NWSR483EB – Hotpoint 7.0 Cu. Ft. Super Capacity Electric Dryer
Dryer Dimensions (in inches)
23-1/2
28-1/4
25-1/2*
8-1/2
Side View
* 24-1/2" from the edge of the side panel to the front. 25-1/2" from front to edge of end caps.
Specification Revised 3/03
®
*24-1/2" from the edge of the side panel to the front.
25-1/2" from front to edge of endcaps.
27
42
11-1/2
36
2
3-1/2
2-1/2
Rear View
Exhaust Options:
4-way via rear, right, left and bottom.
Circuit Requirements:
An individual, properly-grounded branch circuit, protected by a 30-amp circuit
breaker or a time-delay fuse, is required.
Electric Dryer Rating:
208/240V, 5600W, 60Hz, 24 Amp
Installation Information: For complete information, see installation
instructions packed with product for current dimensional data.
Listed by
Underwriters
Laboratories
R
