNDAI dealer.
  • Page 147 Rear fog light indicator uously remains on, take your vehicle to (if equipped) (if equipped) an authorized HYUNDAI dealer and have the system checked. This indicator illuminates when the rear This indicator light illuminates when the fog lights are ON.
  • Page 148 If the brakes fail take your vehicle to an authorized while you are driving, shift to a lower gear HYUNDAI dealer and have the system Low brake fluid level warning for additional engine braking and stop the checked.
  • Page 149 Have the HOLD vehicle checked by an authorized HYUNDAI dealer as soon as possible. If you press the AUTO HOLD switch, the This light illuminates if the ignition switch AUTO HOLD indicator on the cluster...
  • Page 150 But, if the ESP system malfunctions the cluster type B, the indicator illuminates indicator illuminates and stays on. Take on the LCD display. your vehicle to an authorized HYUNDAI dealer and have the system checked. ✽ ✽ NOTICE When the engine automatically starts by...
  • Page 151 OVF051029 blink. If this occurs, have the system checked The indicator illuminates when the cruise by an authorized HYUNDAI dealer as control switch (-SET or RES+) is pressed. soon as possible. The cruise SET indicator does not illumi- For more details, refer to “Speed limit control system”...
  • Page 152 Tire Pressure Monitoring System. If this occurs, have the system checked by an authorized HYUNDAI dealer as soon as possible. For more details, refer to the TPMS in sec- tion 6.
  • Page 153 LCD display. engine off immediately. In any damage could result. instance where the oil light stays on when the engine is running, the engine should be checked by an authorized HYUNDAI dealer before the car is driven again. 4 75...
  • Page 154 (for your vehicle to your nearest author- Generally, your vehicle will continue to be about 25 minutes). ized HYUNDAI dealer and have the drivable, but have the system checked by If the malfunction indicator light system checked.
  • Page 155 If your vehicle overheats, refer System inspected as soon as pos- perature, air temperature and battery to “Overheating” in section 6. sible by an authorized HYUNDAI condition. dealer. ✽ ✽ NOTICE ✽ ✽ NOTICE...
  • Page 156 Have an authorized overspeed. When the fuel filter warning light HYUNDAI dealer correct the problem illuminates, engine power (vehicle as soon as possible. speed & idle speed) may decrease. If you keep driving with the warning...
  • Page 157 Features of your vehicle PARKING ASSIST SYSTEM (IF EQUIPPED) ■ sensing range objects Front detectable by the sensors are limited. Whenever moving pay as much attention to what is in front and behind of you as you would in a vehicle without a parking assist system.
  • Page 158 Features of your vehicle • The sensing distance while moving for- Type of warning indicator and sound ward is approximately 60 cm (24 in.) : with Warning sound when you are driving less than 10 km/h : without Warning sound (6.2 mph).

  • Page 159: Parking Assist System Button

    Features of your vehicle Non-operational conditions of There is a possibility of parking CAUTION assist system malfunction when: parking assist system • This system can only sense 1. Driving on uneven road surfaces such Parking assist system may not oper- objects within the range and loca- as unpaved roads, gravel, bumps, or ate normally when:...
  • Page 160 If this occurs, have your vehicle checked 4. When the sensor is frozen or stained WARNING by an authorized HYUNDAI dealer as with snow or water, the sensor may be soon as possible. inoperative until the stains are Pay close attention when the vehi- removed using a soft cloth.
  • Page 161 LCD display to help size rather than the size recom- requires parking manually. through parking. mended by the HYUNDAI dealer, • The Parking Assist System's front and the system may not work properly. rear warning sound activates when...
  • Page 162 Features of your vehicle ■ Right side ■ Left side Non-operating condition • Heavy wind - parallel mode -parallel mode • Wheel changed to an unauthorized Never use the Smart Parking Assist size System in the below conditions. • A problem with the wheel alignment •...
  • Page 163 Features of your vehicle (Continued) (Continued) WARNING 2. Parking in snow 3. Parking in narrow space Do not use the Smart Parking Assist System in the following con- ditions for unexpected results may occur and cause a serious accident. 1. Parking on inclines OLM041292 OSL040144 Snow may interfere with sensor...
  • Page 164 Features of your vehicle (Continued) (Continued) (Continued) 4. Parking diagonal 6. Parking behind a truck 5. Parking in uneven road OLM041274 OSL040145 OLM041291 The system is a supplemental for An accident may occur when park- Parking in uneven roads, the driver parallel parking.
  • Page 165 Features of your vehicle ✽ ✽ NOTICE How the system works (Continued) 1. Activate the Smart Parking Assist • Before activating the system check if 7. Obstacle in parking space System the conditions are possible to use the 2. Select parking assist mode system.

  • Page 166: Smart Parking Assist System Button*

    Features of your vehicle ■ Right side ■ Left side ■ Right side ■ Left side - parallel mode -parallel mode - parallel mode -parallel mode OVF041105 OVF041107 OVF041203 1. Activate Smart Parking Assist 2. Select parking assist mode 3. Search for parking space System •...
  • Page 167 Features of your vehicle ✽ ✽ NOTICE • Turn on the hazard warning flasher if it is crowded with other vehicles. • If the parking lot is small, slowly drive more nearer to the parking space. • The search for a parking space will be 50~150 cm completed only when there is enough space for the vehicle to move to park.
  • Page 168 Features of your vehicle ■ Right side ■ Left side CAUTION - parallel mode -parallel mode • Always drive slowly with the brake pedal applied. • Always check for objects around your vehicle before driving. • If the vehicle does not move even though the brake pedal is not depressed, check the surround- ing before depressing the accel-...
  • Page 169 Features of your vehicle To cancel the system while parking ■ Manual transaxle CAUTION Press the Smart Parking Assist System button or turn the steering wheel to the Always check the surrounding left or right. before releasing the brake pedal. WARNING Always be careful while parking for other vehicles or pedestrians.
  • Page 170 Features of your vehicle The system may be cancelled in the below conditions: • Ignoring the gear shift message and drive the vehicle approximately 150cm (59in). • The front and rear Parking Assist System warning sound (distance from object is within 30cm: continuous beep) is heard at the same time.
  • Page 171 Smart Parking Assist System, the space Parking Assist System will operate - When you hold the steering wheel after 2 seconds. firmly If you notice any problem, have your vehicle checked by an authorized HYUNDAI dealer as soon as possible. 4 93...
  • Page 172 Features of your vehicle REARVIEW CAMERA (IF EQUIPPED) The rearview camera will activate when WARNING the back-up light is ON with the ignition switch ON and the shift lever in the R • This system is a supplementary (Reverse) position. function only.

  • Page 173: Hazard Warning Flasher

    Features of your vehicle HAZARD WARNING FLASHER OVF061001 The hazard warning flasher should be used whenever you find it necessary to stop the car in a hazardous location. When you must make such an emer- gency stop, always pull off the road as far as possible.
  • Page 174 Features of your vehicle LIGHTING Battery saver function Headlight (Headlamp) escort Headlight (Headlamp) welcome function (if equipped) function (if equipped) • The purpose of this feature is to pre- vent the battery from being dis- The headlights (and/or taillights) remain When the headlight switch is in the ON or charged.

  • Page 175: Light Switch

    Features of your vehicle Smart cornering light While driving the corner, for your sight and safety, the smart cornering light turns on automatically. The system will operate automatically as follows: • When vehicle speed is under 10km/h and steering wheel angle approximate- ly 80 degrees.
  • Page 176 Features of your vehicle CAUTION • Never place anything over the sensor (1) located on the instru- ment panel, this will ensure better auto-light system control. • Don’t clean the sensor using a window cleaner, the cleaner may leave a light film which could interfere with sensor operation.
  • Page 177 Features of your vehicle ✽ ✽ NOTICE Traffic change (for Europe) (if equipped) • The high-beam indicator will light Use this function when you visit a coun- when the headlight high beams are try with opposite traffic direction. switched on. Follow the below procedure.
  • Page 178 Features of your vehicle One-touch lane change function (if equipped) To activate an one-touch lane change function, move the turn signal lever slightly and then release it. The lane change signals will blink 3 times. ✽ ✽ NOTICE If an indicator flash is abnormally quick or slow, bulb may be burned out or have a poor electrical connection in the cir- cuit.
  • Page 179 Features of your vehicle ■ Type A CAUTION When in operation, the fog lights consume large amounts of vehicle electrical power. Only use the fog lights when visibility is poor. OVF041124 ■ Type B OVF041125 Rear fog light (if equipped) To turn on the rear fog lights do one of the following: •...

  • Page 180: Headlight Leveling Device*

    Features of your vehicle Daytime running light ■ The higher the number of the switch is Left-hand drive type positioned, the lower the headlight beam (if equipped) level. Always keep the headlight beam at Daytime Running Lights (DRL) can make the proper leveling position, or headlights it easier for others to see the front of your may dazzle other road users.
  • Page 181 Do not attempt to inspect or uously remains on, take your vehicle to keep your field of vision wide by swiveling replace the wiring yourself. an authorized HYUNDAI dealer and have and leveling the headlamp. the system checked. Change the switch to the AUTO position when the engine is running.

  • Page 182: Wiper/Washer

    Features of your vehicle WIPERS AND WASHERS A : Wiper speed control (front) Windshield wiper/washer Rear window wiper/washer · / MIST – Single wipe ■ ■ Type A Type A · O / OFF – Off · --- / INT – Intermittent wipe AUTO* –...
  • Page 183 Features of your vehicle Windshield wipers ■ To vary the speed setting, turn the speed Type A control knob (1). Operates as follows when the ignition If the wiper switch is set in AUTO mode switch is turned ON. when the ignition switch is ON, the wiper / MIST : For a single wiping cycle, will operate once to perform a self-check move the lever to this (...
  • Page 184 Features of your vehicle ■ Type A CAUTION CAUTION When washing the vehicle, set the To prevent possible damage to the wiper switch in the OFF position to washer pump, do not operate the stop the auto wiper operation. washer when the fluid reservoir is empty.
  • Page 185 Features of your vehicle Headlight washer (if equipped) ■ ■ Type A Type A If your vehicle is equipped with the head- light washer it will operate at the same time when you operate the windshield washer. It will operate when the headlight switch is in the first or second position and the ignition switch or engine OXM049103E...

