- Page 1 VikinX User Manual VD3232M/VD6464M/VD9696M/VD128128M/VD3232S/ VD6464S/HD3232M/HD6464M/HD9696M/HD128128M/ HD3232S/HD6464S VikinX Modular SD/HD Video Router Rev. 13...
-
Page 2: Revision History
Modular SD/HD Video Router Rev. 13 Network Electronics ASA Thorøya P.O. Box 1020 Sandefjord, Norway Phone: +47 33 48 99 99 Fax: +47 33 48 99 98 E-mail: mailto:support@network-electronics.com http://www.network-electronics.com/ Service Phone: +47 90 60 99 99 Revision history Current revision of this document is the uppermost in the table below. -
Page 3: Table Of Contents
Modular SD/HD Video Router Rev. 13 Contents Revision history................2 General environmental requirements for Network Electronics equipment ..................5 Product Warranty ................6 ® Important notes regarding Software in the VikinX Modular router family range ................... 7 1 Product overview................. 8 1.1 Product versions ..................8... - Page 4 Modular SD/HD Video Router Rev. 13 4.2 Maximum cable length (RS-232) ...............27 4.3 Ethernet connection ..................27 5 Connecting signal cables to the Modular SD/HD Video Router .. 28 6 Before calling Network Support ..........29 7 Serial number overview ............. 30 Notes ...................
-
Page 5: General Environmental Requirements For Network Electronics Equipment
Modular SD/HD Video Router Rev. 13 General environmental requirements for Network Electronics equipment 1. The equipment will meet the guaranteed performance specification under the following environmental conditions: - Operating room temperature range: 0°C to 45°C - Operating relative humidity range: <... -
Page 6: Product Warranty
Modular SD/HD Video Router Rev. 13 Product Warranty The warranty terms and conditions for the Modular SD/HD Video Router follow the General Sales Conditions by Network Electronics ASA. These conditions are available on the company web site of Network Electronics ASA: www.network-electronics.com... -
Page 7: Important Notes Regarding Software In The Vikinx
This product utilises software components that are licensed with open source licenses. The source code for these components, and our modifications are available from: http://labs.network-electronics.com/open-source/ You may also send Network Electronics a recordable CD and a self-addressed http://labs.network- envelope, and we will burn the contents of electronics.com/open-source/ to your CD and send it back to you. -
Page 8: Product Overview
3 party management software. On top of that does the Network Electronics’ THOR management package allow control of the most common 3 party routers. This enables you to utilise existing routers and management systems from other manufacturers and still draw the ®... - Page 9 Modular SD/HD Video Router Rev. 13 HD9696M As above, but equipped 96x96. HD128128M As above, but fully equipped 128x128. High Definition Serial Digital Video - 5RU: ® HD3232S VikinX Modular multirateframe for SDI and HD-SDI (19.4 to 1485 Mbps), 5RU, equipped 32x32, expandable up to 64x64 in steps of 32x32.
-
Page 10: Specifications
Modular SD/HD Video Router Rev. 13 2 Specifications 2.1 Mechanics Dimensions: HxWxD = 396x483x340mm, (19”, 9RU), or HxWxD = 220x483x340mm, (19”, 5RU). Backplane card: 128x128 HD/SD video (9RU), or 64x64 HD/SD video (5RU). X-point Modules: 32x32 module cards. System Controller: 1 SysCon card required, must be specified, 1 redundant card is optional. -
Page 11: Video Specifications
Modular SD/HD Video Router Rev. 13 Internal module voltages. Status surveillance: On each board with LED, and via system controller. Re-clocker option: Bypass of re-clocking (from system controller). Synchronisation handled Analogue Black Burst, Looped. Both PAL and NTSC by SysCon: supported. - Page 12 Modular SD/HD Video Router Rev. 13 Electrical signal outputs, HD: Connector: 75 ohm BNC female. Impedance: 75 ohm nominal. Return loss: > 15dB (5MHz-1.485Ghz). Signal level: 800mVp-p ±10%. Signal polarity: Non-inverting with respect to inputs. Signal transition (both video formats): Jitter: <...
-
Page 13: Rear View
Modular SD/HD Video Router Rev. 13 2.5 Rear view The following service connectors can be found on the rear of the Modular SD/HD Video Router: AC Mains A: AC mains power supply. AC Mains B: AC mains power supply (if redundant AC/DC PSU is installed). - Page 14 Modular SD/HD Video Router Rev. 13 Serial GYDA B: RS-232 or RS-422 for external connection to GYDA-VX (if redundant GYDA-VX is installed). Ethernet GYDA A: 10/100Base-T Ethernet bus for external connection to GYDA-VX (if GYDA-VX is installed). Ethernet GYDA B: 10/100Base-T Ethernet bus for external connection to GYDA-VX (if redundant GYDA-VX is installed).
