- Page 1 Simpo Digital Podium User manual MODEL : SIMPO-220...
-
Page 2: Table Of Contents
Contents Introduction and notes about connection ------------------------ 1 Caution and Warnings ---------------------------------------- 2 System Components ---------------------------------------- 3 Explanation of connection terminal(upper part) ----------------- 4 Explanation of connection terminal(lower part) ------------------ 5 PC storage in/output ----------------------------------------- 6 LAPTOP PC connection ----------------------------------------- 7 PC connection ----------------------------------------- 8 Speaker connection... -
Page 3: Introduction And Notes About Connection
Introduction The Simpo is simple. The podium is minimalistic in both design and operation, yet powerful enough to support any kind of presentation you’d like to make. The Simpo’s hardware is incorporated into its structure, providing functionality without the added bulk of regular podiums. Designed to be as efficient as possible, the Simpo was designed to be operated with either a mini-pc, laptop, or other external device. -
Page 4: Caution And Warnings
Caution and Warnings Don’t use the Simpo with a damaged power cord, plug or loose socket. It may cause fire or electric shock. Don’t touch with a moist hand when taking out or inserting the power plug. It may cause fire or electric shock. Use power plugs, and sockets with grounded connections. -
Page 5: System Components
System Components ① Upper Cover (used to place laptops or text books). Do not sit or lean on this pullout cover, as it is not designed to support heavy objects. If putting heavy materials on the cover, it may cause it to break. -
Page 6: Explanation Of Connection Terminal(Upper Part)
Explanation of connection terminal (upper part) 1) Input USB for latop or other external device (TABLET sensing) / RGB(VGA) for video (gently pull the cables out, after usage push them back into the Simpo) 2) AC OUTLET(power for outer apparatus, same voltage as main input voltage) 3) Main power switch (when power is ON, switch will light) 4) Input video signal (input for composite audio and video) -
Page 7: Explanation Of Connection Terminal(Lower Part)
Explanation of connection terminal (side part) ① Speaker output terminal (25W+25W, 4 Ω) ② Audio output 1/8” (LINE OUT) ③ Video output ④ USB (for outer monitor touch sensor) ⑤ LAN Input ⑥ RGB (VGA) Output(for outer monitor) ⑦ AC Power input Imbedded fuse in AC socket. -
Page 8: Pc Storage In/Output
PC storage in-output All cables are already connected as shown below. To upper terminal To computer PC RGB/VGA PC USB PC Connection ♦ The Simpo and its PC storage were designed for use with a MINI PC. - the PC’s monitor output port should be connected to the blue PC RGB/VGA cable. - the PC tablet USB cable should be connected so that the monitor can be used as a tablet. -
Page 9: Laptop Pc Connection
LAPTOP PC connection Connect RGB/VGA cable and USB (for tablet) cable on the upper plate. LAPTOP PC connection ♦ Sound and LAN connection 1) Connect cable from audio output terminal (Green) to the device’s audio output. 2) Connect the audio input terminal (Pink) to the device’s audio input. 3) Connect laptop LAN terminal to the device’s LAN terminal. -
Page 10: Pc Connection
PC connection You can find cables which can be connected to your mini PC in the PC housing PC connection ♦ Connection sound and LAN 1) Connect PC OUT cable to PC Audio output terminal in PC housing. 2) Connect PC IN cable to PC AUDIO input terminal in PC housing. 3) Connect LAN cable to PC LAN terminal in PC housing. -
Page 11: Speaker Connection
Speaker connection Connect speakers ♦ Amplifier can support a maximum output of 50W (25W + 25W) 4Ω. ATTENTION! : When connecting speakers, pay attention that you do not reverse their polarity. -
Page 12: Product Specifications
Specifications Product specifications contents Specification Speaker output 50W 4Ω ( 25W + 25W) Stereo Mic input 30mV (1 Input) Response frequency 25Hz ~ 20KHz Highest angle of monitor 50 degrees Input terminal LAN , AV, RGB(LAPTOP), RGB(PC), MIC(LAPTOP), USB Out put terminal SOUND OUT, RGB, LINE OUT, VIDIO, AC OUTLET Height / monitor angle MOTOR actuator X 2EA... -
Page 13: Pc Storage Dimensions
PC Storage Dimensions The Simpo is available with two PC storage case sizes. The smaller case is designed for use with mini PCs and the larger size for slim PCs. The dimensions for both are shown below in millimetres. Mini PC Storage Slim PC Storage... -
Page 14: Fault Diagnosis
Fault diagnosis Fault diagnosis If encountering a problem with the Simpo, take a look at the list of most common resolutions below. Before requesting repair, make sure your problems aren’t caused by any of these errors. symptom Fault diagnosis remark ...