  • Page 186: Interior Light

    Features of your vehicle INTERIOR LIGHT - The map lamp and room lamp will stay CAUTION on for approximately 20 minutes if a door is opened with the ignition switch Do not use the interior lights for in the ACC or LOCK/OFF position. extended periods when the engine is not running.
  • Page 187 Features of your vehicle ■ Type A OVF041134 ■ Type B OHG040128 OVF041135 Vanity mirror lamp (if equipped) Luggage room lamp Opening the cover of the vanity mirror will The luggage room lamp comes on when automatically turn on the mirror lamp. the tailgate is opened.
  • Page 188 Features of your vehicle WELCOME SYSTEM (IF EQUIPPED) Escort welcome (if equipped) Interior light When the headlight(light switch in the When the interior light switch is in the headlight or AUTO position) is on and all DOOR position and all doors (and tail- doors (and tailgate) are locked and gate) are locked and closed, the room closed, the headlight, position light and...
  • Page 189 Features of your vehicle DEFROSTER ✽ ✽ NOTICE CAUTION • If there is heavy accumulation of snow To prevent damage to the conduc- on the rear window, brush it off before tors bonded to the inside surface of operating the rear defroster. the rear window, never use sharp •...
  • Page 190 Features of your vehicle MANUAL CLIMATE CONTROL SYSTEM (IF EQUIPPED) 1. Fan speed control switch 2. Air conditioning button 3. OFF button 4. Mode selection knob 5. MAX A/C selection button 6. Air intake control button 7. Temperature control switch OVF041142...
  • Page 191 Features of your vehicle Heating and air conditioning 1. Start the engine. 2. Set the mode to the desired position. To improve the effectiveness of heat- ing and cooling: - Heating: - Cooling: 3. Set the temperature control to the desired position.
  • Page 192 Features of your vehicle Floor/Defrost-Level (A, C, D, E, F) Face-Level (B, D, F) Most of the air flow is directed to the floor Air flow is directed toward the upper body and the windshield with a small amount and face. Additionally, each outlet can be directed to the side window defrosters.
  • Page 193 Features of your vehicle ■ Front OVF041147 ■ Rear OVF041143 OVF041148 Temperature control Air intake control The temperature control switch allows The air intake control is used to select you to control the temperature of the air- the outside (fresh) air position or recircu- flow in the vehicle.
  • Page 194 Features of your vehicle ✽ ✽ NOTICE Recirculated air position WARNING With the recirculated Prolonged operation of the heater in the air position selected, • Continue using the climate con- recirculated air position (without air air from the passenger trol system in the recirculated air conditioning selected) may cause fogging compartment will be position may allow humidity to...
  • Page 195 Features of your vehicle OVF041149 OVF041187 OVF041164 Fan speed control Air conditioning (if equipped) OFF mode The ignition switch must be in the ON Press the A/C button to turn the air con- Press the OFF button to turn off the air position for fan operation.

  • Page 196: System Operation

    Features of your vehicle System operation Operation Tips Air conditioning (if equipped) • To keep dust or unpleasant fumes from All HYUNDAI Air Conditioning Systems Ventilation entering the vehicle through the venti- are filled with environmentally friendly 1. Set the mode to the position.
  • Page 197 Features of your vehicle ✽ ✽ NOTICE Air conditioning system operation tips • When using the air conditioning sys- tem, you may notice clear water drip- • If the vehicle has been parked in direct • When using the air conditioning sys- ping (or even puddling) on the ground sunlight during hot weather, open the tem, monitor the temperature gauge...

  • Page 198: Climate Control Air Filter

    Therefore, if abnormal operation is • When the air flow rate suddenly found, have the system inspected by an decreases, the system should be Blower authorized HYUNDAI dealer. checked at an authorized HYUNDAI Heater core Climate control Evaporator dealer. ✽ ✽ NOTICE...

  • Page 199: Automatic Climate Control System (If Equipped)

    Features of your vehicle AUTOMATIC CLIMATE CONTROL SYSTEM (IF EQUIPPED) ■ ■ Type A (Vehicle’s equipped with audio system) 1. Driver's temperature control button 2. Front windshield defroster button 3. Air conditioning button 4. Mode selection button 5. Fan speed control knob 6.
  • Page 200 Features of your vehicle 1. Press the AUTO button. The modes, fan speeds, air intake and air-condi- tioning will be controlled automatically by setting the temperature. 2. Set the temperature to the desired temperature. 3. To turn the automatic operation off, select any button of the following: •...
  • Page 201 Features of your vehicle Manual heating and air condition- The heating and cooling system can be controlled manually by pressing buttons or turning knob(s) other than the AUTO button. In this case, the system works sequentially according to the order of buttons or knob(s) selected.
  • Page 202 Features of your vehicle ■ Front Face-Level (B, D, F) Air flow is directed toward the upper body and face. Additionally, each outlet can be controlled to direct the air discharged from the outlet. Floor-Level (A, C, D, E) OVF041147 Most of the air flow is directed to the ■...
  • Page 203 Features of your vehicle 2. Operate the driver side temperature ■ ■ ■ ■ Driver’s side Passenger’s side Type A Type B control to adjust the driver side tem- perature. Operate the passenger side temperature control to adjust the pas- senger side temperature.
  • Page 204 Features of your vehicle ✽ ✽ NOTICE Adjusting the driver and passenger side temperature equally • If the battery has been discharged or 1. Press the DUAL button again to deac- disconnected, the temperature mode tivate DUAL mode. The passenger display will reset to Centigrade.
  • Page 205 Features of your vehicle ✽ ✽ NOTICE Recirculated air position ■ ■ ■ ■ ■ ■ ■ ■ ■ Type A With the recirculated air Prolonged operation of the heater in the position selected, air from recirculated air position (without air the passenger compart- conditioning selected) may cause fog- ment will be drawn through...
  • Page 206 Features of your vehicle ■ Type A ■ Type B WARNING • Continue using the climate control system in the recirculated air posi- tion allow humidity increase inside the vehicle which may fog the glass and obscure vis- ibility. • Do not sleep in a vehicle with the air conditioning or heating system on.
  • Page 207 Features of your vehicle System operation Ventilation 1. Set the mode to the position. 2. Set the air intake control to the outside (fresh) air position. 3. Set the temperature control to the desired position. 4. Set the fan speed control to the desired speed.
  • Page 208 ✽ ✽ NOTICE Operation Tips Air conditioning (if equipped) • To keep dust or unpleasant fumes from All HYUNDAI Air Conditioning Systems • When using the air conditioning sys- entering the vehicle through the venti- are filled with environmentally friendly...

  • Page 209: Climate Control System

    (fresh) air position is selected. If this hap- pens, have the climate control air filter replaced by an authorized HYUNDAI dealer. 4 131...
  • Page 210 • When the air flow rate suddenly found, have the system inspected by an decreases, the system should be authorized HYUNDAI dealer. checked at an authorized HYUNDAI dealer. ✽ ✽ NOTICE It is important when servicing the air conditioning system that the correct type and amount of oil and refrigerant is used.

  • Page 211: Windshield Defrosting And Defogging

    Features of your vehicle WINDSHIELD DEFROSTING AND DEFOGGING • For maximum defrosting, set the tem- WARNING Windshield perature control to the hottest position and the fan speed control to the high- heating est speed. Do not use the position during •...

  • Page 212: Automatic Climate Control System

    Features of your vehicle ■ ■ Type A Type A ■ ■ Type B Type B OVF041165 OVF041166 OVF041167 To defrost outside windshield To defrost outside windshield Automatic climate control system 1. Set the fan speed to the highest posi- 1.
  • Page 213 Features of your vehicle ✽ ✽ NOTICE This indicator illuminates when the auto defogging If the A/C off is manually selected while system senses the moisture the auto defogging system is on, the auto of inside the windshield and defogging indicator will blink 3 times to operates.

  • Page 214: Center Console Storage

    Features of your vehicle STORAGE COMPARTMENT CAUTION • To avoid possible theft, do not leave valuables in the storage compartment. • Always keep the storage com- partment covers closed while driving. Do not attempt to place so many items in the storage compartment that the storage compartment cover can not close securely.
  • Page 215 Features of your vehicle WARNING Do not put perishable food in the cool box because it may not main- tain the necessary consistent tem- perature to keep the food fresh. OVF041175 OVF041173 Cool box (if equipped) Sunglass holder You can keep beverage cans or other To open the sunglass holder, press the items cool in the glove box.
  • Page 216 Features of your vehicle ■ Front tray OVF041200 ■ Center tray OVF041199 OVF041211 Luggage side tray Luggage side partition The luggage side tray can be used for ✽ ✽ NOTICE storing small items. • To open the cover, pull up the handle The luggage side partitions can be and lift the cover.
  • Page 217 Features of your vehicle OVF041210 Rear seat floor pocket (if equipped) WARNING Do not put heavy or sharp objects in the pockets. In an accident they could come loose from the pocket and injure vehicle occupants. 4 139...

  • Page 218: Interior Features

    When the element has heated, the lighter in an ashtray with other com- will pop out to the "ready" position. bustible materials may cause a If it is necessary to replace the cigarette fire. lighter, use only a genuine HYUNDAI replacement or its approved equivalent.

  • Page 219: Cup Holder/Ashtray

    Features of your vehicle Cup holder ■ ■ Front Rear Cups or small beverage cans may be placed in the cup holders. WARNING Hot liquids • Do not place uncovered cups of hot liquid in the cup holder while the vehicle is in motion. If the hot liquid spills, you burn yourself.

  • Page 220: Power Outlet/Cigarette Lighter

    Features of your vehicle ■ Power outlet Front The power outlet is designed to provide power for mobile telephones or other devices designed to operate with vehicle electrical systems. The devices should draw less than 10 amps with the engine running.

  • Page 221: Aux, Usb And Ipod

    Features of your vehicle ✽ ✽ NOTICE WARNING When using a portable audio device Do not put a finger or a foreign ele- connected to the power outlet, noise may ment (pin, etc.) into a power outlet occur during playback. If this happens, and do not touch with a wet hand.
  • Page 222 OVF041201 floor mat in place. To avoid any Clothes hanger interference with pedal operation, HYUNDAI recommends that only the HYUNDAI floor mat designed CAUTION for use in your vehicle be • Do not hang heavy clothes, since installed. those may damage the hook.
  • Page 223 It is designed to help protect the heads of If necessary, contact your authorized the occupants by preventing objects from HYUNDAI dealer to obtain a luggage net. flying forward in frontal collisions. There are four hook holders on both side ✽...
  • Page 224 Features of your vehicle When the barrier net is not in use : WARNING 1. Remove the hook by pulling it through the large holes. • Do not put passengers in the rear seat or cargo area behind the bar- 2.
  • Page 225 Features of your vehicle OVF041194 OVF041195 OVF041196 To remove the barrier net To use the cargo security screen Cargo security screen (if equipped) 1. Press the lock release button(1) locat- 1. Pull the cargo security screen towards ed at the end of both sides. the rear of the vehicle by the handle Use the cargo security screen to hide (1).
  • Page 226 Features of your vehicle When the cargo security screen is not in WARNING use: 1. Push down the center of the cargo • Do not place objects on the cargo security screen (approximately 70 security screen. Such objects degree). may be thrown about inside the 2.
  • Page 227 Features of your vehicle Build in segmentation bar CAUTION • Put both pillars (A) from the segmenta- • The segmentation bar must be tion bar in the openings from the rail. mounted and demounted with • To move the segmentation bar, put both pillars simultaneously.
  • Page 228 Features of your vehicle CAUTION Tensile force : max. 150 kgf. for 1 shackle OVF041189 Applying the shackle on the guide rail • Put the shackle (A) in the position where the shackle is put in the rail (3). • To move the shackle, press the button (1) and move the shackle along the rail.

