ViewSonic TD2740 Specifications page 2

27" Multi-Touch
Full HD 1080p Monitor
Stable Bookstand Base with Ergonomic Tilt Adjustment
The TD2740 has a stable, integrated bookstand design that makes it
easy to adjust the angle of the display for a better user experience.
The ergonomic tilt can be adjusted from between 15 to 70 degrees,
or the display can be laid completely flat on a tabletop so that you
can create a more comfortable work environment. The TD2740's
advanced ergonomic technology is designed to provide
an excellent touch experience with maximum
comfort and productivity.
Lay Flat
VA Panel with Full HD 1080p Resolution
SuperClear™ VA technology provides viewers with a 178°/
VA
178° wide-viewing angle and consistent color performance.
The TD2740 also features 1920 x 1080 native resolution,
and a 20M:1 MEGA Dynamic Contrast Ratio to deliver
stunning, crisp, and sharp images every time – no matter
which high-definition multimedia application you choose.
HDMI (MHL) and DisplayPort Inputs for
Multimedia Devices
The TD2740 is equipped with HDMI (MHL) and DisplayPort
inputs that let you connect to a wide range of high-
definition digital devices, including PS3/Xbox360 and Blu-
ray DVD players. In addition, MHL-enabled devices such as
smartphones and tablets can be plugged into the TD2740. This
allows you to enjoy HD content from your mobile devices within
the large screen format of the TD2740.
Specifications
LCD PANEL Type
Display Area
Optimum Resolution
Brightness
Contrast Ratio
Dynamic Contrast Ratio
Viewing Angles
Response Time
Backlight
Backlight Life
Panel Surface
VIDEO INPUT Analog
Digital
Frequency
Sync
AUDIO OUTPUT Speakers
COMPATIBILITY PC
CONNECTOR Video Analog
Video Digital
USB
Audio
Power
WEBCAM Hardware
POWER Voltage
Consumption
Optimize
Conserve
CONTROLS Front Panel Buttons
OSD
*Energy savings may vary based on actual usage and other factors. Program, specifications and availability are subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic
representative for complete details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2013 ViewSonic Corporation. All rights reserved. [16706-00B-05/13]
Sales: (888) 881-8781 or SalesInfo@ViewSonic.com • More product information: www.ViewSonic.com
70º
27" Wide Color TFT Active Matrix VA LED
23.5" horizontal x 13.2" vertical; 27.0" diagonal
1920x1080
260 cd/m (typ.)
2
3000:1 (typ.)
20,000,000:1
178º horizontal, 178º vertical
12ms (typ.)
White-light LED
30,000 hours (min.)
7H Scratch Resistant Surface Hardness
RGB analog (0.7 / 1.0 Vp-p, 75 ohms)
HDMI (TMDS, 100 ohms) / DisplayPort (PCI-E)
Fh: 24~82kHz, Fv: 50~75Hz
Separate Sync
2-watt (x2)
PC compatibles (VGA up to 1920 x 1080 Non-Interlaced)
15-pin mini D-sub (VGA)
HDMI (v1.4), DisplayPort, MHL (shared with HDMI port)
USB 2.0 x2
Audio In (3.5mm mini-jack)
Earphone Out (3.5mm mini-jack)
Internal power board, 3-pin plug (CEE22)
1MP
AC 100–240V (universal), 50 / 60Hz
w/o audio 39W (typ.) / w/ audio 52W (typ.)
33.5W (typ.)
28W (typ.)
1, 2, Down, Up, Power
Auto Image Adjust, Contrast/Brightness, Input Select, Audio
Adjust, Color Adjust, Information, Manual Image Adjust,
Setup Menu, Memory Recall (See user guide for complete
OSD functionality)
7H Scratch-Resistant
Surface Hardness
15º
Integrated Speaker
Adjustable
Bookstand
AC-In Power
ERGONOMICS
OPERATING Temperature
CONDITIONS
DIMENSIONS Physical with Stand
(W x H x D)
WEIGHT Net with Stand
WALL MOUNT
REGULATIONS
RECYCLE / DISPOSAL
WARRANTY
What's in the box?
TD2740 display, power cable, audio cable, VGA cable, HDMI cable, USB cable, Quick Start Guide,
ViewSonic Wizard CD (available in some countries only)
TD2740
Webcam 10-Point Projected Capacitive
Integrated Speaker
Wall Mountable
USB (Type A x2,
Type B x1)
Tilt 15º – 70º, lay flat
32–104º F (0–40º C)
Humidity 20–90% (non-condensing)
26.5 x 16.5 x 2.0 in. / 672.6 x 418.9 x 49.9 mm
Packaging 29.1 x 20.1 x 5.0 in. / 739 x 510 x 127 mm
19.4 lb. / 8.8 kg
Gross 23.1 lb. / 10.5 kg
VESA 100mm x 100mm
®
WEEE, RoHS, CE, CB, Window 8, FCC-B w/ ICES003,
US NRTL w/ CA, cULus/cTUVus, cETLus/cBVus,
Mexico, Mexico Energy
Please dispose of in accordance with local, state
or federal laws.
Three-year limited warranty on parts, labor and backlight.
Touch Technology
Touch Sensitive
Controls
Kensington
®
Lock Slot
HDMI / MHL
VGA
DisplayPort
Headphone Jack
Audio In
ViewSonic Corporation's QMS & EMS
have been registered to ISO 9001 & ISO
14001, respectively, by TUV NORD.
