Consonance CD120 Linear User Manual page 4

To cancel repeat, press the
To cancel repeat, press the
Dim display
To dim the display on the screen, press the FA button. The display will change from bright to
dead on the screen.
Switch sampling
While the player in standby, press the FB button to switch the sampling
44.1/ 88.2kHz.
Track information
While the player in playing, press the FB button to show the track time, time left of the playing
track and time left of whole disc.
Back panel of CD-player
From left to right the connectors are :
AC Power connection 240V / 230V / 220V / 115V / 100V AC dependent on country.
Digital output Phono/RCA
Unbalanced outputs Phono/RCA right/left
We recommend to connect signal cables to the CD-player when the CD-player and all the
other units of the audio system is switched off.
The CD-player has two types of analog audio outputs: unbalanced audio signal with RCA
plugs (phono plugs) .
button third.
button third. "REP OFF" will be displayed on the screen.
4