  • Page 229: Exterior Features

    Features of your vehicle EXTERIOR FEATURES ✽ ✽ NOTICE If the vehicle is equipped with a sunroof, be sure not to position cargo onto the roof in such a way that it could interfere with sunroof operation. CAUTION • When carrying cargo on the roof, take the necessary precautions to make sure the cargo does not damage the roof of the vehicle.
  • Page 230 Features of your vehicle WARNING • The vehicle center of gravity will be higher when items are loaded onto the roof. Avoid sudden starts, braking, sharp turns, abrupt maneuvers or high speeds that may result in loss of vehicle control or rollover resulting in an accident.

  • Page 231: Audio/Avn System

    Features of your vehicle AUDIO SYSTEM ✽ ✽ NOTICE CAUTION If you install an aftermarket HID head • Before entering a place with a low lamp, your vehicle’s audio and electron- height clearance or a car wash, ic device may malfunction. remove the antenna by rotating it counterclockwise.
  • Page 232 Features of your vehicle MODE (1) If the SEEK button is pressed for less than 0.8 second, it will work as follows in Press the button to select Radio or CD each mode. (compact disc). RADIO mode VOL ( ) (2) It will function as the PRESET STATION •...
  • Page 233 Features of your vehicle FM reception AM radio reception FM radio station JBM001 JBM002 JBM003 How vehicle audio works AM broadcasts can be received at FM broadcasts are transmitted at high greater distances than FM broadcasts. frequencies and do not bend to follow the AM and FM radio signals are broadcast This is because AM radio waves are earth's surface.
  • Page 234 Features of your vehicle Using a cellular phone or a two- way radio When a cellular phone is used inside the vehicle, noise may be produced from the audio equipment. This does not mean that something is wrong with the audio equipment.
  • Page 235 Features of your vehicle ✽ ✽ NOTICE Care of disc (if equipped) • Keep CDs in their cases after use to Playing an protect them from scratches or dirt. Incompatible Copy • If the temperature inside the car is too •...
  • Page 236 Features of your vehicle ■ ■ ■ ■ CD Player : AC100DFE/AC110DFE CD Changer : AC600DFE/AC610DFE ❋There will be no ® logo if the Bluetooth feature is not supported. VF_AC100DFE_EU / VF_AC600DFE_EU...
  • Page 237 Features of your vehicle • Press buttons more SEEK Button than 0.8 seconds or longer to save the SEEK • When the is pressed, it will TRACK current station to the respective button automatically tune to the next lower with a beep. station.
  • Page 238 Features of your vehicle • MEDIA Select default display of MP3 play infor- mation. “Folder/File” or “Artist/Title” can be selected. • SCROLL Select whether long file names are scrolled continuously (On) or just once (Off). VF_EU_RADIO • RDS(if available) Button RDS menu includes News/AF/Region/ •...
  • Page 239 Features of your vehicle • AF(AF MENU indication is possible with • Time RDS MENU) Select “Time” button to enter Time setting. Select this item to turn the AF(Alternate Adjust the hour and press the Frequency) feature ON or OFF. knob to set.
  • Page 240 Features of your vehicle • MIDDLE Control • BALANCE Control Press and turn the Press and turn the MIDDLE BALANCE knob to adjust the middle setting. In this knob to adjust the left/right volume set- state, turn the knob clockwise to ting.
  • Page 241 Features of your vehicle SEEK Button (REPEAT) • Press button for less than TRACK 0.8 seconds to play the next song. Press this button for less than 0.8 sec- SEEK onds to activate ‘RPT’ mode and more • Press button for 0.8 seconds TRACK than 0.8 seconds to activate ‘FLD.RPT’...
  • Page 242 Features of your vehicle 11. CD Slot Press knob to move to the Insert a CD label side up and gently push folder displayed. in while ignition switch is on ACC or ON. The audio automatically switches to CD & Knob mode and begins to play the CD.
  • Page 243 Features of your vehicle NOTE: 2. Folder playing order : ❋ If no song file is contained in the Order of playing files (folders) : folder, that folder is not displayed. 1. Song playing order : sequen- VF_AC600DFE_CDC tially. LOAD Button (CD Changer : AC600DFE/AC610DFC)) Push...
  • Page 244 Features of your vehicle (Continued) (Continued) CAUTION IN USING • An encrypted MP3 PLAYER is not • If you disconnect the external USB USB DEVICE recognizable. device during playback in USB • To use an external USB device, mode, the external USB device can •...
  • Page 245 Features of your vehicle (Continued) (Continued) • If the USB device is divided by • Please avoid using USB memory logical drives, only the music files products which can be used as on the highest-priority drive are key chains or cellular phone recognized by car audio.
  • Page 246 Features of your vehicle Press the button for 0.8 seconds or • Press this button for 0.8 seconds or longer longer to play the song in reverse to repeat all songs in current folder. direction in fast speed. • To cancel REPEAT, press this button SEEK again.
  • Page 247 Features of your vehicle & Knob • Turn this knob clockwise to browse songs after current song, or counter clockwise to browse songs before cur- rent song. To play the displayed song, press the knob. • Pressing this knob without turning enters to AUDIO CONTROL mode.
  • Page 248 • When the iPod cable is connected, iPod DEVICE the system can be switched to AUX • Some iPod models might not sup- • The Hyundai iPod Power Cable is mode even without iPod device port the communication protocol needed in order to operate iPod and may cause noise.
  • Page 249 Features of your vehicle SEEK Button (MENU) • Press button for 0.8 seconds TRACK Moves to the upper category from cur- or longer to initiate reverse direction high rently played category of the iPod. speed sound search of current song. SEEK To move to (play) the category (song) •...
  • Page 250 Features of your vehicle VF_EU_iPod & Knob When you rotate the knob clockwise, it will display the songs (category) ahead of the song currently played (category in the same level). Also, when you rotate the knob counter- clockwise, it will display the songs (cate- gory) before the song currently played (category in the same level).
  • Page 251 Features of your vehicle (continued) CAUTION IN USING • Do not place the phone near or ® BLUETOOTH CELLULAR inside metallic objects, otherwise PHONE ® communications with Bluetooth • Do not use a cellular phone or system or cellular service sta- ®...
  • Page 252 A2DP feature) wirelessly. ® Bluetooth SIG, Inc. and any use of • Voice recognition engine such marks by Hyundai is under ® Bluetooth system supports 10 types of license. A Bluetooth enabled cell languages: ® phone is required to use Bluetooth FRENCH wireless technology.
  • Page 253 Features of your vehicle ■ ® Voice Recognition Activation • At any time if you say “help”, the system ■ Bluetooth Language Setting will announce what commands are • The voice recognition engine contained The system language can be changed by available.
  • Page 254 Features of your vehicle ■ Voice Operation Tip 5) Bluetooth off • Pairing phone ® - To skip the information message, Press Before using Bluetooth features, the To get the best performance out of the again and then a beep is heard. phone must be paired (registered) to the Voice Recognition System, observe the audio system.
  • Page 255 Features of your vehicle 3. Say “Pair Phone” - By Manual Operation: name displayed on your phone from i40 to i401 and i402. 4. Proceed at next step. 1. Select “Pair” in PHONE menu, then proceed from step5. Refer to your phone’s User’s Guide, or 5.
  • Page 256 Features of your vehicle - By Manual Operation: 4. Say the name or number of desired - By Voice Command: phone from the list. 1. Select “Select” in PHONE menu, then 1. Press button. select desired phone from the list. 5.
  • Page 257 Features of your vehicle ■ • Changing Language ® Phone Book (In-Vehicle) • Turning Bluetooth ON/OFF - By Voice Command: ® • Adding Entry Bluetooth system can be enabled (ON) or disabled (OFF) by this menu. 1. Select “Language” in PHONE menu, Phone numbers and voice tags can be adjust language to desired language ®...
  • Page 258 Features of your vehicle ✽ ✽ NOTICE • Adding Entry by Phone • Deleting Name 1. Press button. The registered names can be deleted. - The system can recognize single digits from zero to nine. Numbers that are 2. Say “Phonebook”. 1.
  • Page 259 Features of your vehicle ■ ■ • Dialing by Number Receiving a Phone Call Talking on the Phone A phone call can be made by dialing the When receiving a phone call, a ringtone When talking on the phone, “Active Call” spoken numbers.
  • Page 260 Features of your vehicle ® NOTE: ■ Bluetooth Audio Music Streaming • In addition to streaming MP3 files, ® The audio system supports Bluetooth all music and sound files your cellu- A2DP (Audio Advanced Distribution lar phone supports can be played Profile) and AVRCP (Audio Video by the audio system.
  • Page 261 Features of your vehicle ■ Key matrix Class Connected Paired H/P Disconnected Incoming Call Outgoing Call 2nd Call Active Call Empty Normal mode BT SETUP menu 2nd call 2nd Call Not Paired Not Connecting Accept Call 1st Call:waiting 2nd Call:waiting SHORT 2nd Call:active 1st Call:active...
  • Page 262 Before driving / 5-3 Key positions / 5-4 Engine start/stop button / 5-8 ISG (Idle Stop and Go) system / 5-14 Manual transaxle / 5-19 Automatic transaxle / 5-22 Brake system / 5-29 Cruise control system / 5-48 Speed limit control system / 5-53 Lane keeping assist system (LKAS) / 5-56 Economical operation / 5-63 Driving your vehicle...

  • Page 263: Driving Your Vehicle

    HYUNDAI dealer. • Do not run the engine in an enclosed area.

  • Page 264: Seat Belts

    Driving your vehicle BEFORE DRIVING Before entering vehicle Necessary inspections Before starting • Be sure that all windows, outside mir- Fluid levels, such as engine oil, engine • Close and lock all doors. ror(s), and outside lights are clean. coolant, brake fluid, and washer fluid •...

