Summary of Contents for NewSound Aria mini series
- Page 1 User Manual Aria mini! More than simplicity Aria...
-
Page 3: Table Of Contents
Contents Preface Description Preparation Attaching the domes and tubes Replacing the batteries (on/off control) Insertion and Removal Operation Volume Control Memory Switch (digital models only) Maintenance Troubleshooting Guide Low Battery Warning Caring for Batteries Cleaning Appendix Working condition Technical Data FDA information... -
Page 4: Preface
Aria mini is one type of hearing instrument. Scope This user manual only applies to Aria mini series hearing instruments. Precautions For patients with middle ear infection, hearing instrument can't be worn until cured or follow your doctor's recommendation. -
Page 5: Description
Description 1. Microphone inlet 2. Memory switch (digital models only) 3. Volume control (on/off control) 4. Battery compartment 5. Tube/sound output 6. Dome 7. Retention... -
Page 6: Preparation
Preparation Attaching the domes and tubes Attaching the domes Push the dome over the grooves on the tube to mount it. Attaching the tubes Hold the end of the tube in one hand and the hearing instrument in the other. Line up the sound tube on top and push onto the adaptor that sticks out of the hearing instrument case. -
Page 7: Replacing The Batteries (On/Off Control)
Replacing the batteries (on/off control) Aria mini uses a 10A zinc air battery as its power source. 1. Using the nail grip, open the battery door and remove the old battery. 2. Remove the protective foil from the new battery and wait 2 minutes. -
Page 8: Insertion And Removal
Insertion and Removal Place the hearing instrument over your ear, then insert the dome or mold. 1. Place the hearing instrument over the top of your ear. 2. Hold the tube near the tube with your thumb and forefinger. Gently insert the dome into your ear canal, until the tube sits flush against the side of your head. -
Page 9: Operation
Operation Volume Control To adjust the volume, rotate the volume control by your fingertip. To increase the volume, turn the volume control counter-clockwise . To decrease the volume control, turn the volume clockwise This Volume Control only support 250 degree rotate. - Page 10 Your hearing instrument can be programmed with up to 4 different listening programs. When the hearing instrument is turned on, it will automatically be in Program 1 - quiet environment mode. The additional settings that are pre-programmed for your specific needs are accessed by the memory switch, Program 2 - noisy environment mode, Program 3 - telecoil mode and Program 4 - mute mode.
-
Page 11: Maintenance
Maintenance Troubleshooting Guide SYMPTOM POSSIBLE CAUSES SOLUTIONS No battery Insert battery Dead or low battery Replace battery N o sound Battery improperly inserted Insert battery correctly Clean both microphone and receiver with brush. Wax or debris in the microphone Remove and clean the dome or receiver Low battery Replace battery... -
Page 12: Caring For Batteries
Caring for batteries The performance of hearing instrument depends on the quality of the batteries used to a large extent. 1. Our hearing instrument, it is important to use high-quality batteries. The lifetime of a battery is influenced by the quality. With reliable batteries, you can avoid periodic hearing instrument failures. -
Page 13: Cleaning The Instrument
Cleaning the instrument Clean your instrument with a soft, dry cloth and the small brush. Do the cleaning on the soft table to avoid damage or scratch if the instrument fell. Do not use water or other fluids. Cleaning the tube After removing the tube from the hearing instrument, use the black cleaning rod to “push”... -
Page 14: Appendix
500 and 1100 hPa is not detrimental to the instrument. Technical Data Maximum Output ( 2cc-coupler / IEC-118-7/2005 ) Aria mini series 112dB (Typical) Manufactuer Wellkang Ltd t/a Wellkang Tech Consulting Suite B, 29 Harley Street LONDON W1G 9QR... -
Page 15: Fda Information
FDA information Following the medical evaluation, the physician will give you a written statement that states that your hearing loss has been medically evaluated and that you may be considered a candidate for a hearing aid. The physician will refer you to an audiologist or hearing aid dispenser, as appropriate, for a hearing aid evaluation. - Page 16 Notes...
- Page 17 Notes...
- Page 18 Notes...
- Page 20 US HQ: 3948 Addison Woods Road, Frederick, MD 21704-USA E-mail: sales@usnewsound.com www.usnewsound.com Version:1108A 6098- 000...