-
Page 15: Modules Inside The Modular Sd/Hd Video Router
Modular SD/HD Video Router Rev. 13 3 Modules inside the Modular SD/HD Video Router In order to get an overview of the parts that form the Modular SD/HD Video Router this chapter will highlight some of the main components. GYDA SysCon (not shown in picture) Power Supplies X-point Modules 3.1 How to access the modules... -
Page 16: Power Supply Module
Modular SD/HD Video Router Rev. 13 For further instructions on router configuration, please see the online documentation in the System Configurator. 3.3 Power Supply module Each Modular SD/HD Video Router frame comes with either one or two power supply modules. One power supply is standard, dual redundant power supply is an option. -
Page 17: Status Leds And Relay Contacts
Modular SD/HD Video Router Rev. 13 Note: There is a switch on the right hand side of the power supply module that selects mains voltage. The mains voltage can be either 110VAC or 230VAC. This switch must be set in the correct position, depending on the mains voltage on the router’s site. -
Page 18: System Controller - Syscon
Modular SD/HD Video Router Rev. 13 3.4 System Controller – SysCon ® Each VikinX Modular frame comes with either one or two system controller cards, SysCon. One SysCon is necessary to control the router; dual redundant SysCon is an option. SysCon can be enabled for 3 party control interfaces as an option. -
Page 19: Card Removal
Modular SD/HD Video Router Rev. 13 3.4.2 Card removal To remove a module card from the sub-rack frame, release the card by moving the red handle until it is in horizontal position, as shown in the figure below. Then pull the card out of the sub-rack with the red handle. 3.4.3 Status LEDs and Reset button There are 4 LEDs on the front side of the SysCon card, and a reset button on the rear side. -
Page 20: Cf-Card And Battery
Modular SD/HD Video Router Rev. 13 The LEDs indicate the following: Diode Red LED Yellow LED Green LED No light Status Card error. Not applicable. Overall status of the Card has no power, or card is OK is not inserted correctly. -
Page 21: Gyda-Vx
Modular SD/HD Video Router Rev. 13 Compact Flash card 1. Remove the SysCon card from its slot, according to the description earlier in this manual. 2. Slide the CF card out of its socket, and insert the new CF card into the socket. -
Page 22: Card Insertion
Modular SD/HD Video Router Rev. 13 Your GYDA-VX card(s) may be inserted in any of the two dedicated GYDA slots (A) and (B). See picture under 3. 3.5.1 Card insertion The GYDA-VX card is inserted in the exact same way as the SysCon card. See Chapter 3.4.1. -
Page 23: Card Insertion
Modular SD/HD Video Router Rev. 13 3.6.1 Card insertion To insert a X-point card, slide the module along the plastic guide rails into its position. On both sides of the card tray there is a hole next to each module slot. -
Page 24: Service Switches And Reset Button
Modular SD/HD Video Router Rev. 13 There are 10 LEDs on the front of each X-point card, and they indicate the following: Diode Red LED Green LED Blinks when the µController is running BEAT (heartbeat). SYST.ERR A fault is detected on the card. The system controller lights, or turns off this LED. - Page 25 Modular SD/HD Video Router Rev. 13 switch must always be in the position towards the card front. The switch is for factory use only. Reset button Service switches SW4 + SW2...
-
Page 26: Router Communication
Modular SD/HD Video Router Rev. 13 4 Router communication You gain access to router for communication purposes by connecting either the router’s serial port to your computer and/or by using an Ethernet connection. 4.1 Serial connection Connection can by made trough the serial port(s) of the router; see also Chapter 1 for connection details. -
Page 27: Maximum Cable Length (Rs-232)
Modular SD/HD Video Router Rev. 13 4.2 Maximum cable length (RS-232) IEEE has specified the maximum cable length for an RS-232 connection to 15m. Longer distances can be installed depending on the environmental conditions of the installation site. It is the responsibility of the installer / user to secure a proper installation of the RS-232 connection. -
Page 28: Connecting Signal Cables To The Modular Sd/Hd Video Router
Modular SD/HD Video Router Rev. 13 5 Connecting signal cables to the Modular SD/HD Video Router The Modular SD/HD Video Router offers standard 75Ohms BNC connectors for video in- and outputs. All video inputs are terminated with 75Ohms. <Picture…>... -
Page 29: Before Calling Network Support
Modular SD/HD Video Router Rev. 13 6 Before calling Network Support The following table shows possible symptoms, and what to do in order to correct possible error sources. Every user should read this before calling Network Technical Support. Symptom What to do… The lower, GREEN LED on the Power Supply is No mains, or battery power supplying the OFF. -
Page 30: Serial Number Overview
Modular SD/HD Video Router Rev. 13 7 Serial number overview The following table shows the serial numbers of all parts of your Modular SD/HD Video Router. Please refer to these numbers when contacting Network Electronics ASA for product support. Device / Part Part / Serial number Frame, including all static cards Power Supply Module #1... -
Page 31: Notes
Modular SD/HD Video Router Rev. 13 Notes... -
Page 32: Materials Declaration And Efup
Modular SD/HD Video Router Rev. 13 Materials Declaration and EFUP Materials declaration For product sold into China after 1st March 2007, we comply with the “Administrative Measure on the Control of Pollution by Electronic Information Products”. In the first stage of this legislation, content of six hazardous materials has to be declared. -
Page 33: Recycling Information
Network Electronics ASA’s Customer Support for assistance with recycling if this site does not show the information you require. Where it is not possible to return the product to Network Electronics ASA or its agents for recycling, the following general information may be of assistance: Before attempting disassembly, ensure the product is completely disconnected from power and signal connections. -
Page 34: Ec Declaration Of Conformity
Not applicable (Established within the EEA) MODEL NUMBER(S) HD3232M / HD6464M / HD9696M / HD128128M HD3232S / HD6464S VD3232M / VD6464M / VD9696M / VD128128M VD3232S / VD6464S DESCRIPTION Modular Multirate SD/HD Digital Video Router DIRECTIVES this equipment complies with...