  • Page 265: Key Positions

    Driving your vehicle KEY POSITIONS ■ Type A WARNING WARNING - Driving under the influence of alcohol or • When you intend to park or stop drugs the vehicle with the engine on, be careful not to depress the accel- Drinking and driving is dangerous.
  • Page 266 Driving your vehicle Ignition switch position WARNING - Ignition key The warning lights can be checked LOCK before the engine is started. This is the • Never turn the ignition switch to The steering wheel locks to protect normal running position after the engine LOCK or ACC while the vehicle is against theft.
  • Page 267 Driving your vehicle Starting the engine Starting the gasoline engine CAUTION 1. Make sure the parking brake is WARNING If the engine stalls while you are in applied. motion, do not attempt to move the 2. Manual Transaxle - Depress the Always wear appropriate shoes shift lever to the P (Park) position.
  • Page 268 Driving your vehicle Starting and stopping the engine for tur- Starting the diesel engine bocharger intercooler Glow indicator light To start the diesel engine when the 1. Do not race or accelerate the engine engine is cold, it has to be pre-heated immediately after starting.
  • Page 269 (ON position), stop not solved, have it checked by an author- the vehicle then press the engine OVF051001 ized HYUNDAI dealer. start/stop button. Illuminated engine start/stop but- In addition, if the engine start/stop button is in the OFF position after the driver's...
  • Page 270 Driving your vehicle ACC(Accessory) CAUTION You are able to turn off the engine (START/RUN) or vehicle power (ON), only when the vehicle is not in motion. In an emergency situation Orange Blue while the vehicle is in motion, you are With manual transaxle able to turn the engine off and to the With manual transaxle...
  • Page 271 Driving your vehicle ✽ ✽ NOTICE START/RUN (Continued) If you leave the engine start/stop button • Never reach for the engine start/ in the ACC or ON position for a long stop button or any other controls time, the battery will discharge. through the steering wheel while the vehicle is in motion.
  • Page 272 Driving your vehicle Starting the engine Starting the gasoline engine Starting the diesel engine 1. Carry the smart key or leave it inside To start the diesel engine when the the vehicle. engine is cold, it has to be pre-heated WARNING before starting the engine and then have 2.
  • Page 273 Driving your vehicle Starting and stopping the engine for tur- • Even if the smart key is in the vehicle, bocharger intercooler if it is far away from you, the engine Glow indicator light may not start. 1. Do not race or accelerate the engine immediately after starting.
  • Page 274 Driving your vehicle CAUTION CAUTION If the engine stalls while the vehicle Do not press the engine start/stop is in motion, do not attempt to move button for more than 10 seconds the shift lever to the P (Park) posi- except when the stop lamp fuse is tion.
  • Page 275 Driving your vehicle ISG (IDLE STOP AND GO) SYSTEM (IF EQUIPPED) Your vehicle may be equipped with the ■ ■ ■ ■ Type A Type B Type A Type B ISG system, which reduces fuel con- sumption by automatically shutting down the engine, when the vehicle is at a standstill.
  • Page 276 Driving your vehicle ■ ■ Type A Type B ■ ■ Type A Type B OVF051031 OVF051038 OVF051035 ✽ ✽ NOTICE Auto start (Continued) • A message "Auto Start Deactivated If you unfasten the seatbelt or open the To restart the engine from idle stop Start Manually"...
  • Page 277 Driving your vehicle The engine will also restart automati- Condition of ISG system opera- ■ ■ Type A Type B cally without the driver’s any actions tion if the following occurs: The ISG system will operate under - The fan speed of manual climate con- the following condition: trol system is set above the 3rd position - The driver’s seat belt is fastened.
  • Page 278 Driving your vehicle ISG system malfunction The system may not operate when: The ISG related sensors or system error occurs. The following will happen: • The yellow AUTO STOP ( ) indica- tor on the instrument cluster will stay on after blinking for 5 seconds. ■...
  • Page 279 HYUNDAI dealer as soon as possible. Before leaving the car or doing any- • When the ISG OFF button light comes thing in the engine room area, stop on, it may stop illuminating after driv-...
  • Page 280 Driving your vehicle MANUAL TRANSAXLE (IF EQUIPPED) • Depress the clutch pedal down fully CAUTION while shifting, then release it slowly. • When downshifting from 5 (Fifth) If your vehicle is equipped with an igni- gear to 4 (Fourth) gear, caution tion lock switch, the engine will not should be taken not to inadver- start when starting the engine without...
  • Page 281 Driving your vehicle • During cold weather, shifting may be Using the clutch WARNING difficult until the transaxle lubricant has The clutch pedal should be depressed all warmed up. This is normal and not the way to the floor before shifting, then •...
  • Page 282 Driving your vehicle Downshifting Good driving practices WARNING When you must slow down in heavy traf- • Never take the vehicle out of gear and fic or while driving up steep hills, down- • Always buckle-up! In a collision, coast down a hill. This is extremely shift before the engine starts to labor.
  • Page 283 Driving your vehicle AUTOMATIC TRANSAXLE (IF EQUIPPED) Automatic transaxle operation The highly efficient automatic transaxle has 6 forward speeds and one reverse speed. The individual speeds are select- ed automatically, depending on the posi- tion of the shift lever. ✽ ✽ NOTICE The first few shifts on a new vehicle, if the battery has been disconnected, may be somewhat abrupt.
  • Page 284 Driving your vehicle For smooth operation, depress the brake Transaxle ranges CAUTION pedal when shifting from N (Neutral) to a The indicator lights in the instrument forward or reverse gear. • To avoid damage your cluster displays the shift lever position transaxle, do not accelerate the when the ignition switch is in the ON engine in R (Reverse) or any for-...
  • Page 285 Driving your vehicle R (Reverse) N (Neutral) WARNING Use this position to drive the vehicle The wheels and transaxle are not backward. engaged. The vehicle will roll freely even • Shifting into P (Park) while the on the slightest incline unless the parking vehicle is in motion will cause the brake or service brakes are applied.

  • Page 286: Paddle Shifter

    Driving your vehicle ✽ ✽ NOTICE • In sports mode, the driver must exe- cute upshifts in accordance with road conditions, taking care to keep the engine speed below the red zone. • In sports mode, only the 6 forward gears can be selected.

  • Page 287: Shift Lock System

    3. Have your vehicle inspected by an If you pull the [+] and [-] paddle shifters of the P (Park) position into anoth- authorized HYUNDAI dealer immedi- at the same time, you cannot shift the er position to avoid inadvertent ately.
  • Page 288 Driving your vehicle Ignition key interlock system Good driving practices • Exercise extreme caution when driving (if equipped) on a slippery surface. Be especially • Never move the shift lever from P careful when braking, accelerating or The ignition key cannot be removed (Park) or N (Neutral) to any other posi- shifting gears.
  • Page 289 Driving your vehicle Moving up a steep grade from a stand- WARNING WARNING ing start To move up a steep grade from a stand- • Always buckle-up! In a collision, If your vehicle becomes stuck in ing start, depress the brake pedal, shift an unbelted occupant is signifi- snow, mud, sand, etc., then you the shift lever to D (Drive).

  • Page 290: Brake System

    Driving your vehicle BRAKE SYSTEM Power brakes (Continued) WARNING - Brakes Your vehicle has power-assisted brakes • Always, confirm the position of that adjust automatically through normal • Do not drive with your foot rest- the brake and accelerator pedal usage.
  • Page 291 Driving your vehicle In the event of brake failure Disc brakes wear indicator CAUTION If service brakes fail to operate while the When your brake pads are worn and new • To avoid costly brake repairs, do vehicle is in motion, you can make an pads are required, you will hear a high- not continue to drive with worn emergency stop with the parking brake.
  • Page 292 Driving your vehicle ✽ ✽ NOTICE On a steep incline or when pulling a trailer if the vehicle does not stand still, do as follows: 1. Apply the EPB. 2. Pull up the EPB switch for more than 3 seconds. CAUTION Do not operate the parking brake while the vehicle is moving except...
  • Page 293 R (Rear) or D (Drive). • For your safety, depress the brake HYUNDAI dealer. pedal and release the parking brake • Shift lever in N (Neutral) • Do not drive your vehicle with the...
  • Page 294 Driving your vehicle EPB (electric parking brake) may be ■ ■ Type A Type B WARNING automatically applied when: • The EPB is overheated • To prevent unintentional move- ment when stopped and leaving • Requested by other systems the vehicle, do not use the shift ✽...
  • Page 295 Driving your vehicle ■ ■ ■ ■ Type A Type B Type A Type B CAUTION • A click sound may be heard while operating or releasing the EPB, but these conditions are normal and indicate that the EPB is func- tioning properly.
  • Page 296 HYUNDAI dealer. If this occurs, have your vehicle checked up. If the EPB warning does not by an authorized HYUNDAI dealer as go off, have the system checked soon as possible. by an authorized HYUNDAI dealer.
  • Page 297 HYUNDAI dealer by towing the vehicle vehicle to a complete stop by depressing and have the system checked. the brake pedal.
  • Page 298 Driving your vehicle Leaving If you press the accelerator pedal with the shift lever in R (Reverse), D (Drive) or sports mode, the Auto Hold will be released automatically and the vehicle will start to move. The indicator changes from green to white. WARNING When driving off from Auto Hold by depressing the accelerator pedal,...
  • Page 299 Hold may not work properly. - The vehicle is in a standstill for more Take your vehicle to an authorized than 10 minutes HYUNDAI dealer and have the sys- - The vehicle is standing on a steep tem checked. slope...
  • Page 300 Driving your vehicle Anti-lock brake system (ABS) The ABS continuously senses the speed (Continued) of the wheels. If the wheels are going to The safety features of an ABS (or lock, the ABS system repeatedly modu- WARNING ESP) equipped vehicle should not lates the hydraulic brake pressure to the ABS (or ESP) will not prevent acci- be tested by high speed driving or...
  • Page 301 If the ABS is malfunctioning. light stays on, you may have a • Do not pump your brakes! problem with your ABS. Contact • Have the battery recharged before an authorized HYUNDAI dealer as driving the vehicle. soon as possible.

  • Page 302: Electronic Stability Program (Esp) Button

    Driving your vehicle ■ The Electronic Stability Program (ESP) Type A WARNING system is an electronic system designed to help the driver maintain vehicle control Never drive too fast for the road under adverse conditions. It is not a conditions or too quickly when cor- substitute for safe driving practices.
  • Page 303 Driving your vehicle ESP operation When operating ESP operation off When the ESP is in operation, ESP ON condition ESP OFF state ESP indicator light blinks. • When the ignition is turned • To cancel ESP operation, ON, ESP and ESP OFF indi- •...
  • Page 304 Driving your vehicle ESP OFF usage ■ ESP indicator light WARNING When driving The Electronic Stability Program • ESP should be turned on for daily driv- system is only a driving aid; use ing whenever possible. precautions for safe driving by •...
  • Page 305 This is only the weather and on a slippery road. authorized HYUNDAI dealer and have effect of brake control and indicates noth- • Driving with varying tire or wheel the system checked.
  • Page 306 Driving your vehicle Hill-start assist control (HAC) Emergency Stop Signal (ESS) CAUTION (if equipped) A vehicle has the tendency to slip back The Emergency Stop Signal (ESS) on a steep hill when it starts to go after The Emergency Stop Signal system system will not work if the hazard stopping.
  • Page 307 HYUNDAI dealer for (manual transaxle). If your vehicle is pedestrians. assistance.
  • Page 308 Driving your vehicle • Under some conditions your parking brake can freeze in the engaged posi- tion. This is most likely to happen when there is an accumulation of snow or ice around or near the rear brakes or if the brakes are wet.
  • Page 309 Driving your vehicle CRUISE CONTROL SYSTEM (IF EQUIPPED) ■ ■ Type A Type B CAUTION WARNING During cruise-speed driving of a • If the cruise control is left on, manual transaxle vehicle, do not (cruise indicator light is illuminat- shift into neutral without depress- ed), the cruise control can be ing the clutch pedal, since the switched on accidentally.

