Pure Sine Wave Power Inverter
• High efficiency- save battery
• Compact size- portable
• Low Idle Current
• Soft Start Technology
THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING
SAFETY, OPERATION, MAINTENANCE AND STORAGE OF THIS
PRODUCT. BEFORE USE, READ AND UNDERSTAND ALL CAUTIONS,
WARNINGS, INSTRUCTIONS AND PRODUCT LABELS, PLUS YOUR
VEHICLE'S BATTERY MANUFACTURER GUIDELINES. FAILURE TO DO
SO COULD RESULT IN INJURY AND/OR PROPERTY DAMAGE.
To ensure reliable service, your power inverter must be installed and used properly.
Please read the installation and operating instructions thoroughly prior to
installation and use. Pay particular attention to the WARNING and CAUTION
statements in this manual. The CAUTION statements advise against certain
conditions and practices that may result in damage to your inverter. The WARNING
statements identify conditions or practices that may result in personal injury. Read
All Instructions Before Using This Power Inverter!
OWNER'S MANUAL
Featured Design
IMPORTANT SAFETY INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pure Sine Wave and is the answer not in the manual?

Questions and answers

Summary of Contents for Voltec Pro Pure Sine Wave

  • Page 1 Pure Sine Wave Power Inverter OWNER’S MANUAL Featured Design • High efficiency- save battery • Compact size- portable • Low Idle Current • Soft Start Technology THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY, OPERATION, MAINTENANCE AND STORAGE OF THIS PRODUCT. BEFORE USE, READ AND UNDERSTAND ALL CAUTIONS, WARNINGS, INSTRUCTIONS AND PRODUCT LABELS, PLUS YOUR VEHICLE’S BATTERY MANUFACTURER GUIDELINES.

  • Page 2: Important Cable Information

    WARNINGS: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, EXPLOSION OR INJURY: 1. Do not connect to AC distribution wiring. This inverter is NOT grid interactive. 2. Remove appliance plug from outlet strip or turn off inverter before working on the appliance.

  • Page 3: Installation / Environments

    THE OUTPUT WAVEFORM The AC output waveform of the inverter is known as “Pure Sine Wave” or “True Sine Wave”. It is a waveform that has characteristics same to the sine wave shape of utility power. (See Figure 1).
  • Page 4 The inverter will provide you 115 VAC when powered by a 12 VDC source such as is found in a vehicle or multiple battery configurations as shown in FIGURE 2. This manual does not describe all of the possible types of battery configurations, battery charging configurations and battery isolation configurations.

  • Page 5: Connecting To A Power Source

    CAUTION: Loose connectors may cause overheated wires and melted insulation. Check to make sure you have not reversed the polarity. Reverse polarity connection will result in a blown fuse and may cause permanent damage to the inverter. CONNECTING TO A POWER SOURCE External FUSE and DC cable selection: WATT FUSE...

  • Page 6: Connection To Load

    11. If the inverter is not properly operating, then refer to the troubleshooting sections of this manual. CAUTION: Loose connectors may cause overheated wires and melted insulation. CONNECTION TO LOAD Plug the cord from the equipment you wish to operate into the AC receptacle. The green LED indicator lights to indicate that the inverter is functioning.

  • Page 7: Operating Tips

    SAFE – Do not use the inverter near flammable materials or in any locations that may accumulate flammable fumes of gases. OPERATING TIPS RATED VERSUS ACTUAL CURRENT DRAW OF EQUIPMENT Most electrical tools, appliances and audio/video equipment have labels that indicate the power consumption in amps or watts.

  • Page 8: Protective Features Of The Inverter

    To get an estimate of the current (in amps) that the battery must be capable of delivering, divide the load consumption power (in watts) by (10). Keep in mind that most appliances are not operating for long periods of time. For example, a typical home-use coffee maker draws 500 watts during its brew time of 5 minutes, but it maintains the temperature of the pot at about 100 watts.

  • Page 9: Special Features

    If the low voltage alarm sounds when the battery is fully charged, follow the steps for solving lack of output power in the Troubleshooting guide. The alarm will sound when the inverter is overloaded, in thermal shutdown, or if there is an excessive voltage drop between the battery and inverter.

  • Page 10: Troubleshooting Guide

    TROUBLESHOOTING GUIDE TABLE 1 – INVERTER POWER SWITCH TURNED ON TROUBLE/ INDICATION POSSIBLE CAUSE SUGGESTED REMEDY No AC output; Low battery voltage Recharge or replace battery Yellow LED lit Inverter overheatthermal Remove or reduce load, Green LED not lit shutdown wait for inverter to cool.

  • Page 11: Fuse Replacement

    CAUTION: NO USER-SERVICEABLE COMPONENTS INSIDE. DO NOT ATTEMPT TO OPEN THE INVERTER. SPECIFICATIONS Output Connection………………..……………North America AC Receptacle(s) Output Voltage………………………………….. Approx 115 volt AC RMS 60 Hz Output Waveform……………………………………….Soft Start Pure Sine Wave Max. Efficiency……………………………………………………Approximately 90% Input Voltage …………………………………….….……………12.5 volt DC Input Fuse……………………………………………………………………..Internal...