  • Page 310: Cruise Control Switch* / Speed Limiter Switch

    Driving your vehicle ■ ■ ■ Type A Type A Type A OVF051012 OVF051013 OVF051015 ■ ■ ■ Type B Type B Type B OVF051070 OVF051020 OVF051022 Cruise control switch To set cruise control speed: 3. Move the lever down (to SET-), and release it at the desired speed.
  • Page 311 Driving your vehicle ■ ■ To temporarily accelerate with the Type A Type A cruise control on: If you want to speed up temporarily when the cruise control is on, depress the accelerator pedal. Increased speed will not interfere with cruise control operation or change the set speed.
  • Page 312 Driving your vehicle ■ Each of these actions will cancel cruise ■ Type A Type A control operation (the cruise set indicator light will go off), but it will not turn the system off. If you wish to resume cruise control operation, move up the lever (to RES+) located on your steering wheel.
  • Page 313 Driving your vehicle To turn cruise control off, do one of the following: • Press the cruise /CRUISE button (the cruise indicator light will illumi- nate). • Turn the ignition off. Both of these actions cancel cruise con- trol operation. If you want to resume cruise control operation, repeat the steps provided in “To set cruise control speed”...
  • Page 314 Driving your vehicle SPEED LIMIT CONTROL SYSTEM (IF EQUIPPED) You can set the speed limit when you do not want to drive over a specific speed. If you drive over the preset speed limit, the warning system operates (set speed limit will blink and chime will sound) until the vehicle speed returns within the speed limit.
  • Page 315 Driving your vehicle ■ ■ ■ ■ Type A Type B Type A Type B OVF051018 OVF051025 OVF051026 2. Move the lever down (to SET-). The set speed limit will be displayed. To drive over the preset speed limit you must depress hard on the accelerator 3.
  • Page 316 • Press the cruise switch (If you press If this occurs, have the system cruise switch, the cruise system will checked by an authorized HYUNDAI turn on) dealer as soon as possible. If you press the CANCEL switch once, the set speed limit will cancel, but it will not turn the system off.
  • Page 317 Driving your vehicle LANE KEEPING ASSIST SYSTEM (LKAS) (IF EQUIPPED) (Continued) WARNING • The system detects lane markers • The steering wheel is not contin- and controls the steering wheel uously controlled so if the vehicle by a camera, therefore, if the lane speed is very fast when leaving a markers are hard to detect, the lane the vehicle may not be con-...
  • Page 318 Driving your vehicle ■ ■ Lane undetected Lane detected OVF051072 OVF051059 OVF051057 LKAS activation LKAS operation • If the system detects a lane, the color changes from black to white. • The LKAS screen will appear on the • To turn on the LKAS, push the button LCD display if the system is activated.
  • Page 319 Driving your vehicle ■ ■ ■ ■ Left lane Right lane Left lane detected Right lane detected ■ ■ Left lane Right lane OVF051062 OVF051058 OVF051063 Warning • If the system detects the left lane, the • If all the conditions to activate LKAS is left lane color will change from black to •...
  • Page 320 Driving your vehicle WARNING • The driver is responsible for accurate steering. • Turn off the system and drive the vehicle personally in below situa- tions. - In bad weather - In bad road condition - When the steering wheel needs to be controlled by the driver frequently.
  • Page 321 Driving your vehicle The system will be cancelled when: DRIVER'S ATTENTION • Vehicle speed is below 60 km/h (37.3 The driver must be cautious in the mph) and over 150 km/h (93.2 mph). below situations for the system may not •...
  • Page 322 LKAS is not working properly. Take your with an audible warning. If the problem distinguish due to dust or grease. vehicle to an authorized HYUNDAI deal- continues the LKAS fail indicator will • The lane marker is hard to distinguish er and have the system checked.
  • Page 323 • Check if there is foreign matter on the lane. camera lens • If the LDWS is operating the indicator (white) will illuminate. If the problem is not solved, have the • The steering wheel will not be con- vehicle checked by an authorized trolled. HYUNDAI dealer.

  • Page 324: Economical Operation

    Driving your vehicle ECONOMICAL OPERATION Your vehicle's fuel economy depends • Do not "ride" the brake or clutch pedal. • Keep your vehicle in good condition. mainly on your style of driving, where you This can increase fuel consumption For better fuel economy and reduced drive and when you drive.
  • Page 325 Therefore, have an authorized run for 10 to 20 seconds prior to plac- HYUNDAI dealer perform scheduled ing the vehicle in gear. In very cold inspections and maintenance. weather, however, give your engine a slightly longer warm-up period.

  • Page 326: Special Driving Conditions

    Driving your vehicle SPECIAL DRIVING CONDITIONS Hazardous driving conditions Rocking the vehicle WARNING - Downshifting When hazardous driving conditions are If it is necessary to rock the vehicle to Downshifting with an automatic encountered such as water, snow, ice, free it from snow, sand, or mud, first turn transaxle, while driving on slippery mud, sand, or similar hazards, follow the steering wheel right and left to clear...
  • Page 327 Driving your vehicle Smooth cornering Driving at night WARNING - Spinning tires Avoid braking or gear changing in cor- Because night driving presents more Do not spin the wheels, especially ners, especially when roads are wet. hazards than driving in the daylight, here at speeds more than 56 km/h (35 Ideally, corners should always be taken are some important tips to remember:...
  • Page 328 Driving your vehicle Driving in the rain Driving in flooded areas Highway driving Rain and wet roads can make driving Avoid driving through flooded areas Tires dangerous, especially if you’re not pre- unless you are sure the water is no high- Adjust the tire inflation pressures to pared for the slick pavement.
  • Page 329 Driving your vehicle Fuel, engine coolant and engine oil WARNING High speed travel consumes more fuel than urban motoring. Do not forget to • Underinflated overinflated check both engine coolant and engine tires can cause poor handling, oil. loss of vehicle control, and sud- den tire failure leading to acci- dents, injuries, and even death.

  • Page 330: Winter Driving

    Driving your vehicle WINTER DRIVING Snowy or Icy conditions Snow tires If you mount snow tires on your vehicle, To drive your vehicle in deep snow, it may make sure they are radial tires of the be necessary to use snow tires or to same size and load range as the original install tire chains on your tires.
  • Page 331 Driving your vehicle Chain installation CAUTION When installing chains, follow the manu- • Make sure the snow chains are facturer's instructions and mount them as the correct size and type for your tightly as you can. Drive slowly with tires. Incorrect snow chains can chains installed.
  • Page 332 7. The level of charge in your battery can pension, body and wheels. be checked by an authorized HYUNDAI • Stop driving and retighten the dealer or a service station. chains any time you hear them hitting the vehicle.
  • Page 333 Don't let ice and snow accumu- accordance with instructions on the con- late underneath tainer. Window washer anti-freeze is available from an authorized HYUNDAI Under some conditions, snow and ice dealer and most auto parts outlets. Do can build up under the fenders and inter- not use engine coolant or other types of fere with the steering.

  • Page 334: Trailer Towing

    Ask an too heavy, the brakes may not work exceeded by not more than 10 % or authorized HYUNDAI dealer for further well - or even at all. You and your 100 kg (220.4 lbs), whichever value is details before towing.
  • Page 335 Load-pulling components such as the • A HYUNDAI accessory trailer hitch is engine, transaxle, wheel assemblies, and available at an authorized HYUNDAI tires are forced to work harder against dealer.
  • Page 336 Driving your vehicle Safety chains Trailer brakes Driving with a trailer should always attach chains If your trailer is equipped with a braking Towing a trailer requires a certain amount of experience. Before setting out between your vehicle and your trailer. system, make sure it conforms to your for the open road, you must get to know Cross the safety chains under the tongue...
  • Page 337 Always back up slowly Use only an approved trailer wiring har- and, if possible, have someone guide ness. you. An authorized HYUNDAI dealer can assist you in installing the wiring harness.
  • Page 338 Driving your vehicle Driving on grades CAUTION WARNING Reduce speed and shift to a lower gear • When towing a trailer on steep before you start down a long or steep Failure to use an approved trailer grades (in excess of 6%) pay downgrade.
  • Page 339 Driving your vehicle Parking on hills However, if you ever have to park your WARNING trailer on a hill, here is how to do it: - Parking brake Generally, if you have a trailer attached to your vehicle, you should not park your 1.
  • Page 340 Driving your vehicle When you are ready to leave after park- Maintenance when trailer towing CAUTION ing on a hill Your vehicle will need service more often 1. With the manual transaxle in Neutral • Due to higher load during trailer when you regularly pull a trailer.
  • Page 341 (132) (176) (176) (154) • When towing a trailer, be sure to con- device kg (Ibs.) sult an authorized HYUNDAI dealer for Recommended distance from further information additional requirements such as a towing kit, etc. rear wheel center to coupling 1180 (46.4)
  • Page 342 Driving your vehicle The trailer tongue should weigh a maxi- mum of 10% of the total loaded trailer weight, within the limits of the maximum permissible trailer tongue load. After you've loaded your trailer, weigh the trail- er and then the tongue, separately, to see if the weights are proper.

  • Page 343: Vehicle Weight

    Driving your vehicle VEHICLE WEIGHT This section will guide you in the proper GAW (Gross axle weight) Overloading loading of your vehicle and/or trailer, to This is the total weight placed on each keep your loaded vehicle weight within its axle (front and rear) - including vehicle WARNING - Vehicle weight...
  • Page 344 Road warning / 6-2 In case of an emergency while driving / 6-3 If the engine does not start / 6-4 Emergency starting / 6-5 If the engine overheats / 6-7 If you have a flat tire / 6-8 Tire pressure monitoring system (TPMS) / 6-16 If you have a flat tire (with TireMobilityKit) / 6-21 Towing / 6-26 Emergency commodity / 6-30...

  • Page 345: Road Warning

    What to do in an emergency ROAD WARNING It should be used whenever emergency repairs are being made or when the vehi- cle is stopped near the edge of a road- way. Press the flasher switch with the ignition switch in any position. The flasher switch is located in the center console switch panel.

  • Page 346: In Case Of An Emergency While Driving

    When the vehicle has slowed not equipped with a ignition lock authorized HYUNDAI dealer or seek to such a speed that it is safe to do so, switch, the vehicle can move forward other qualified assistance.

  • Page 347: If The Engine Does Not Start

    4. If the engine still does not start, call an 4. Check the starter connections to be authorized HYUNDAI dealer or seek sure they are securely tightened. other qualified assistance. 5. Do not push or pull the vehicle to start it.

  • Page 348: Emergency Starting

    What to do in an emergency EMERGENCY STARTING Jump starting ■ Engine compartment WARNING - Battery Jump starting can be dangerous if done Jumper Cables • Keep all flames or sparks away incorrectly. Therefore, to avoid harm to from the battery. The battery pro- yourself or damage to your vehicle or battery, follow the jump starting proce- duces hydrogen gas which may...
  • Page 349 4. Connect the jumper cables in the exact not apparent, you should have your vehi- teries are maintenance-free and sequence shown in the illustration. First cle checked by an authorized HYUNDAI should only be serviced by an connect one end of a jumper cable to the dealer.

  • Page 350: If The Engine Overheats

    (manual heating happens again, call an author- the engine immediately and call the transaxle) and set the parking brake. If ized HYUNDAI dealer for assistance. nearest authorized HYUNDAI dealer the air conditioning is on, turn it off. for assistance. 3. If engine coolant is running out under...
  • Page 351 What to do in an emergency IF YOU HAVE A FLAT TIRE Jacking instructions WARNING - Changing tires The jack is provided for emergency tire changing only. • Never attempt vehicle repairs in the traffic lanes of a public To prevent the jack from “rattling” road or highway.
  • Page 352 What to do in an emergency (Continued) • The vehicle can easily roll off jack causing serious injury or death. No person should place any portion of their body under a vehicle that is supported only by a jack; use vehicle support stands. •...
  • Page 353 What to do in an emergency WARNING - Changing a tire • To prevent vehicle movement while changing a tire, always set the parking brake fully, and always block the wheel diagonally opposite the wheel being changed. • We recommend that wheels of the vehicle be chocked, and that no person...
  • Page 354 What to do in an emergency 9. Loosen the wheel nuts and remove them with your fingers. Slide the wheel off the studs and lay it flat so it cannot roll away. To put the wheel on the hub, pick up the spare tire, line up the holes with the studs and slide the wheel onto them.
  • Page 355 Then double-check each nut for tightness. After changing wheels, have authorized HYUNDAI dealer tighten the wheel nuts to their proper torque as soon as possible.
  • Page 356 Refer to “Tires and wheels” in proper storage locations. If in doubt, consult an author- section 8. ized HYUNDAI dealer. 6 13...
  • Page 357 What to do in an emergency Important - use of compact spare tire When using a compact spare tire, (if equipped) WARNING observe the following precautions: Your vehicle is equipped with a com- The compact spare tire is for • Under no circumstances should pact spare tire.
  • Page 358 What to do in an emergency • Do not take this vehicle through an • The compact spare tire should not automatic car wash while the com- be used on any other wheels, nor pact spare tire is installed. should standard tires, snow tires, wheel covers or trim rings be used •...
  • Page 359 What to do in an emergency TIRE PRESSURE MONITORING SYSTEM (TPMS) (IF EQUIPPED) Each tire, including the spare (if pro- Please note that the TPMS is not a vided), should be checked monthly substitute for proper tire mainte- when cold and inflated to the inflation nance, and it is the driver’s responsi- pressure recommended by the vehi- bility to maintain correct tire pres-...
  • Page 360 (changed tire equipped with Take your vehicle to the nearest If either telltale illuminates, immedi- a sensor in the vehicle) authorized HYUNDAI dealer and ately reduce your speed, avoid hard have the system checked if any of cornering and anticipate increased the below happens: stopping distances.
  • Page 361 Left, or Rear Right tire is under-inflat- ed, the low tire pressure position tell- tales may illuminate together with the TPMS malfunction indicator. Have the system checked by an authorized HYUNDAI dealer as soon as possible to determine the cause of the problem.
  • Page 362 Have the flat tire repaired • The TPMS malfunction indicator ly 1 minute and then remain by an authorized HYUNDAI dealer may blink for approximately 1 continuously illuminated if the as soon as possible or replace the...
  • Page 363 What to do in an emergency You may not be able identify a low WARNING WARNING TPMS - Protecting tire by simply looking at it. Always TPMS use a good quality tire pressure • The TPMS cannot alert you to gauge to measure the tire's inflation severe and sudden tire dam- Tampering with, modifying, or...
  • Page 364 What to do in an emergency IF YOU HAVE A FLAT TIRE (WITH TIREMOBILITYKIT, IF EQUIPPED) Air pressure loss in the tire may adversely affect tire performance. For this reason, you should avoid abrupt steering or other driving maneuvers, especially if the vehicle is heavily loaded or if a trailer is in use.
  • Page 365 What to do in an emergency 8. Button for reducing tire inflation pressure 9. Hose to connect compressor and sealant bottle or compressor and wheel Connectors, cable and connection hose are stored in the compressor housing. WARNING Before using the TireMobilityKit, follow the instructions on the sealant bottle.
  • Page 366 What to do in an emergency Using the TireMobilityKit 9) Switch off the compressor. 1. Filling the sealant 10) Detach the hoses from the sealant bottle connector and Strictly follow the specified sequence, from the tire valve. otherwise the sealant may escape under high pressure.
  • Page 367 - To increase the inflation pres- Please contact the nearest until you can safely pull off of sure: Switch on the compressor, HYUNDAI dealer, or a workshop the side of the road. position I. To check the current that works...
  • Page 368 What to do in an emergency Notes on the safe use of the • Never leave the TireMobilityKit Technical Data TireMobilityKit unattended while it is being used. System voltage: DC 12 V Working voltage: DC 10 - 15 V • Park your car at the side of the •...
  • Page 369 If emergency towing is necessary, we CAUTION recommend having it done by an author- • Do not tow the vehicle backwards ized HYUNDAI dealer or a commercial with the front wheels on the tow-truck service. Proper lifting and tow- ground as this may cause dam- ing procedures are necessary to prevent age to the vehicle.
  • Page 370 If towing is necessary, we recommend 4. Remove the towing hook and install you to have it done by an authorized the cover after use. HYUNDAI dealer or a commercial tow truck service. 6 27...
  • Page 371 Contact an • Before emergency towing, check that ditions from which the vehicle cannot authorized HYUNDAI dealer or a the hook is not broken or damaged. be driven out under its own power. commercial tow truck service for •...
  • Page 372 What to do in an emergency Emergency towing precautions CAUTION - Automatic • Turn the ignition switch to ACC so the transaxle steering wheel isn’t locked. • If the car is being towed with all • Place the transaxle shift lever in N four wheels on the ground, it can (Neutral).
  • Page 373 What to do in an emergency EMERGENCY COMMODITY (IF EQUIPPED) There are some emergency commodities First aid kit To check the tire pressure, take the fol- in the vehicle to help you respond to the lowing steps: There are some items such as scissors, emergency situation.
  • Page 374 Engine compartment / 7-2 Maintenance services / 7-5 Owner maintenance / 7-7 Scheduled maintenance service / 7-9 Explanation of scheduled maintenance items / 7-41 Engine oil / 7-44 Engine coolant / 7-45 Brake/clutch fluid / 7-48 Washer fluid / 7-49 Fuel filter / 7-50 Air cleaner / 7-51 Climate control air filter / 7-53...

  • Page 375: Positive Battery Terminal

    Maintenance ENGINE COMPARTMENT ■ ■ Gasoline Engine (1.6L) 1. Engine oil dipstick 2. Engine oil filler cap 3. Engine coolant reservoir 4. Radiator cap 5. Brake/clutch* fluid reservoir 6. Windshield washer fluid reservoir 7. Air cleaner 8. Positive battery terminal 9.

  • Page 376: Fuse Box

    Maintenance ■ ■ Gasoline Engine (2.0L) 1. Engine oil dipstick 2. Engine oil filler cap 3. Engine coolant reservoir 4. Radiator cap 5. Brake/clutch* fluid reservoir 6. Windshield washer fluid reservoir 7. Air cleaner 8. Positive battery terminal 9. Negative battery terminal 10.
  • Page 377 Maintenance ■ ■ Diesel Engine (1.7L) 1. Engine oil dipstick 2. Engine oil filler cap 3. Engine coolant reservoir 4. Radiator cap 5. Brake/clutch* fluid reservoir 6. Windshield washer fluid reservoir 7. Fuel filter 8. Air cleaner 9. Positive battery terminal 10.

  • Page 378: Maintenance Services

    An authorized HYUNDAI dealer has fac- ✽ ✽ NOTICE shown on the following pages. You need tory-trained technicians and genuine this information to establish your compli-...
  • Page 379 People using pacemakers should authorized HYUNDAI dealer. ficial heart pacemaker to malfunction. not move than 30cm closer to the • Working under the hood with the •...

  • Page 380: Owner Maintenance

    • Note any changes in the sound of the When you stop for fuel: the owner or an authorized HYUNDAI exhaust or any smell of exhaust fumes • Check the engine oil level. dealer at the frequencies indicated to in the vehicle.
  • Page 381 Maintenance At least monthly: At least twice a year At least once a year : (i.e., every Spring and Fall) : • Check coolant level in the engine • Clean body and door drain holes. coolant reservoir. • Check radiator, heater and air condi- •...

  • Page 382: Scheduled Maintenance Service

    Maintenance SCHEDULED MAINTENANCE SERVICE Follow Normal Maintenance Schedule If your vehicle is operated under the above conditions, you should inspect, if the vehicle is usually operated where replace or refill more frequently than the none of the following conditions apply. If following Normal Maintenance Schedule.

  • Page 383: Explanation Of Scheduled Maintenance Items

    Have driven in severe conditions, more fre- issues such as hard starting. If an exces- an authorized HYUNDAI dealer replace quent oil and filter changes are required. sive amount of foreign matter accumu- any damaged or leaking parts immedi- lates in the fuel tank, the filter may ately.
  • Page 384 Vapor hose and fuel filler cap Air cleaner filter Coolant The vapor hose and fuel filler cap should A Genuine HYUNDAI air cleaner filter is The coolant should be changed at the be inspected at those intervals specified recommended when the filter is replaced.
  • Page 385 Check the linkage for bends or damage. transaxle fluid. (Refer Hyundai web site. Check the dust boots and ball joints for “Recommended lubricants deterioration, cracks, damage. (http://brakemanual.hmc.co.kr) capacities” in section 8.) Replace any damaged parts.

  • Page 386: Engine Oil

    Maintenance ENGINE OIL 5. Pull the dipstick out again and check the level. The level should be between F and L. CAUTION • Do not overfill the engine oil. It may damage the engine. • Do not spill engine oil, when adding or changing engine oil.

  • Page 387: Engine Coolant

    Checking the coolant level reservoir filled with year-round antifreeze Have engine oil and filter changed by an coolant. The reservoir is filled at the fac- authorized HYUNDAI dealer according to WARNING tory. the Maintenance Schedule at the begin- Removing radiator Check the antifreeze protection and ning of this section.
  • Page 388 Temperature coolant refill is required, see an author- Antifreeze Water shut off. This is a normal condition. ized HYUNDAI dealer for a cooling sys- -15°C (5°F) If your vehicle is equipped with tem inspection. GDI, the electric motor (cooling fan) -25°C (-13°F)
  • Page 389 Maintenance Changing the coolant Have coolant changed by an authorized HYUNDAI dealer according to the Maintenance Schedule at the beginning of this section. CAUTION Put a thick cloth or fabric around the radiator cap before refilling the coolant in order to prevent the...

  • Page 390: Brake/Clutch Fluid

    In the event the brake system kind of fluid. A few drops of miner- requires frequent additions of fluid, al-based oil, such as engine oil, in the vehicle should be inspected by your brake system can damage an authorized HYUNDAI dealer. brake system parts.

  • Page 391: Washer Fluid

    Maintenance WASHER FLUID WARNING - Coolant • Do not use radiator coolant or antifreeze in the washer fluid reservoir. • Radiator coolant can severely obscure visibility when sprayed on the windshield and may cause loss of vehicle control or damage to paint and body trim.
  • Page 392 ON position. If this warning light illuminates, take your car to an authorized HYUNDAI dealer and have drain the water and checked OVF071022 the system. Extracting air from the fuel filter...

  • Page 393: Air Cleaner

    Maintenance AIR CLEANER OVF071010 OVF071012 OVF071011 Filter replacement 1. Loosen the air cleaner cover attaching 2. Wipe the inside of the air cleaner. clips and open the cover. 3. Replace the air cleaner filter. It must be replaced when necessary, and 4.
  • Page 394 • Use a HYUNDAI genuine part. Use of nongenuine part could damage the air flow sensor or turbo charg-...
  • Page 395 Maintenance CLIMATE CONTROL AIR FILTER (IF EQUIPPED) Filter inspection If the vehicle is operated in the severely air-polluted cities or on dusty rough roads for a long period, it should be inspected more frequently and replaced earlier. When you, the owner, replace the climate control air filter, replace it per- forming the following procedure, and be careful to avoid damaging other compo-...
  • Page 396 Maintenance OVF071015 OHG070041 3. Remove the climate control air filter 4. Replace the climate control air filter. case while pressing the lock on the 5. Reassemble in the reverse order of right side of the cover. disassembly. ✽ ✽ NOTICE When replacing the climate control air filter install it properly.

  • Page 397: Wiper Blades

    Maintenance WIPER BLADES Contamination of either the windshield or Blade replacement the wiper blades with foreign matter can When the wipers no longer clean ade- reduce the effectiveness of the wind- quately, the blades may be worn or shield wipers. Common sources of con- cracked, and require replacement.
  • Page 398 Maintenance OHM078059 OHM078060 OHG070043 Front windshield wiper blade 2. Lift up the wiper blade clip. Then pull 3. Install the blade assembly in the down the blade assembly and remove it. reverse order of removal. 1. Raise the wiper arm. 4.
  • Page 399 3. Make sure the blade assembly is installed firmly by trying to pull it slight- To prevent damage to the wiper arms or other components, have an authorized HYUNDAI dealer replace the wiper blade. 7 57...
  • Page 400 Maintenance BATTERY (Continued) WARNING - Battery dangers If any electrolyte gets into your eyes, flush your eyes Always read the following with clean water for at least instructions carefully when 15 minutes and get immedi- handling a battery. ate medical attention. Keep lighted cigarettes and If electrolyte gets on your all other flames or sparks...
  • Page 401 Never use unauthorized observe the following precautions: tery authorized devices. • The battery must be removed HYUNDAI dealer to be recy- from the vehicle and placed in an cled. area with good ventilation. • When lifting a plastic-cased bat- Battery recharging •...
  • Page 402 Maintenance Reset items (Continued) Items should be reset after the battery • Disconnect the battery charger in has been discharged or the battery has the following order. been disconnected. 1. Turn off the battery charger • Auto up/down window (See section 4) main switch.
  • Page 403 Maintenance TIRES AND WHEELS Tire care WARNING - Tire underin- For proper maintenance, safety, and flation maximum fuel economy, you must Severe underinflation (70 kPa always maintain recommended tire (10 psi) or more) can lead to inflation pressures and stay within severe heat build-up, causing the load limits and weight distribution blowouts, tread separation and...
  • Page 404 • Be sure to reinstall the tire • Check the pressure of your ized HYUNDAI dealer. inflation valve caps. Without spare tire each time you check • Overinflation produces the valve cap, dirt or moisture the pressure of other tires.
  • Page 405 • Remember to check the pres- sure your spare tire. HYUNDAI recommends that you check the spare every time you check the pressure of the other tires on your vehi- cle. 7 63...
  • Page 406 Maintenance Tire rotation Disc brake pads should be inspected With a full-size spare tire (if equipped) for wear whenever tires are rotated. To equalize tread wear, it is recom- mended that the tires be rotated ✽ ✽ NOTICE every 12,000 km (7,500 miles) or sooner if irregular wear develops.
  • Page 407 Maintenance Wheel alignment and tire balance Tread wear indicator WARNING - Replacing The wheels on your vehicle were tires aligned and balanced carefully at the • Driving on worn-out tires is factory to give you the longest tire life very hazardous will and best overall performance.
  • Page 408 Maintenance Compact spare tire replacement Wheel replacement (Continued) (if equipped) When replacing the metal wheels for • The use of any other tire size A compact spare tire has a shorter any reason, make sure the new or type may seriously affect tread life than a regular size tire.
  • Page 409 Maintenance Tire traction 2. Tire size designation A tire’s sidewall is marked with a tire Tire traction can be reduced if you size designation. You will need this drive on worn tires, tires that are information when selecting replace- improperly inflated or on slippery ment tires for your car.
  • Page 410 Maintenance 92 - Load Index, a numerical code Tire speed ratings 3. Checking tire life (TIN : Tire Identification Number) associated with the maximum The chart below lists many of the dif- load the tire can carry. ferent speed ratings currently being Any tires that are over 6 years, based used for passenger cars.
  • Page 411 Maintenance 5. Maximum permissible inflation Tread wear pressure WARNING - Tire age The tread wear grade is a compara- This number is the greatest amount tive rating based on the wear rate of Tires degrade over time, even of air pressure that should be put in the tire when tested under controlled when they are not being used.
  • Page 412 Maintenance Traction - AA, A, B & C Temperature -A, B & C WARNING - Tire The traction grades, from highest to The temperature grades are A (the temperature lowest, are AA, A, B and C. Those highest), B and C representing the grades represent the tires ability to tire’s resistance to the generation of The temperature grade for this...
  • Page 413 Do not use a screwdriver or any the system involved and immediately other metal object to remove fuses consult an authorized HYUNDAI dealer. because it may cause a short circuit Three kinds of fuses are used: blade type and damage the system.
  • Page 414 5. Push in a new fuse of the same rating, and make sure it fits tightly in the clips. If it fits loosely, consult an authorized HYUNDAI dealer. If you do not have a spare, use a fuse of the same rating from a circuit you may not need for operating the vehicle, such as the cigar lighter fuse.
  • Page 415 4. Push in a new fuse of the same rating, and make sure it fits tightly in the clips. If it fits loosely, consult an authorized HYUNDAI dealer. CAUTION OVF071021 After checking the fuse box in the...
  • Page 416 Maintenance ✽ ✽ NOTICE If the multi fuse or main fuse is blown, consult an authorized HYUNDAI dealer. OVF071024 OLM079025 Main fuse Multi fuse If the main fuse is blown, it must be If the multi fuse is blown, it must be...
  • Page 417 Maintenance Fuse/Relay panel description Inside the fuse/relay box covers, you can find the fuse/relay label describing fuse/relay name and capacity. Driver’s side panel Engine compartment Diesel only OVF071025/OVF071026/OVF071028/OVF071027 ✽ ✽ NOTICE Not all fuse panel descriptions in this manual may be applicable to your vehicle. It is accurate at the time of printing. When you inspect the fuse box on your vehicle, refer to the fuse box label.
  • Page 418 Maintenance Instrument panel (Driver’s side fuse panel) Fuse rating Symbol Fuse Name Protected component POWER Console Power Outlet, Rear Power Outlet OUTLET 2 POWER Power Tail Gate TAIL GATE Smart Key Control Module, BCM, Audio, AMP, JBL AMP, A/V & Navigation Head Unit, MODULE 1 DC-DC Converter (Audio/AMP), Over Head Console Lamp, Parking Guide System, Power Outside Mirror Switch...
  • Page 419 Maintenance Fuse rating Symbol Fuse Name Protected component Power Window LH Relay, Power Window Main Switch, P/WDW LH Driver/Passenger Safety Power Window Module, Rear Safety Power Window Module LH, Rear Power Window Switch LH Tail Gate Open Relay, Trunk Lid Latch (SEDAN), PDM 1 Power Tail Gate Latch/Tail Gate Latch (WAGON), ICM Relay Box (Fuel Filler Lock/Unlock Relay)
  • Page 420 Maintenance Fuse rating Symbol Fuse Name Protected component E/R Fuse & Relay Box (Fuse - F27, F28, F29, F30, F31) Instrument Cluster, Front Seat Warmer Switch LH/RH, MODULE 6 Adaptive Front Lighting Module, Electric Parking Brake Module MDPS EPS Control Module Door Lock/Unlock Relay, ICM Relay Box (Dead Lock Relay), DR LOCK Driver/Passenger Door Lock Actuator, Rear Door Lock Actuator LH/RH...
  • Page 421 Maintenance Fuse rating Symbol Fuse Name Protected component S/HEATER RR Rear Seat Warmer Modul LH/RH 7.5A MEMORY 2 RF Receiver PDM 1 Smart Key Control Module W/O Button Start : E/R Fuse & Relay Box (RLY. 8), 7.5A START Ignition Lock Switch, Transaxle Range Switch With Button Start : ECM/PCM, Transaxle Range Switch SUNROOF Panorama Sunroof...
  • Page 422 Maintenance Engine compartment main fuse panel Fuse rating Symbol Protected component EPS Control Module I/P Junction Box (IPS 0 (4CH), IPS 1 (4CH), IPS 2 (2CH), Fuse - F13/F14/F19/F20/F21/F26/F36) ESP Control Module, Multipurpose Check Connector ESP Control Module, Multipurpose Check Connector MULTI FUSE RLY.
  • Page 423 Maintenance Fuse rating Symbol Protected component RLY. 5 (Horn Relay), ICM Relay Box (Front Deicer Relay) RLY. 12 (HAC Relay), Stop Signal Relay ICM Relay Box (Head Lamp Washer Relay) D4FD & A/T : TCM W/O Button Start : Ignition Switch, With Button Start : RLY.
  • Page 424 Maintenance Fuse rating Symbol Protected component G4FD/G4NC - Ignition Coil #1/ #2/ #3/ #4, Condenser Fuel Pump Relay G4FD : ECM G4NA/G4NC : PCM (A/T), ECM (M/T) SPARE G4NA - Injector #1/#2/#3/#4 G4FD : ECM G4NA : Fuel Pump Relay G4NC : Fuel Pump Relay, PCM (A/T), ECM (M/T) D4FD : Oil Level Sensor, Fuel Pressure Regulating Valve FUSE...
  • Page 425 Maintenance Symbol Relay Name Type C/FAN LO RELAY PLUG MICRO C/FAN HI RELAY PLUG MICRO ESS RELAY PLUG MICRO BLOWER RELAY PLUG MICRO HORN RELAY PLUG MICRO PDM 4 (IG2) RELAY PLUG MICRO FRONT WIPER RELAY PLUG MICRO PDM 2 (ACC) RELAY PLUG MICRO BURGLAR ALARM PLUG MICRO...
  • Page 426 Maintenance Engine compartment sub fuse panel (Diesel Engine) Circuit Fuse Name Fuse rating Protected component GLOW Glow Relay PTC HEATER #1 PTC Heater Relay #1 PTC HEATER #2 PTC Heater Relay #2 PTC HEATER #3 PTC Heater Relay #3 Relay Type Relay Name Relay Type Glow Relay...

  • Page 427: Light Bulbs

    HYUNDAI Removing/installing the headlight dealer. Use only the bulbs of the specified assembly can result in damage to wattage.
  • Page 428 Maintenance Headlight (Low/High), smart corner- ing light and turn signal light Smart cornering 1. Turn off the engine and open the hood. 2. Remove the front bumper. 3. Remove the headlight assembly from the body of the vehicle. If you can reach the bulb without removing the headlight assembly, you do not need to do step 2 and 3.
  • Page 429 12. Install the headlight bulb cover by turning it clockwise. ✽ ✽ NOTICE If the headlight aiming adjustment is necessary after the headlight assembly is reinstalled, consult an authorized HYUNDAI dealer. OHD076046 OVF071057 Turn signal light WARNING - Halogen bulbs Follow the steps 1 to 4 from the previous page.
  • Page 430 Front fog light bulbs by an authorized HYUNDAI Dealer. when the headlamp switch is cycled it is 1. Turn off the engine. likely the HID lamp needs to be replaced.
  • Page 431 Maintenance 5. To aim the low beam left or right, turn the driver (1) clockwise or counter- clockwise. To aim the low beam up or down, turn the driver (2) clockwise or counterclockwise. To aim the high beam up or down, turn the driver (3) clockwise or counter- clockwise.
  • Page 432 Maintenance Aiming point < Ground Height > < Distance between lamps > H1 : Height between the head lamp bulb center and ground (Low beam) H2 : Height between the head lamp bulb center and ground (High beam) H3 : Height between the fog lamp bulb center and ground W1 : Distance between the two head lamp bulbs centers (Low beam) W2 : Distance between the two head lamp bulbs centers (High beam) W3 : Distance between the two fog lamp bulbs centers...
  • Page 433 Maintenance OMD051054L Head lamp low beam (driver’s side) 1. Turn the low beam on without driver aboard. 2. The cut-off line should be projected in the cut-off line shown in the picture. 3. When aiming the low beam, vertical aiming should be adjusted after adjusting the horizontal aiming. 4.
  • Page 434 Maintenance OMD051055L Head lamp low beam (front passenger’s side) 1. Turn the low beam on without driver aboard. 2. The cut-off line should be projected in the cut-off line shown in the picture. 3. When aiming the low beam, vertical aiming should be adjusted after adjusting the horizontal aiming. 4.
  • Page 435 Maintenance OMD051056L Front fog light 1. Turn the front fog lamp on without the driver aboard. 2. The cut-off line should be projected in the allowable range (shaded region). 7 93...
  • Page 436 If the light bulb does not operate, have (1) Stop light the vehicle checked by an authorized (2) Rear turn signal light HYUNDAI dealer. (3) Back-up light (4) Tail light (5) Rear fog light (if equipped) OVF071038 Outside light Rear turn signal light 1.
  • Page 437 Maintenance 4. Loosen the light assembly retaining screws with a cross-tip screwdriver. 5. Remove the rear combination light assembly from the body of the vehicle. OVF071039 OVF071040 6. Remove the socket from the assembly Inside light by turning the socket counterclockwise 1.
  • Page 438 Maintenance 7. Install the socket in the assembly by aligning the tabs on the socket with the slots in the assembly. Push the socket into the assembly and turn the socket clockwise. 8. Install the service cover by putting it into the service hole.
  • Page 439 If the light does not operate, have the 1. Turn off the engine. vehicle checked by an authorized 2. Loosen the retaining screws with a HYUNDAI dealer. philips head screwdriver. 3. Remove the bulb assembly by turning it counterclockwise. 4. Remove the bulb by pulling it straight out.
  • Page 440 Glove box lamp (if equipped) CAUTION ■ ■ ■ ■ Be careful not to dirty or damage lens, lens tab, and plastic housings. Room lamp (Type B) If the light bulb does not operate, have the vehicle checked by an authorized HYUNDAI dealer. OVF071046/OXM079041/OVF071044/OVF071045/OVF071047/OHG070038...

  • Page 441: Appearance Care

    Maintenance APPEARANCE CARE Exterior care Finish maintenance CAUTION Washing Exterior general caution • Do not use strong soap, chemical To help protect your vehicle’s finish from It is very important to follow the label detergents or hot water, and do rust and deterioration, wash it thoroughly directions when using any chemical not wash the vehicle in direct...
  • Page 442 Maintenance Waxing Finish damage repair Wax the vehicle when water will no Deep scratches or stone chips in the longer bead on the paint. painted surface must be repaired promptly. Exposed metal will quickly rust Always wash and dry the vehicle before and may develop into a major repair waxing.
  • Page 443 Maintenance Bright-metal maintenance Underbody maintenance WARNING • To remove road tar and insects, use a Corrosive materials used for ice and tar remover, not a scraper or other snow removal and dust control may col- After washing the vehicle, test the sharp object.
  • Page 444 Maintenance Aluminum wheel maintenance Corrosion protection Moisture breeds corrosion The aluminum wheels are coated with a Moisture creates the conditions in which Protecting your vehicle from corrosion corrosion is most likely to occur. For clear protective finish. By using the most advanced design and example, corrosion is accelerated by •...
  • Page 445 Maintenance Keep your car clean Keep your garage dry Don't neglect the interior The best way to prevent corrosion is to Don't park your car in a damp, poorly Moisture can collect under the floor mats keep your car clean and free of corrosive ventilated garage.
  • Page 446 Maintenance Interior care Cleaning the upholstery and interior Cleaning the lap/shoulder belt web- trim bing Interior general precautions Clean the belt webbing with any mild Vinyl Prevent caustic solutions such as per- soap solution recommended for cleaning Remove dust and loose dirt from vinyl fume and cosmetic oil from contacting upholstery or carpet.

  • Page 447: Emission Control System

    PCSV clos- the air intake hose. Inside the crankcase, ized HYUNDAI dealer in accordance with es so that evaporated fuel is not taken the fresh air mixes with blow-by gases, the maintenance schedule in this manu- into the engine.
  • Page 448 Maintenance 3. Exhaust emission control Engine exhaust gas precautions • Do not operate the engine in confined (carbon monoxide) or closed areas (such as garages) any system more than what is necessary to move • Carbon monoxide can be present with The Exhaust Emission Control System is the vehicle in or out of the area.
  • Page 449 HYUNDAI dealer. rosion control. It may present a blink. • Avoid driving with a extremely low fuel fire risk under certain conditions.
  • Page 450 HYUNDAI dealer and then check the DPF system. If you continue to drive with the malfunc- tion indicator light blinking for a long time, the DPF system can be damaged and fuel consumption can be worsen.
  • Page 451 Dimensions / 8-2 Engine / 8-2 Bulb wattage / 8-3 Tires and wheels / 8-4 Weight and volume / 8-4 Recommended lubricants and capacities / 8-5 Vehicle identification number (VIN) / 8-8 Vehicle certification label / 8-8 Tire specification and pressure label / 8-9 Engine number / 8-9 E-mark label / 8-10 Specifications &...
  • Page 452 Specifications & Consumer information DIMENSIONS ENGINE Item mm (in) Item Diesel 1.7 Gasoline 1.6 Gasoline 2.0 Overall length 4770 (187.7) Displacement 1591 1999 1685 (cu. in) (97.08) (121.9) (102.8) Overall width 1815 (71.4) Overall height 1470 (57.8) Bore x Stroke 77x85.44 81x97 77.2x90...

  • Page 453: Bulb Wattage

    Specifications & Consumer information BULB WATTAGE Light Bulb Wattage Bulb type 55 or 35 (HID or AFLS) H7S or D1S Headlights High Smart cornering light Dedicated lamp Front Front turn signal lights PY21W Position lights Side repeater lights Front fog lights Rear fog light H21W Stop and tail lights (Outside)

  • Page 454: Tires And Wheels

    Specifications & Consumer information TIRES AND WHEELS Inflation pressure bar (psi, kPa) Wheel lug nut torque Item Tire size Wheel size Normal load Maximum load kg•m (lb•ft, N•m) Front Rear Front Rear 205/60R16 7.0J×16 (33, 230) (33, 230) (33, 230) (33, 230) Full size tire 215/50R17...

  • Page 455: Recommended Lubricants And Capacities

    Engine oil *1 *2 1.6L 3.3 l (3.48 US qt.) API Service SL or SM, ACEA A5 or above Use the engine oils approved by Hyundai Motor Company. Gasoline (drain and refill) Consult an authorized HYUNDAI dealer for details. Engine MPI engine 2.0L...
  • Page 456 Specifications & Consumer information Lubricant Volume Classification 1.6L 6.8 l (7.18 US qt.) 7.1 l (7.50 US qt.) Gasoline Mixture of antifreeze and distilled water Engine Coolant 2.0L 6.8 l (7.18 US qt.) (Ethylene glycol base coolant for aluminum radiator) 6.9 l (7.29 US qt.) Diesel Engine 6.9 l (7.29 US qt.)
  • Page 457 Specifications & Consumer information Recommended SAE viscosity Engine oil viscosity (thickness) has an When choosing an oil, consider the range effect on fuel economy and cold weather number of temperature your vehicle will be oper- operating (engine start and engine oil ated in before the next oil change.

  • Page 458: Vehicle Identification Number (Vin)

    Specifications & Consumer information VEHICLE IDENTIFICATION NUMBER (VIN) VEHICLE CERTIFICATION LABEL ■ Type A Frame number VIN label (if equipped) OYN089002 OMD081002L OVF081001 ■ Type B The vehicle identification number (VIN) is The VIN is also on a plate attached to the the number used in registering your vehi- top of the dashboard.

  • Page 459: Tire Specification And Pressure Label

    Specifications & Consumer information TIRE SPECIFICATION AND ENGINE NUMBER PRESSURE LABEL ■ ■ Gasoline engine (1.6L) Diesel engine (1.7L) OVF081002 ■ Gasoline engine (2.0L) OVF081003/OVF081004/OVF081005 The tires supplied on your new vehicle are chosen to provide the best perform- The engine number is stamped on the ance for normal driving.
  • Page 460 Specifications & Consumer information E-MARK LABEL (FOR EUROPE) (IF EQUIPPED) OMD080002 An E-mark label is located on the driver's side center pillar. The label certifies that your vehicle has satisfied the ECE Safety/Environment regulation. It con- tains the following information: •...
  • Page 461 Index...
  • Page 462 Index Air cleaner·······································································7-51 Economical operation ·····················································5-63 Airbag-supplemental restraint system ····························3-40 E-mark label····································································8-10 Appearance care······························································7-99 Emergency commodity ···················································6-30 Audio system ································································4-153 Emergency starting ···························································6-5 Automatic climate control system ································4-121 Emission control system ···············································7-105 Automatic transaxle ························································5-22 Engine ···············································································8-2 Engine compartment···················································2-5/7-2 Engine coolant ································································7-45 Battery·············································································7-58 Engine number ··································································8-9 Before driving ···································································5-3...
  • Page 463 Index Manual climate control system·····································4-112 Manual transaxle·····························································5-19 If the engine does not start················································6-4 Mirrors ············································································4-44 If the engine overheats······················································6-7 If you have a flat tire (with TireMobilityKit) ·················6-21 If you have a flat tire·························································6-8 Owner maintenance ··························································7-7 In case of an emergency while driving·····························6-3 Indicator symbols on the instrument cluster·····················1-6 Instrument cluster ···························································4-48 Panorama sunroof ···························································4-35...
  • Page 464 Index Storage compartment ····················································4-136 Tailgate············································································4-20 Theft-alarm system ·························································4-12 Tire pressure monitoring system (TPMS) ······················6-16 Tire specification and pressure label ································8-9 Tires and wheels ·······················································7-61/8-4 Towing·············································································6-26 Trailer towing··································································5-73 Vehicle break-in process ···················································1-5 Vehicle certification label ·················································8-8 Vehicle identification number (VIN) ································8-8 Vehicle weight·································································5-82 Washer fluid ····································································7-49 Weight and volume ···························································8-4...

This manual is also suitable for:

Jazz hybrid

Table of Contents

Save PDF
